GE Profile PT916BM Manuel

Listed by

Underwriters

Laboratories

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Specification Revised 10/07

220241

PT916BM/CM/WM

GE Profile™30" Built-In Single Convection Wall Oven

KW Rating

240V 4.5

208V 3.4

Breaker Size

240V 20 Amps

208V 20 Amps

Dimensions and Installation Information (in inches)

Most 30” Wall Cabinets can be used with this unit.

Note: These ovens are not approved for

stackable installations. Cabinets installed

adjacent to wall ovens must have an adhesion

spec of at least a 194°F temperature rating.

Door handle protrudes 3" from door face. Cabinets

and drawers on adjacent 45° and 90° walls should

be placed to avoid interference with the handle.

Electric wall ovens are not approved for

installation with a plug and receptacle. They

must be hard wired in accordance with

installation instructions.

Installation Information: Before installing, consult

installation instructions packed with product for

current dimensional data.

Side-by-side installations rerquire at least 2"

between cutouts.

L2 x 4 or

equivalent

runners

Suitable

bracing

to support

runners

21-5/8"

over centerline

of cabinet

(must support 275 lbs.)

Cutout width

28-1/2'' MIN.

28-5/8'' MAX.

29-3/4

Recommended

cutout location

32-1/2"

from floor

Junction

box

location

Allow minimum of 21'' for clearance

to adjacent corners, drawers, walls, or etc.

A=Allow 1" overlap of oven over top and bottom edges of cutout.

B=Allow 11/16"-3/4" for overlap of oven over side edges of cutout.

C=28-1/4" without trim and 28-3/4" with trim.

Conduit

(72"

long)

27-1/4'' MIN.

27-5/16'' MAX.

Cutout height

23-1/2'' MIN.

Cutout depth

22'' MIN.

L2 x 4 or

equivalent

runners

Suitable

bracing

to support

runners

21-5/8"

over centerline

of cabinet

(must support 275 lbs.)

Cutout width

28-1/2'' MIN.

28-5/8'' MAX.

29-3/4

Recommended

cutout location

32-1/2"

from floor

Junction

box

location

Allow minimum of 21'' for clearance

to adjacent corners, drawers, walls, or etc.

A=Allow 1" overlap of oven over top and bottom edges of cutout.

B=Allow 11/16"-3/4" for overlap of oven over side edges of cutout.

C=28-1/4" without trim and 28-3/4" with trim.

Conduit

(72"

long)

27-1/4'' MIN.

27-5/16'' MAX.

Cutout height

23-1/2'' MIN.

Cutout depth

22'' MIN.

Optional Undercounter Dimensions and Installation Information

Dimension and installation information are shown in inches.

Listed by

Underwriters

Laboratories

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Specification Revised 10/07

220241

PT916BM/CM/WM

GE Profile™30" Built-In Single Convection Wall Oven

Note: 36” ribbon cooktop are approved for use

over GE 30” single wall ovens only. 30” ribbon

cooktops are approved for use over GE 30” and

GE 27” single wall ovens. Refer to cooktop and

wall oven installation information packed with

products for current dimensional data.

Note: CleanDesign or Sealed Burner Gas

This installation is to achieve minimum gap

between bottom of countertop and control

panel. For this installation, the bottom trim will

not be flush with a typical 4” toe kick

Note: Cabinets installed adjacent to wall ovens

must have an adhesion spec of at least a 194°F

temperature rating.

Installation Information: Before installing,

consult installation instructions packed with

product for current dimensional data.

Power cord

for cooktop

Junction box

for oven

Junction box in

adjacent cabinet

for cooktop

hook-up

2 (two) 90°elbows &

sufficient pipe to

connect in adjacent

cabinet

Right cabinet side

3/4" Support

Shut-off

valve

Pressure

regulator

1/2" Black

iron pipe

Union

Conduit

(72" long)

30" built-in

oven

3-1/2" MIN.

Free space

4" To 4-1/2"

3-1/4

Side View

5-9/16"

Reference dim.

for MAX. support

height with typical

36" countertop

height

36" Typical

Countertop height

Power cord

Reference

5-9/16

30-7/16

Free space

1-1/2" MIN.

1-1/2" Typical countertop

Side View

27-5/16" MAX.

Cutout height

27-1/4" MIN.

Junction box(s) for

oven & radiant

cooktop 22" from

floor

Add suitable

filler to match

adjacent cabinets

when needed

to maintain toe

kick alignment

30" Oven W/ Rad. Cktp.

Gas or electric cooktops may be installed

over this oven. See cooktop installation

instructions for cutout size. See label on

top of oven for approved cooktop models.

Gas (including the pressure regulator) and

electrical connections for gas cooktop must

be located in an adjacent accessible location.

For a 30" gas cooktop, the connections are

more conveniently made to the right.

120 Volt

Outlet

Gas

connection

Junction box

location

240/208V

36'' MIN.

4'' To 4-1/2 '' Toe kick allowable

Match toe kick height

front and two sides

22'' MIN. above

support platform

Top and/or side

fillers may be

necessary if unit

is positioned

between

existing cabinets

28-1/2'' MIN.

28-5/8'' MAX.

3/4'' Support

platform required

23-1/2" MIN.

Cutout depth

Allow 11/16''

overlap over side

edges of cutout

1-1/2"

Countertop

27-1/4'' MIN.

27-5/16'' MAX.

Cutout height

With 36" Gas Cooktop With 30" CleanDesign or Sealed Burner Gas Cooktop

Specification Revised 10/07

220241

PT916BM/CM/WM

GE Profile™30" Built-In Single Convection Wall Oven

Features and Benefits

• Glass Touch Controls - Features a smooth glass design that is easy-to-

operate and easy-to-clean

• Precise Air™Convection System - Provides even air and heat circulation

for superior baking and roasting results

• Flat Back Convection - Features a more streamline convection fan that

better accommodates baking or roasting pans

• Convection Bake - Delivers ideal airflow throughout the oven cavity,

ensuring better baking results

• Convection Roast - Delivers even cooking and consistent results, roasting

meats up to 25% faster than a conventional oven

• Hidden Bake Oven Interior - Hides previously exposed bottom element to

deliver a clean interior appearance

• Self Clean Oven - Conveniently cleans the oven cavity without need

of scrubbing

• Improved Lighting - Positions lamps diagonally across the top of the oven

to promote better viewing

• Self-Clean Heavy-Duty Oven Racks - Double coated porcelain-enameled

racks no longer require hand cleaning

• Extra-Large Oven Capacity - Provides a large oven interior ideal for

cooking more items at once

• Model PT916BMBB – Black on black

• Model PT916CMCC – Bisque on bisque

• Model PT916WMWW – White on white

PT916WM/CM/BM
