Residential Power Washers

2500psi

2700psi

3100psi

2500/2700/3100

features

Model UPC: Emissions

Certification

2500psi @ 2.3 gpm

6020-2 6 96471 06020 1 49-State

2700psi @ 2.3 gpm

6022-2 6 96471 06022 5 49-State

6023-0 6 96471 06023 2 50-State

3100psi @ 2.7 gpm

6024-2 6 96471 06024 9 49-State

6025-0 6 96471 06025 6 50-State

GENERAC OHV ENGINE

• LowOilShutdownonallModels

EASY ACCESS

• Axialcampumpiswellabovetheground,makinghoseconnectionseasy.

• EngineControls(clearlymarkedforeasystarting)

MOBILITY

• Balancedforalmosteffortlessmobility,regardlessofterrain.

• Pumpheightmakesiteasytogatherhosesfortransport.

COMFORT

• CushionGrip(providesgreatercomfortwhilecleaning)

• Easy-to-pulltriggerreducesfatigue.

• Longergun–improvedgripsurface.

• Rearhoseconnectiononspraygunprovidesbetterbalanceandcomfort.

COMPACTDESIGN

• Doesn’ttakeupmuchroominthegarageorshed

2 of 2

Residential Power Washers

GeneracPowerSystems,Inc.•P.O.Box8,Waukesha,WI53187•generac.com

specifications by model

OutletPressure-(PSI)/(BAR) 2500/172 2700/186 3100/213

FlowRate-(GPM)/(Liters/min) 2.3/7.6 2.3/7.6 2.7/10.2

(49State) 60202 60222 60242

CARBcertified(50State) N/A 60230 60250

Engine

EngineManufacturer Generac Generac Generac

EngineDisplacement

(CubicInch)/(cc) 11.9/196 11.9/196 12.9/212

EngineType OHV(Over

HeadValve)

OHV(Over

HeadValve)

OHV(Over

HeadValve)

EngineOrientation Horizontal Horizontal Horizontal

NetTorque 12.4N.m(9.1

lb.ft)/2500rpm

12.4N.m(9.1

lb.ft)/2500rpm

12.5N.m(9.2

lb.ft)/3000rpm

GrossPower 6.5Hp/

3600rpm

6.5Hp/

3600rpm

7.0Hp/

4000rpm

LowOilShutDownSystem Yes Yes Yes

FuelCapacity-(Quarts)/(Liters) 3.6/3.5 3.6/3.5 3.6/3.5

FuelOn/OffSwitch Yes Yes Yes

OilCapacity-(Oz)/(Liters) 20/0.6 20/0.6 20/0.6

RecomendedEngineOil SAE30or

10W30

SAE30or

10W30

SAE30or

10W30

ThrottleControl Manual Manual Manual

Choke Manual Manual Manual

StartingMethod Manual Manual Manual

On/OffSwitch Yes Yes Yes

Pump

PumpType AxialCam AxialCam AxialCam

Plunger Stainless

Steel

Stainless

Steel

Stainless

Steel

Material

Aluminum

Body&

Head

Aluminum

Body&

Head

Aluminum

Body,Brass

Head

Misc Oversized

Bearings

Oversized

Bearings

Doubleseal

systemwith

oversized

bearings

Watersupplytemperature(°F)/(C°) 100/38Max

Hose

Hoselength-(Feet)/(Meters) 25/7.6 25/7.6 30/9.1

HoseDia.(Inch)/(mm) 1/4/6.4 1/4/6.4 1/4/6.4

HoseRating 3100psi 3100psi 3100psi

HoseConnectors M22

Threaded

M22

Threaded

M22

Threaded

DetergentSystem

ChemicalTank(s)Numberperunit 012

ChemicalTank(s)-Description Siphon

Hose 3/4Gallon 3/4Gallon

Nozzles

Nozzles-Numberperunit 345

Nozzles-Description 0,25,Soap 0,25,40,

Soap

0,15,

25,40,

Soap

Gun&Lance

Gun Standard Standard Deluxe

GuntoLanceConnection M22

Threaded

M22

Threaded

M22

Threaded

GuntoHoseConnection M22

Threaded

M22

Threaded

M22

Threaded

LanceLength(Inch/CM) 20/51 20/51 20/51

LancetoNozzleConnection Quick

Change

Quick

Change

Quick

Change

LanceMaterial Chrome

PlatedSteel

Chrome

PlatedSteel

Chrome

PlatedSteel

LanceConnectorMaterial Brass Brass Brass

Warranty

Warranty 2Yr.

Limited

2Yr.

Limited

2Yr.

Limited

Frame&Misc.

Handle Fixed Fixed Fixed

Construction Welded

Steel

Welded

Steel

Welded

Steel

Wheels 1.5"x10"

NeverFlat

1.5"x10"

NeverFlat

1.5"x10"

NeverFlat

DimensionsandWeights

UnitDimensions(Inches)andWeight(lbs)

Length(L) 231/4 231/4 231/4

Width(W)[WheeltoWheel] 16 16 16

Height(H) 401/2 401/2 401/2

Unitweightincludinghose,

gun&lance(lbs) 60.3 61.5 67.5

Actualboxedweight 68 69 74

Actualboxedlength 27.0 27.0 27.0

Actualboxedwidth 17.5 17.5 17.5

Actualboxedheight 21.0 21.0 21.0

2500/2700/3100
