PTH8708 User’s Manual

Specifications subject to change

without notice

NOTICE - WE ARE NOT

RESPONSIBLE FOR

TYPOGRAPHICAL ERRORS.

MAN#PTH8708 05/08

PTH8708

USER’S MANUAL

DIGITAL

TEMPERATURE/

HUMIDITY

PEN

Ideal for: HVAC, Hospitals, Laboratories,

Computer Rooms, Paper Mills, General Use,

Wood & Furniture Industry, Industrial,

Printing, Nurseries, Film Processing,

Greenhouses, Tobacco Industry

FEATURES:

• Simultaneous Display of Temperature

and Humidity

• °F/°C Switch

• Auto Power Off:

Approximately after 20 minutes

• MIN/MAX Memory

• RESET Switch

• HOLD Switch

• Pocket-sized • Belt or Pocket Clip

SPECIFICATIONS:

• Range: 14° to 122°F (-10° to 45°C)

• Humidity Range: 5 to 95% RH

• Accuracy: ±3% from 10 to 90%RH

at 77°F (25°C); ±5% from 5 to 10%RH

and from 90 to 95%RH

• Resolution: 0.1°F/0.1°C

• Sensor: Electronic Capacitance

Polymer Film Sensor

• Power Source: 1 “CR2032” battery (included)

• Battery Life: 150 hours

• Dimensions: 6.9" x 1.7" x 0.6"

(175 x 42 x 16 mm)

• Weight: 1.6 oz (45 g)

• Color: Dark Gray

PTH8708 Manual 050815 FINAL Page 1

NORMAL MEASUREMENT:

1. Turn meter on by pressing “ON/OFF” button.

2. Press “C/F” key to convert reading to

desired range. Both temperature and

relative humidity measurement will

display simultaneously.

MIN/MAXFUNCTION:

1. Press and hold “MIN/MAX” button until

(MIN) appears on display. Display is now

showing minimum humidity and temperature

reading in memory.

2. Press and hold “MIN/MAX” button again

until (MAX) appears on display. Display is

now showing maximum humidity and

temperature readings in memory.

3. To return to current temperature and

humidity readings, press and hold

“MIN/MAX” button until (MIN) or (MAX)

disappears from display.

4. To clear current “MIN” and “MAX” reading

from memory, press and hold “RESET”

button until entire display flashes.

DATE HOLDFUNCTION:

1. Press “HOLD” button until (HLD) appears

in display. The current reading is now

being held and will not change until

“HOLD” function is cancelled.

2. Press “RESET” button to cancel the

“HOLD” function. The Hold function

can be used for temperature, humidity,

dew-point and wet bulb.

AUTOPOWER OFF:

1. Unit will turn itself off after 20 minutes.

(Sleep mode)

2. To override Auto Power Off function

(Non-Sleep Mode) press “ON/OFF” and

“MIN/MAX” button simultaneously.

After the full display appears release

“ON/OFF” button, the display will show

“n” in left side. When “n” appears, then

release “MIN/MAX” button. Unit will now

be in Non-sleep Mode.

CHANGINGTHEBATTERY:

1. Use a coin to turn off the battery cover.

2. Put the battery whose “+” faces out

into the battery compartment, place the

battery cover back and lock it.

NOTE:

Remember low batteries will tend

to give inaccurate readings, so make sure

you have good batteries.

Please do not immerse probe into liquids

as this will cause permanent damage

to the sensor.

PTH8708 Manual Page 2 060815
