GarrettCom Hubs Manuel utilisateur

www GarrettCom com

Corporate Headquarters:

GarrettCom, Inc.

( a.k.a. Garrett Communications, Inc.)

213 Hammond Avenue

Fremont, CA 94539

Phone: 510.438.9071

Fax: 510.438.9072

Email support@garrettcom.com

Web: www.garrettcom.com

MagnumBlade

Compact PCI Hubs

10/100 Mbps & 100Mbps Hubs

User Manual

Magnum Blade 10/100Mbps cPCI Hubs User Manual (8/01)

www GarrettCom com

Magnum Blade

10/100Mbps cPCI Hubs

User Manual

Part #: 84-00085 (08/01) Rev.C

Trademarks

Ethernet is a trademark of Xerox Corporation

NEBS is a trademark of Telcordia Technologies

UL is a registered trademark of Underwriters Laboratories

GarrettCom, Magnum and Personal Switch are trademarks and Personal Hub is a

registered trademark of GarrettCom, Inc.

Important: Magnum Blade cPCI Hub contain no user serviceable parts.

Attempted service by unauthorized personnel shall render any and all

warranties null and void. If problems are experienced with a Magnum Blade

cPCI Hub, consult page 9, Troubleshooting, of this User Guide.

be reproduced without prior written permission from GarrettCom, Inc.

Printed in the United States of America.

Magnum Blade 10/100Mbps cPCI Hubs User Manual (8/01)

www GarrettCom com

Contacting GarrettCom, Inc.

To contact us the following information is provided below.

GarrettCom, Inc.

( a.k.a. Garrett Communications, Inc.)

213 Hammond Avenue

Fremont, CA 94539

Phone (510) 438-9071

Fax (510) 438-9072

Email: support@garrettcom.com

Web: www.garrettcom.com

Federal Communications Commission

Radio Frequency Interference Statement

This equipment generates, uses and can radiate frequency energy and if not

installed and used properly, that is in strict accordance with the manufacturer's

instructions, may cause interference to radio communication. It has been tested and

found to comply with the limits for a Class A computing device in accordance with the

specifications in Subpart J of Part 15 of FCC rules, which are designed to provide

reasonable protection against such interference when operated in a commercial

environment. Operation of this equipment in a residential area is likely to cause

interference, in which case the user at his own expense will be required to take whatever

measures may be required to correct the interference.

Ordering Information:

Magnum Blade

DS12 & DS12E 10/100Mbps cPCI Hubs

Magnum Blade DS12

12-port Dual speeds 10/100 Mbps cPCI Hub with 12 RJ-45 ports, each auto

sensing for 100Mbps operation. Occupies one 6U X 4HP slot, rear I/O, in a

cPCI chassis. Stand alone operation, uses no cPCI Backplane connectors.

Magnum Blade DS12E

Same as DS12 but the speed is fixed at 100Mbps, no auto-negotiation.

GarrettCom, Inc. reserves the right to change specifications, performance

characteristics and/or model offerings without notice.

Magnum Blade 10/100Mbps cPCI Hubs User Manual (8/01)

www GarrettCom com

TABLE OF CONTENTS

SECTION PAGE NUMBER

PRODUCT SPECIFICATIONS 4

INTRODUCTION 6

General Description

6 Features

Package Contents 7

HARDWARE INSTALLATION 8

Installation Procedure 8

Standalone Configuration 8

Multi-level Configurations, Cascading 8

TROUBLESHOOTING 9

WARRANTY 10

WARRANTY REGISTRATION CARD 11

Revisions

Rev C 08/01: Change the logo structure and date to the current GarrettCom,

Inc. manual standard. There are no changes to the content of the material at this

time.

Rev B 09/00 : Change the company name to GarrettCom, Inc. (Formerly it was

Garrett Communications). There are no changes to the content of the material at

this time

Rev A 6/00 : This revision is the initial release of the Magnum Blade cPCI Hub

user manual.

Magnum Blade 10/100Mbps cPCI Hubs User Manual (8/01)

www GarrettCom com

SPECIFICATIONS:

PERFORMANCE:

Data Rate:

10/ 100Mbps (DS12)

100Mbps (DS12E)

Partitioning:

Enforced after 32 consecutive collisions

Auto-reconnect:

Occurs after one packet of error-free transmission

DS12 & DS12E:

Class II Repeater

MTBF:

287,864 hrs. @40°C

204,969 hrs. @55°C

PDV (100Mbps Path Delay Value):

80BT

Processing type:

Store and Forward

Auto-learning:

2K addresses

Packet buffers:

512KB

Latency (not including packet time):

5 µs (10 to 100Mbps and 100 to 10Mbps)

NETWORK STANDARDS:

Ethernet V1.0/V2.0 IEEE 802.3: 10BASE-T,

IEEE 802.3u: 100BASE-TX

6U X 4HP Form Factor:

Note: The unit is stand-alone; it does not plug into any cPCI backplane

connectors

OPERATING ENVIRONMENT:

Ambient Temperature: 25°to 130°F ( -5°to 55°C)

Storage Temperature: -40°to 185°F (-40°to 85°C)

Ambient Relative Humidity: 5% to 95% (non-condensing)

NETWORK CABLE CONNECTORS:

All 12Ports are shielded RJ-45 female.

100Mbps: use Category 5 UTP/STP

10Mbps: use Category 3, 4, 5 UTP

SWITCHES, MANUAL:

MDI-X thumb operated slide up-link switch converts top-most port# 1 on hub from a

regular (= position) user segment port to a cross-over (X position) up-link port for on-off

connection to a central hub or switch, or another cascaded hub or switch.

Magnum Blade 10/100Mbps cPCI Hubs User Manual (8/01)

www GarrettCom com

POWER SUPPLY (EXTERNAL):

Power Input Voltage: 12VDC

Power Consumption: 6.5 Watts typical

Dimensions:

10.3in H x 0.8in W x 3.3in D(262mm x 20mm x 84mm)

Weight:

0.5lb. (0.25 kg)

LED INDICATORS, Unit:

PWR: Steady on when power applied.

COL: Common collision indicator, for the 100Mbps and 10Mbps

domain

LED INDICATORS PER RJ-45 PORT:

100: Steady on when speed is 100Mbps

LK/RK: Steady on when LINK is operational, flashing for receive

activity

Agency Approvals

UL listed (UL1950), cUL, CE

Emissions meet FCC Part 15 Class A

NEBS compliant, certifiable as part of a cPCI system

Warranty

Three years, return to factory Made in USA

Magnum Blade 10/100Mbps cPCI Hubs User Manual (8/01)

www GarrettCom com

INTRODUCTION

General Description

The Magnum Blade DS12 & DS12E compact cPCI Hubs are

designed to I/O slot for a simple solution to cPCI Ethernet system problems.

This eliminates the need for a hub in a separate box. The reliable Magnum

Blade hubs provide efficient slot utilization in a 6U X 4HP-cPCI form factor

with no cPCI Backplane connections used. They can be used in practically

any cPCI system, without design modifications.

The Magnum Blade DS12 Dual speed cPCI hub has 12 RJ-45 ports,

each 10/100Mbps auto-sensing. Each port can independently identify (via

802.3u auto sensing) and accept either 100Mbps or 10Mbps Ethernet

signals, adapting to match the best speed of the connected device. There are

two internal traffic domains in Magnum Blade hubs, one for the 100Mbps

traffic and one for the 10Mbps traffic. The 100Mbps users share the

100Mbps domain’s bandwidth and the 10Mbps users share the 10Mbps

domain’s bandwidth.

The Magnum Blade Model DS12E has 12 RJ-45 ports, fixed at

100Mbps speed. There is no auto-negotiation and no uncertainty about the

operating speed accordingly.

Magnum Blade Hubs have an up-link switch at port # 1, located on

the top-front to either connect to a user station or node (= position) or

alternatively to be cascaded to another hub or switch (X position).

The Magnum Blade Hubs are in compliance with the IEEE 802.3u

standards. The Magnum Blade Hubs are equipped with LEDs per port,

providing for convenient monitoring of network operation. PWR LEDs

indicates the power up of the unit and COL LEDs indicates the common

collision at 10Mbps and 100MB. LINK / RX and 100LEDs on each port

indicate each port is operational or receiving data, and is at 100Mbpsspeed

when lit. The PWR LED indicates the power is applied to the unit and the

COL LEDs indicates common collision at 10Mbps and 100MB respectively.

Magnum Blade DS12 Hub (Front Panel w/ LEDs)

agnum

BLADE

LK / RX

100

PWR COL

10/100 Mb

Magnum Blade 10/100Mbps cPCI Hubs User Manual (8/01)

www GarrettCom com

Features

•Twelve Ethernet hub ports on a 6U X 4HP Form-Factor cPCI

•Uses Rear I/O slot in cPCI chassis, keeping Ethernet cabling in the

rear area

•No cPCI backplane connections, “universal”, can be used in any

cPCI system

•High reliability, over 30 years calculated MTBF

•Low EMI noise, better than Class B emissions

•Carrier Class, NEBS compliant, has been NEBS certified in cPCI

systems

•One model for auto negotiating 10/100Mbps dual-speed ports, one

for 100-only.

•Up-link switch for cascading, port #

•Global Collision status LED, indicates collisions for all ports / speeds

on the hub

•Bridge between the two speed domains (Model DS12), has 2K node

addresses and 512KB packet buffers, enables all connected users at

both speeds to talk to each other

•Supports Category 5 (100Mb) and Category 3 (10 Mb) UTP / STP

twisted-pair cabling

•Class II Repeater, 80 BT PDV at 100Mbps

•Auto-partitioning of ports receiving excessive collisions, removes

network faults

•Complies with IEEE802.3u 10 Mb and 100MbEthernet specifications

•Package Contents:

•One twelve-port dual-speed 10/100 Mbps Hub (Model DS12), or

one Fast Ethernet 100Mbps-only Hub (Model DS12E)

•Short power cable with male power connector for insertion into the

power-input jack.

•User manual (includes warranty card)

•Two holding screws for mounting in a 6U X 4HP Rear I/O cPCI

chassis slot

Magnum Blade 10/100Mbps cPCI Hubs User Manual (8/01)

www GarrettCom com

HARDWARE INSTALLATION

Installation Procedure

1. Connect power wires to a 12VDC source, generally available inside the

Compact PCI box.

2. Insert the power plug to the power jack at the bottom inside position.

This applies power to the unit. (It is low voltage, 12VDC, safe to handle

when power is applied)

3. Carefully slide the DS12 hub into the Compact PCI I/0 slot and screw it

tightly through upper and lower screws (provided).

4. Connect a device to a RJ-45 hub port using twisted pair cabling. For

unshielded twisted pair, note that the distance between the hub and the

device cannot exceed 100 m, and that the longest UTP cable path

through a 100Mb collision domain (max. of two Class II cascaded hubs)

should not exceed 205 meters.

5. The LINK indicator will indicate if the connection is properly made, and if

there is power on the device on the other end so that the segment is

ready to operate.

6. Connect each applicable device in your network using the same process.

7. Use the up-link switch on Port # 1 to make a cascaded (X-position)

connection.

Note: To reliably operate your network at 100Mb/s, you must use Category

5 wiring. Category 3 or Category 4 wire may sometimes seem to work, but it

will normally cause data loss and unreliable operation.

Stand-alone Configuration

In a simple stand-alone configuration, the up-link switch is in the “=“ or

upward position, and port # 1 (on the DS12 and DS12E) is used to connect

to a user or other node.

Multi-level Configurations, Cascading

If you want to connect more than 12 ports together, use the up-link port to

connect to another hub or switch. This is called “cascading”. Simply

connect the up-link port (port # 1) to any port on another hub or switch,

with the up-link set to the crossover (X) position. Note that cascaded

configurations should be compliant with Fast Ethernet collision domain

specifications.

agnum

BLADE

100

PWR COL

UP-LINK Switch

for Cascading

Magnum Blade 10/100Mbps cPCI Hubs User Manual (8/01)

www GarrettCom com

TROUBLESHOOTING

This section contains information to help solve problems. If

either the Magnum Blade DS12 or DS12E cPCI hub is not functioning

properly, check that the hub was set up according to the instructions in

this manual.

If the DS12 or DS12E cPCI hub does not connect to the network,

•Check the Link / Activity LED lights on the ports. The Link LED on

each port in use should be ON, which indicates that the physical

wiring connection is made on both ends of the wire and that power

is ON for the devices at both ends.

If the Link / Activity LED light is not ON, check all connections at the

adapter or node, and at the hub.

•Try another port on the hub.

•Turn off the power of the hub, after a while re-power the hub.

•Make sure that the cable is installed properly.

The RJ-45 cable must be securely attached. If the problem persists, try

a different cable.

Other Important Tips

•Make sure the network adapter cards installed in the workstations

and cable connections are in good working condition. Also, make

sure adapter drivers are loaded.

•If you are using the up-link port, confirm that the up-link port is in

the correct position:

This up-link switch is “front” for the up-link setting; “back” for

regular (node) setting. The up-link switch enables cascading when

the switch is set to the crossover (X, or front) position. Alternately,

when the switch is set to the normal straight through (=, or back)

position, the port operates as a normal node-connection port.

Table des matières

Autres manuels GarrettCom Changer

GarrettCom

GarrettCom Magnum CS14 Series Manuel utilisateur

GarrettCom

GarrettCom Magnum 6KQ Manuel utilisateur

GarrettCom

GarrettCom P80C Manuel utilisateur

GarrettCom

GarrettCom Magnum 6K25e Manuel utilisateur

GarrettCom

GarrettCom Magnum 14E Manuel utilisateur

GarrettCom

GarrettCom Magnum Quad-Series Manuel utilisateur

GarrettCom

GarrettCom Ethernet Networks and Web Management Manuel utilisateur

GarrettCom

GarrettCom Hardened Ethernet Switches P62F Manuel utilisateur

GarrettCom

GarrettCom magnum 6kl Manuel utilisateur

GarrettCom

GarrettCom MAGNUM H80B Manuel utilisateur

GarrettCom

GarrettCom Magnum ST80 Stackable Manuel utilisateur

GarrettCom

GarrettCom Magnum 6KQE Manuel utilisateur

GarrettCom

GarrettCom Magnum 1016 Manuel utilisateur

GarrettCom

GarrettCom PS14H-48VDC Manuel utilisateur

GarrettCom

GarrettCom Magnum 10KG Manuel utilisateur

GarrettCom

GarrettCom Magnum 4K16 Manuel utilisateur

GarrettCom

GarrettCom Magnum ITS Blade Manuel utilisateur

GarrettCom

GarrettCom Magnum DS 880 Manuel utilisateur

GarrettCom

GarrettCom Magnum 6K8-Series Manuel utilisateur

GarrettCom

GarrettCom Magnum ES42 Series Manuel utilisateur

GarrettCom

GarrettCom Magnum S14 Manuel utilisateur

GarrettCom

GarrettCom Magnum 6K32F Manuel utilisateur

GarrettCom

GarrettCom Magnum 6K32F Manuel utilisateur

GarrettCom

GarrettCom Magnum 6K32 Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
