Gefen HDMI-CAT5-MS Manuel utilisateur

www.gefen.com

CAT-5 MS

Extreme Extender

EXT-HDMI-CAT5-MS

User Manual

www gefen com

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen Inc.

c/o Customer Service

20600 Nordhoff St

Chatsworth, CA 91311

www.gefen.com

[email protected]

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and

any accompanying documentation without prior written notice.

HDMI CAT-5 MS Extreme is a trademark of Gefen Inc.

All trademarks are the property of their respective companies

ASKING FOR ASSISTANCE

CONTENTS

1 Introduction

2 Operation Notes

3 Features

4 Sender Panel Descriptions

5 Receiver Panel Descriptions

6 Connecting And Operating The HDMI Cat-5 MS Extreme

7 Manual Equalization

8 Network Cable Wiring Diagram

9 Mounting Plate Installation

10 Terminology

11 Speciﬁcations

12 Warranty

Congratulations on your purchase of the HDMI CAT-5 MS Extreme. Your com-

plete satisfaction is very important to us.

Gefen

Gefen delivers innovative, progressive computer and electronics add-on solutions

that harness integration, extension, distribution and conversion technologies.

Gefen’s reliable, plug-and-play products supplement cross-platform computer

systems, professional audio/video environments and HDTV systems of all sizes

with hard-working solutions that are easy to implement and simple to operate.

The Gefen HDMI CAT-5 MS Extreme

The HDMI CAT-5 MS Extreme Extender extends your HDTV display up to 300

feet away from your HDTV source using two CAT-5 cables. It is equipped with

HDMI (high deﬁnition multimedia interface) connectors and is capable of sup-

porting DVI (digital visual interface) equipment when used with a HDMI to DVI

Adapter, providing greater ﬂexibility and options when integrating several home

theater components.

How It Works

The HDMI CAT-5 Extreme-S sender unit sits next to your computer, set-top box

or DVD player source. Cables supplied with the HDMI CAT-5 MS Extreme con-

nect your DVI or HDMI source to the send unit. The HDMI CAT-5 Extreme-R re-

ceive unit sits next to your HDTV display - up to 300 feet away. The display plugs

into the back of the HDMI CAT-5 MS Extreme-R receiver unit. Two CAT-5 cables

connect the sender and the receiver units to each other.

INTRODUCTION

READ THESE NOTES BEFORE INSTALLING OR

OPERATING THE HDMI CAT-5 MS EXTREME

The HDMI CAT-5 MS Extreme units are housed in a metal box for better RF• shielding.

Your CAT-5 cable should not exceed 300 feet.•

If you do not need DDC or HDCP data you can use a single CAT-5 cable for the• video only. The DDC will not be connected. (For further information, see our

Terminology section on page 9.) If HDCP is required, both CAT-5 cables must

be used between the sender and receiver units.

If the source requires EDID present, you can use the Gefen HDMI Detective to• provide EDID information to your source but will not transmit HDCP.

Shielded CAT6 with metal RJ-45 connectors is recommended to protect from• random ﬂashes caused by EMI.

Power supply for the receiver should not be connected unless you are using• one CAT5 or going over a distance of 200ft.

Extensions over 130ft. require you to manually EQ your signal (see page 4).•

Extensions under 130ft. use Auto EQ (which is on by default) (see page 4).•

The extender is factory set to Auto EQ which will work for distances under 130• ft.

OPERATION NOTES

Features

Extends high deﬁnition displays up to 150 feet from the source at 1080p•

Extends high deﬁnition displays up to 300 feet from the source at 1080i•

Improved compensation for cable skew•

Eliminates equipment noise in the viewing environment•

Supports resolutions up to 1080p, 2K, and 1920 x 1200•

Audio and video are transmitted digitally over the CAT-5e cable for zero• signal loss

HDMI compliant•

HDCP compliant•

Package Includes

(1) HDMI CAT-5 MS Extreme Sender

(1) HDMI CAT-5 MS Extreme Receiver

(1) 6 foot HDMI cable (M-M)

(2) 5V DC Power Supply

(1) User Manual

FEATURES

Front Panel

Back Panel

RJ-45 Input

Video RJ-45 Input

DDC

HDMI Input

5V DC Power Supply

Input

Power LED

Indicator

SENDER PANEL DESCRIPTIONS

Front Panel

Back Panel

RJ-45 Input

Video

RJ-45 Input

DDC

HDMI Output 5V DC Power

Supply Input

Power LED

Indicator

EQ Trim Pot

RECEIVER PANEL DESCRIPTIONS

AUTO EQUALIZATION

Connect the HDMI source to the1. HDMI CAT-5 MS Extreme sending unit’s

HDMI input port using the supplied HDMI cable.

Connect the HDMI CAT-5 MS Extreme sending and receiving units together2. using two user supplied CAT-5, CAT-5e or CAT-6 cables.

NOTE: If ﬁeld terminating network cable, please adhere to the TIA/EIA568B

speciﬁcation. Please see page 7 for more information.

Connect the display to the HDMI output port of the HDMI CAT-5 MS Extreme3. receiving unit using a user supplied HDMI cable.

Plug the 5V DC power supply into the4. HDMI CAT-5 MS Extreme sending

unit.

NOTE: In most scenarios, the 5V DC external power supply for the receiving

unit will not be required. Operational power is supplied by the sending unit via

the connected CAT-5, CAT-5e or CAT6 cable. If the power LED indicator on the

receiving unit is not on, please check to make sure that the RJ-45 cables are not

crossed (DDC to video and video to DDC).

Power on the display.5.

Power on the source.6.

The HDMI CAT-5 MS Extreme has built-in auto equalization that will

automatically tune out any unwanted video noise. This feature is reliable with

premium cable runs up to a maximum of 130 feet. It may be necessary to disable

this feature if there is either no video being displayed on initial start-up, there is

video noise in the image, or the cable run exceeds 130 feet. First, verify that all

the proper connections have been made and that all devices are powered on

before attempting to disable auto equalization.

CONNECTINGAND OPERATING THE HDMI CAT-5 MS EXTREME

MANUAL EQUALIZATION

The sender and receiver units both have sets of dip switches located on the

underside of their casings. There is a piece of silver metallic tape that must

be removed to expose these dip switches. Each unit carries a bank of 4 dip

switches. Dip switches 1 and 2 on both the sending and receiving units are used

in this procedure. Dip switches 3 and 4 are not used. By default, all dip switches

on the sending and receiving units should be in the OFF position (Auto EQ On).

To turn off auto equalization, turn dip switch 1 on the receiving unit to the ON

position (Auto EQ off). With this setting please follow the steps below to equalize

the picture.

Insert a small ﬂat head tool into the trim pot on the receiver unit.1.

Turn the trim pot in a clockwise fashion until it comes to a stop. Do not force2. the trim pot beyond this point. Doing so may break the trim pot.

Slowly turn the trim pot counter-clockwise in millimeter increments until the3. image stabilizes and all video noise disappears.

Carefully remove the adjustment tool.4.

NOTE: If your cable run is beyond 130 feet, or the following steps do not produce

any video, it may be necessary to increase the boost from the sending unit. Use

the chart below to increase the boost by changing the sender dip switches. Once

a new boost setting is set, repeat steps 1 through 4 from above.

Sender Dip Switch Settings

Setting Switch 1 Switch 2

No Boost (Default) OFF ON

Medium Boost OFF OFF

High Boost ON OFF

Not Used ON ON

Receiver Dip Switch Settings

Setting Switch 1 Switch 2

Manual EQ ON OFF

Auto EQ (Default) OFF OFF

Adjustment Guidelines:

Strong boost should not be used on stranded cables. Strong boosting will1. cause pixels or no picture on these cables.

Using the wrong settings will not damage the units; it will either produce no2. image or a noisy image.

To eliminate the possibility of cross talk and interference, cables must be3. terminated with 568B scheduling. (See page 6 for details)

No Boost should be set when using Auto EQ.4.
