Gefen EXT-HDKVM-ELR Manuel utilisateur

Release A7

EXT-HDKVM-ELR

User Manual

HD KVM

Extra Long Range Extender

Over One CAT5

*Preferred

Gefen warrants the equipment it manufactures to be free from defects in material and

workmanship.

If equipment fails because of such defects and Gefen is notied within two (2) years from

the date of shipment, Gefen will, at its option, repair or replace the equipment, provided

that the equipment has not been subjected to mechanical, electrical, or other abuse or

modications. Equipment that fails under conditions other than those covered will be

repaired at the current price of parts and labor in effect at the time of repair. Such repairs

are warranted for ninety (90) days from the day of reshipment to the Buyer.

This warranty is in lieu of all other warranties expressed or implied, including without

limitation, any implied warranty or merchantability or tness for any particular purpose, all of

which are expressly disclaimed.

1. Proof of sale may be required in order to claim warranty.

2. Customers outside the US are responsible for shipping charges to and from Gefen.

3. Copper cables are limited to a 30 day warranty and cables must be in their original

condition.

The information in this manual has been carefully checked and is believed to be accurate.

However, Gefen assumes no responsibility for any inaccuracies that may be contained

in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or

consequential damages resulting from any defect or omission in this manual, even if

advised of the possibility of such damages. The technical information contained herein

regarding the features and specications is subject to change without notice.

Warranty Information

• Shielded CAT-5e (or better) cables should not exceed 330 feet (100 meters) between

the Sender and Receiver unit.

• By default, the source device will use the EDID from the display (or other sink device)

which is connected the Receiver unit. See EDID Management (page 8) for more

information.

• If terminating network cables in the eld, please adhere to the TIA/EIA568B

specication. See the Network Cable Diagram (page 12)for details.

Operating Notes

Features and Packing List

Features

• Extends 4K Ultra HD (3840 x 2160 @ 60Hz, 4:2:0 or 30Hz, 4:4:4), and USB over

a single CAT-5e cable up to 330 feet/100 meters (8-bit color)

• Extends 4K Cinema (DCI) (4096 x 2160 @ 24 or 30Hz 4:4:4), and USB over

a single CAT-5e cable up to 330 feet/100 meters (8-bit color)

• Extends HDMI at 1080p Full HD, and USB over a single CAT-5e cable up to

330 feet/100 meters (up to 12-bit Deep Color)

• Supported HDMI features:

►HDMI 2.0

►HDCP 1.4 compliant

►12-bit Deep Color

► LPCM 7.1 audio, Dolby® TrueHD, Dolby Digital® Plus, and DTS-HD® Master

Audio™ pass-through

►3DTV pass-through

► CEC pass-through

► Lip Sync pass-through

• Supports up to 30 Mbps when using USB 2.0

• Backward-compatible with USB 1.1

• EDID management for rapid integration of source and display devices

• ELR and HDBaseT® technologies

• Locking power supplies

• 1U tall, half-rack width enclosures are rack-mountable using EXT-RACK-1U

™

1080P

60Hz, 4:2:0

HDCP

CINEMA

DCI, 4096 x 2160, 30Hz

CINEMA

DCI, 4096 x 2160, 30Hz

Packing List

The HD KVM Extra Long Range Extender Over One CAT5 ships with the items listed

below. The packing contents of the Sender and Receiver unit are listed below. If any of

these items are not present in the box when you rst open it, immediately contact your

dealer or Gefen.

• 1 x HDKVM ELR Extender over One CAT5 - Sender unit

• 1 x HDKVM ELR Extender over One CAT5 - Receiver unit

• 1 x 6 ft. HDMI cable, locking (M-M)

• 1 x 6 ft. USB Cable (A-B)

• 2 x 5V DC Locking Power Supplies

• 2 x AC Power Cord

• 1 x Quick-Start Guide

Features and Packing List

HD KVM

Extra Long Range Extender

Over One CAT5

Getting Started

Page Title

Sender Unit

ID Name Description

1 Power This LED glows solid blue when the unit is

connected to an AC outlet and the unit is

powered ON.

2 Link This LED glows solid blue when the Sender

unit and Receiver unit are connected and

passing video.

3USB This LED indicator glows solid blue when a

USB source is connected to the Sender unit.

4 Video This LED indicator ashes blue when a video

source is connected to the Sender unit.

VideoLink

USB

Power

HD KVM ELR Extender over one CAT-5 S

EXT-HDKVM-ELRS

Service

Link HDMI In USB 5V DC

Introduction

Getting Started

1 3

2 4

Page Title

ID Name Description

1 Link Connects the Sender unit to the Receiver

unit using shielded CAT-5e (or better) cable.

2Service Mini-USB port for factory use only.

3 HDMI In Connect the included HDMI cable from this

connector to the HD source.

4USB Connect the included USB cable from the

computer to this USB port.

5 5V DC Connect the included 5V DC locking power

supply to this power receptacle.

VideoLink

USB

Power

HD KVM ELR Extender over one CAT-5 S

EXT-HDKVM-ELRS

Service

Link HDMI In USB 5V DC

Introduction

Getting Started

43 51 2

Introduction

Getting Started

Receiver Unit

ID Name Description

1 Power This LED glows solid blue when the unit is

connected to an AC outlet and the unit is

powered ON.

2 Link This LED glows solid blue when the Sender

unit and Receiver unit are connected and

passing video.

3USB This LED indicator glows solid blue when

a USB device is connected to the Receiver

unit.

4 Video This LED indicator ashes blue when a

display is connected to the Receiver unit.

Link Video

USB

Power

HD KVM ELR Extender over one CAT-5 R

2 E

1 2

ON TD402

EXT-HDKVM-ELRR

Service

Link HDMI Out USB 5V DC

1 3

2 4

ID Name Description

1 Link Connects the Receiver unit to the Sender

unit using shielded CAT-5e (or better) cable.

2 HDMI Out Connect an HDMI cable from this connector

to the display.

3Service Mini-USB port for factory use only.

4USB Use these ports to connect up to three USB

devices.

5 5V DC Connect the included 5V DC locking power

supply to this power receptacle.

Link Video

USB

Power

HD KVM ELR Extender over one CAT-5 R

2 E

1 2

ON TD402

EXT-HDKVM-ELRR

Service

Link HDMI Out USB 5V DC

Introduction

Getting Started

432 51
