Geemarc AMPLICALL 110 Manuel utilisateur
0
Wireless Telephone Signaler
Alerteur d’appel Téléphonique
Drahtloser Telefonsignalgeber
English P2
FrançaisP9
Deutsch P16
1
2
Please refer to our website: www.geemarc.com for an up to date
user guide, as there may be important updates and changes you need to be
aware of.
Box Contents
The AC110 (AMPLICALLTM110) box contains the following items:
1 user’s manual
1 AC110 (AMPLICALLTM110)
1 RJ11/RJ11 cable
2 screws and 2 anchors
2 x AA,1.5V Alkaline batteries
1 Drill hole template
DESCRIPTION
On/Off slide button
Volume
EXT. jack socket
Bell button
Telephone
Line
5V DC Connector
Battery compartment for two
1.5V Alkaline batteries
Battery cover
RJ11/RJ11 Telephone cord
3
BATTERIES INSTALLATION
Your AMPLICALLTM110 works with two Alkaline AA 1.5V batteries
(not provided).
Please follow the below procedure to insert the batteries.
1.Unscrew the screw on the battery cover.
2.Open the battery cover.
3.Insert the 2 AA batteries into the compartment.
4.Close the battery cover and fix it using the screw.
Low Battery
If your device is running low on battery or if no battery has been
inserted, your AMPLICALLTM110 will send a signal to the receiver
which will make the zone icon light up.
4
Connecting your AC110 to the mains (Optional)
Even if your AMPLICALLTM110 is plugged
into the mains, you must insert batteries,
otherwise your device will send a low battery
signal to your receiver.
Those batteries will however only work as
backup batteries in the event of a power
failure.
Connect the type C USB power cable to
the DC input connector.
Pairing your AC110 with the AMPLICALL receivers
The AC110 can work on its own, it will amplify the ringer and will flash
when you receive a call. You also have the possibility to register your
AMPLICALLTM110 with the AMPLICALL receivers. If paired, the
receivers will receive the information from the AMPLICALLTM110 and
ring and flash as well.
Enter pairing mode for the AMPLICALL receivers.
1.Press & hold the LEARNING button (●) for 3 seconds. The LED in
zone icon #1 will flash
2.Press the LEARNING button (●) again to move to the zone icon
you wish to pair the AC110 with.
Press the melody selection () button to scroll through the
melodies. Once you hear a melody you like, do not press any
button during the melody.
3.Press once the bell button of the AC110 to pair.
4.If successful, the AMPLICALL receivers will generate two short
tones.
5
Connecting your AC110 to a phone socket
1.Connect one end of the supplied RJ11 cord to your phone socket
and the other to the “Tel” input connector on your AC110
2.Connect one end of your original phone cord to the “Line” input
connector on your AC110 and the other to your wall outlet.
Wall mounting
The AC110 can either be placed on a flat surface or be mounted on
a wall.
Mark two holes on the wall using a pencil and drill hole template.
Mount the unit to the wall using the provided anchors and screws.
6
Charging the settings of your AC110
On ( ) / Off ( ) slide button: Slide to the Off () position when
no receiver is used.
Volume ( ): You can adjust the volume of the ringer by sliding this
button, you can switch between the H(high), L(low), and
X
(silent)
position.
Connecting an External Sensor to your AC110
The AC110 is compatible with external devices such as fall mats
and other types of sensors which can be connected to the AC110
using the “EXT” jack socket. Once connected, the device will send
a signal to the receiver every time it is triggered.
On/Off slide button
Volume
7
GUARANTEE
From the moment your Geemarc AMPLICALLTM110 is purchased,
Geemarc guarantee is for the period of two years. During this time,
all repairs or replacements (at our discretion) are free of charge.
Should you experience a problem then contact our help line or visit
our website at www.geemarc.com. The guarantee does not cover
accidents, negligence or breakages to any parts. The product must
not be tampered with or taken apart by anyone who is not an authorized
Geemarc representative. The Geemarc guarantee in no way limits
your legal rights.
IMPORTANT : YOUR RECEIPT IS PART OF YOUR GUARANTEE
AND MUST BE RETAINED AND PRODUCED IN THE EVENT OF
A WARRANTY CLAIM.
Please note: The guarantee applies to the United Kingdom only.
DECLARATIONS:
UKCA Directives
Geemarc Telecom SA hereby declares that this AMPLICALLTM110 is
in compliance with the essential requirements and other relevant
provisions of the Radio Equipment Directive 2014/53/UE.
The UKCA declaration of conformity may be consulted at
www.geemarc.com
RF power : < 250mW
Recycling Directives
The WEEE (Waste Electrical and Electronic Equipment) has been
put in place for the products at the end of their useful life are recycled
in the best way.
When this product is finished with, please do not put it in your domestic
waste bin. Please use one of the following disposal options:
- Remove the batteries and deposit them in an appropriate WEEE
skip. Deposit the product in an appropriate WEEE skip.
- Or, hand the old product to the retailer. If you purchase a new one,
they should accept it. Thus if you respect these instructions you
ensure human health and environmental protection.
8
For product support and help visit our website at
www.geemarc.com
telephone 01707 387602
lines are open 09h00 to 16h00 Mon to Fri
2 Rue Galilée, Parc de l’Etoile, 59791 Grande-Synthe, France
This product is made in China To Geemarc Telecom
9
Veuillez consulter notre site Web: www.geemarc.com car il peut y
avoir des mises à jour importantes et changement dont vous devez être
conscient.
Contenu de la boite
La boite de l’AC110 contient les éléments suivants:
1 guide d’utilisation
1 AC110 (AMPLICALLTM110)
1 câble 1 RJ11/RJ11
2 vis et 2 chevilles
2 piles Alcalines AA, 1,5 V
1 gabarit de perçage
DESCRIPTION
Bouton coulissant Marche/Arrêt
Volume
Prise jack EXT
Bouton de sonnerie
Téléphonique
Ligne
Connecteur CC 5V
Compartiment pour deux piles
alcalines AA de 1,5 V
Couvercle du compartiment des
piles
Cordon téléphonique RJ11/RJ11
