THE “OPERATOR”

INTRODUCTION 3
ACCESSING YOUR SYSTEM 3
FUNCTIONS OF THE "OPERATOR" 4
SECTION I. CHECKING SYSTEM STATUS 4
SECTION II. USING THE MENU 5
SECTION III. ARMING YOUR SECURITY SYSTEM 6
SECTION IV. USING THE INSTANT / DELAY OPTION 6
SECTION V. DISARMING YOUR SECURITY SYSTEM 7
SECTION VI. BYPASSING ZONES 7
SECTION VII. ACCESSING ZONE STATUS 8
SECTION VIII. ACCESSING THE HOME CONTROL MENU 9
SECTION IX. ACCESSING DATE/TIME MENU 11
SECTION X. ACCESSING ALARM MEMORY 12
PROGRAMMING/CHANGING ACCESS CODES 13
ACTIVATING EMERGENCY ALARMS 14
THINGS TO KNOW ABOUT THE "OPERATOR" 14
QUICK REFERENCE BACK


INTRODUCTION

The “Operator” is an interactive phone module for Caddx security

controls that interconnects your telephone with your security system. It

allows authorized users to operate the security system from any

TouchTone telephone, whether it is at the protected site or anywhere

else in the world. This manual is furnished to help you understand how

the “Operator” works in conjunction with your security system. You

should first make sure that you fully understand the operation of your

security system as described in the supplied manual before attempting

to use the “Operator”. The “Operator” is Y2K compliant.

ΝIMPORTANT NOTE: Throughout this manual, phrases and messages

will appear in BOLD ITALICS CAPITAL LETTERS. These phrases are

the actual words as stated by the “Operator”.

ACCESSING YOUR SYSTEM

From a protected site, you can access your security system

“Operator” from any of your TouchTone telephones.

Step 1 Pick up the receiver.

Step 2 Within 8 seconds of hearing a dial tone, press the star key

three times. The “Operator” will come on the line.

ρρρ

Step 3 The “Operator” will tell you the System Status including any

warnings, along with the various MENU choices.

From an off-site premise, you can also access the “Operator” using a

TouchTone telephone.

Step 1 Call the phone number of the protected site.

Step 2 When the phone is answered, press the pound key three

times within the first 8 seconds.

# # #

If a person or a device such as a fax/answering machine

answers the call, the “Operator” will come on the line when

the answering machine or person hangs up. Otherwise, the

“Operator” will automatically answer the call after a pre-

designated number of rings occur.

The “Operator” will prompt for a valid user code: “PLEASE

ENTER YOUR CODE”.

Step 3 Enter your code. When it recognizes the valid user code, the

“Operator” will tell you the System Status including any

warnings, along with the various MENU choices.

FUNCTIONS OF THE “OPERATOR”

The “OPERATOR” has a wide variety of functions available to use in

controlling your security system by means of a TouchTone telephone.

Section I. CHECKING SYSTEM STATUS

System status is the first information you will hear when the “Operator”

comes on the line. This will inform you of the present status of your

security system. The messages given for System Status are as follows:

# "SYSTEM IS ARMED, ENTER CODE TO DISARM" - Enter your

code to DISARM.

# "SYSTEM IS READY, ENTER CODE TO ARM" - Enter your code

to ARM your system.

# “SYSTEM IS ARMED IN STAY MODE” – Your system is armed

in the STAY mode and provides exit delays.

# "SYSTEM NOT READY, PLEASE SECURE" – One or more zones

are not secure. Check zone status.

# "TO ACCESS MENU, ENTER [

]" - This takes you to the MENU

for the other options.

# "ZONE BYPASS ACTIVE" - One or more zones are bypassed.

Check zone status.

# “SYSTEM TROUBLE, ENTER [

] [2]” – This will identify the

service condition. Consult your security system’s user manual for

more information or call your installer.

# "POWER FAILURE"- Your system has lost electrical power.

# "LOW BATTERY" - Your backup battery has failed a system

battery test.

# "PHONE LINE TROUBLE" - Your system has detected a problem

with the phone line.

# "SYSTEM IS ARMED IN THE STAY MODE. ENTER CODE TO

DISARM. EXIT DOOR DELAY IS OFF."- Your system is

armed in the INSTANT Mode. Refer to page 6for details.

# "WHEN FINISHED, HANG UP" - Disconnect from the

“Operator” by hanging up.

Section II. USING THE MENU

When the “Operator” is on the line, the System Status will be stated. To

access the MENU for the various features of your system, press ρ.

The messages listed below are presented. Press the appropriate

number for the desired MENU selection.

# "FOR ZONE STATUS, ENTER [0]" - For checking open/faulted

zones. Refer to page 8.

# "TO CHANGE AREA, ENTER [1]" - For changing the area.

# “FOR SYSTEM STATUS, ENTER [2]” – For checking

armed/disarmed status of system. Refer to page 4.

# "FOR ALARM MEMORY, ENTER [3]" - For checking Alarm

Memory. Refer to page 12.

# "TO TEST SIREN, ENTER [4]" - For testing the siren.

# "TO CHANGE CODE, ENTER [5]" – To change a user code. This

option available in disarmed state only. Refer to page 13.

# “FOR HOME CONTROL MENU, ENTER [6]” – To access menu

for lights and thermostat control. Refer to page 9.

# “TO RESET SMOKE DETECTOR, ENTER [7]” – To reset

detectors.

# “TO PROGRAM SYSTEM, ENTER [8]” – Accesses program

mode.

# “FOR MORE OPTIONS, ENTER [9]” – Options include a zone

list, and features to set system date and time. Refer to page 11.

Section III. ARMING YOUR SECURITY SYSTEM

When the “Operator” is on the line to a system that is in the DISARMED

state, the System Status will be stated as, "SYSTEM IS READY.

ENTER CODE TO ARM". If there are any bypassed zones, "ZONE

BYPASS ACTIVE" will be stated. Since your security system will ignore

bypassed zones, you may want to check Zone Bypass Status before

ARMING your system (see BYPASSING ZONES THROUGH THE

OPERATOR). If you choose to ARM your system at this point, enter an

authorized 4-digit user code and the “Operator” will say "SYSTEM IS

ARMED, ENTER CODE TO DISARM". Your security system is now in

the ARMED state. You may hang up or go to another MENU option.

Section IV. USING THE INSTANT / DELAY OPTION

(Refer to your security system user's manual to see if your system has

been programmed for the "INSTANT" option. Read and familiarize

yourself with this option.)

While your system is in the ARMED state you may activate the

"INSTANT" option through the “Operator” as follows:

Step 1 Press ρ3 .

The [ρ] accesses the MENU and [3] is the STAY mode.

Step 2 “SYSTEM IS ARMED IN STAY MODE. ENTER CODE

TO DISARM.” Your system is now armed in the STAY

mode with exit delay.

Step 3 At this point, you may enter your code to disarm.

Or to change the armed status to INSTANT, press ρ3

again.

Step 4 “SYSTEM IS ARMED IN STAY MODE. ENTER CODE

TO DISARM. EXIT DOOR DELAY IS OFF.” Your

system is now armed in the INSTANT mode with no exit

delay.

Step 5 To toggle from the INSTANT mode to the STAY mode and

vice versa, simply press ρ3 .

Step 6 To exit, press the #key.

Section V. DISARMING YOUR SECURITY SYSTEM

When the “Operator” is on the line to a system is in the ARMED state,

the System Status will be stated as "SYSTEM IS ARMED, ENTER

CODE TO DISARM". To DISARM your system at this point, enter an

authorized 4-digit user code and the “Operator” will say "SYSTEM

READY, ENTER CODE TO ARM". Your security system is now

DISARMED. You may hang up or go to another MENU option.

Section VI. BYPASSING ZONES

Your security system must be DISARMED to perform the bypass

procedure. When you disarm your system, all bypassed zones will

automatically unbypass. Since your system’s arming procedure ignores

bypassed zones, these instructions should only be given to authorized

persons.

When the “Operator” is on the line, perform the following steps to

bypass or unbypass any of the zones in your security system.

Step 1 Press ρ9 0 .

The [ρ] accesses the main MENU, [9] gives the OPTIONS

menu, and [0] provides the ZONE LIST.

Step 2 The “Operator” will state the condition of each individual

zone with one of the following messages:

 “ZONE 1 IS SECURE. TO BYPASS ENTER [0] NOW.”

 “ZONE 2 IS BYPASSED.”

Step 3 You may toggle (reverse) the bypass condition of a

particular zone. After that zone number is stated, press

Step 4 The “Operator” will say "PLEASE WAIT" before

repeating the status of that zone, and continue scrolling

through the remaining zones.

Step 5 Press a zone number followed by #to proceed directly

to that zone number.

For example, to go to zone 9 you would press 9#.

Step 6 Press #to exit the Zone Bypass section of the MENU.

Section VII. ACCESSING ZONE STATUS

When the “Operator” is on the line, the Zone Status option of the MENU

can be reached by performing the following steps:

Step 1 Press ρ0 .

The star [ρ] key accesses the main MENU and the zero

[0] accesses the Zone Status information.

Step 2 The “Operator” will state the name(s) of any zone(s) and

their conditions with one of the following messages:

# "ZONE 1 IS OPEN. TO BYPASS, ENTER [ρ] NOW"

# "ZONE 1 IS BYPASSED"

# "FIRE, ZONE 1"

# "FIRE TROUBLE, ZONE 1"

# "TAMPER, ZONE 1"

Section VIII. ACCESSING THE HOME CONTROL MENU

The Home Control Menu section provides information concerning the

lights and temperature control provided through your security system.

HOME CONTROL – LIGHTS/APPLIANCES

When the “Operator” is on the line, perform the following steps to turn

lights/appliances on or off.

Step 1 Press ρ6 .

The [ρ] accesses the main MENU and [6] goes to the

HOME CONTROL menu.

Step 2  “TO TURN LIGHT OFF, ENTER [0].”

 “TO TURN LIGHT ON, ENTER [1].”

 “THERMOSTAT CONTROL, ENTER [2].” (For

instructions on this menu item, please refer to the steps

in the next segment.)

Step 3 Press zero 0 to turn lights on or off.

Step 4 The “Operator” will begin scrolling through each of the

thirty-two outputs with one of the following messages:

 "LIGHT 1, ENTER [0] TO TURN OFF"

 "LIGHT 2, ENTER [0] TO TURN ON.”

Step 5 As each is recited, you can enter zero 0to turn the

light on/off.

Pressing a Light number followed by the # key will take

you directly to that light. After the condition of a light has

changed, the “Operator” will state its condition before

scrolling through the remainder of lights.

Step 6 To exit, press #or hang up.

HOME CONTROL – THERMOSTAT CONTROL

When the “Operator” is on the line, perform the following steps to

change the thermostat control. The thermostat control has three

separate modes:

 Thermostat mode

 Fan mode  Day mode

(NOTE: The “Operator” will only function with a special type of

thermostat, which may not be currently available in your area.

Contact your installer.)

Step 1 Press ρ6 2 .

The [ρ] accesses the MENU and [6] takes you to the HOME

CONTROL menu, then [2] proceeds to the THERMOSTAT

CONTROL section.

Step 2  “INSIDE TEMPERATURE IS ZERO.”

 “OUTSIDE TEMPERATURE IS ZERO.”

 “THERMOSTAT MODE IS EMERGENCY. TO CHANGE,

ENTER [0].”

 “FAN MODE IS AUTO. FOR ON MODE, ENTER [1].”

 “DAY MODE IS ON. TO SELECT NIGHT MODE,

ENTER [2].”

 “DAY MODE HEAT SET POINT IS ZERO. TO CHANGE,

ENTER [3].”

 “NIGHT MODE HEAT SET POINT IS ZERO. TO

CHANGE, ENTER [4].”

 “DAY MODE COOL SET POINT IS ZERO. TO

CHANGE, ENTER [5].”

 “NIGHT MODE COOL SET POINT IS ZERO. TO

CHANGE ENTER [6].”

Step 3 When you have heard the status of the THERMOSTAT

mode, when you enter a number to change, the

“Operator” will ask you to “PLEASE WAIT.”

Autres manuels pour NetworX Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels GE Unité de contrôle

GE TLE Scalable 150 Manuel utilisateur

GE RX3i PROFINET Manuel utilisateur

GE Masoneilan VariPak 28001 Manuel utilisateur

GE 22158 Manuel utilisateur

GE C-400 Series Manuel utilisateur

GE IC3645SR4W746HL1 Manuel utilisateur

GE VersaMax IC200CHS006 Manuel utilisateur

GE PACSystems RX3i IC695ETM001-JW Manuel utilisateur

GE Tetra 24/24 Manuel utilisateur

GE IC3645SR4W746N5 Manuel utilisateur

GE IC3645SR4W606N6 Manuel du propriétaire

GE Baker Hughes Masoneilan 31000 Series Manuel utilisateur

GE VARIVENT S Series Manuel utilisateur

GE NetworX Series Manuel d'installation

GE EntelliGuard TU Manuel utilisateur

GE Ziton ZP3-ECU Manuel utilisateur

GE IC693CBL300 Manuel utilisateur

GE Masoneilan 469 Series Manuel utilisateur

GE NX-1710E - Single Door Control Module Manuel d'installation et d'exploitation

GE C-800 Series Manuel utilisateur

GE MM3 Manuel utilisateur

GE MiCOM P40 Agile Manuel utilisateur

GE GEH-5201 Manuel utilisateur

GE b30 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
