Fujitsu fi-71X0 Guide de configuration
1
fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
fi-71X0/fi-72X0 CONSUMABLE REPLACEMENT
AND CLEANING INSTRUCTIONS INSTRUCTIONS
CG00002-285801RevisionA
fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
2
Kit Contents
F1 Cleaner
Low VOC Qty 1 Cotton Swabs
Qty 1 100/pack
Lint Free
Cleaning Cloths
Qty 1 20/pack
Cleaning Paper
Qty 1 10/pack
Brake Roller
Qty 1
Pick Rollers
Qty 2
3
fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
ConsumablesList
Thefollowing table showsthe specifications ofconsumables and their
standard replacement cycle. It is recommended that you stock extra
consumablesbefore theonesin thescanner reach theend of theirservice
life. The consumables must be replaced periodically. You can check the
number of scanned pages for the Brake roller unit and the Pick roller unit
byreferring toeach counteron thisscanner.
Description Qty Life Fujitsu P/N
Pick Roller 2 200,000 PA03670-0002
Brake Roller 1 200,000 PA03670-0001
Pick Roller
Brake Roller
Note: ReplacementCycles areestimatedguidelines establishedby
testingwithA4/Lettersizedwoodfree and woodbased 17 lbpaper. NCR
orCarbonless paperhaschemical compositionwhichdamages thepad
andthe pickroller. Cleaningof theconsumables willbe required more
frequentlyto avoid feedprobelms. Consumablelife willbereduced if
NCRor Carbonless paperisscanned.
fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
4
CLEANING OF THE SCANNER
TheScannersAutomaticDocumentFeeder(ADF) shouldbecleaned at
leastevery 5000pages. This is verydependant onthe types ofpaper
beingscanned, whenscanning documents withtonner that hasnot fused
wellor have ink,the scanner mayrequire more frequentcleaning.
Open theADF by pressing
theADFOpenLeverand
pullingtheADF towardsthe
front of the scanner in the
directionof the arrowshow
in the drawing to the right.
ADF Open
Lever
Cleanthe Brake Rollers
(1) byremoving them from
thescanner and cleaning
with a lint free cloth
moistendwith F1cleaner.
Using the same lint free
cloth moistend with F1
cleanthe Feed Rollers(2),
EjectRollers(3), Glass(4)
andUltrasonicSensor(7).
5
fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
Clean the Pick Rollers(5) by
removingthemfromthe
scannerand cleaningwitha
lint free cloth moistend with
F1 cleaner. Using the same
lint free cloth moistend with
F1 clean the Glass(4),
PlasticRollers(6) and
UltrasonicSensor(7). Clean
thepaper pathof any loose
debris using a soft cloth or
vacuum.
Caution: When cleanning the paper path in the ADF avoid damaging the document
sensors shown below(1)
fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
6
REPLACING CONSUMABLES
From the [start] menu, select [All Programs] ([Scanner Utility for
MicrosoftWindows]([SoftwareOperationPanel].
Fromthe SoftwareOperator Panel selectionson the leftselect [Device
Settings]
Click on the [Clear] button next to the Pick Roller or Brake Roller counter
to clear it to 0 once you have replaced them. This will start the count over
for the new pick roller or brake roller installed in the following steps.
Click the [OK] button to close the Software Operator Panel Dialoge box.
If this message appears you may be able to scan a bit longer but you
should replace consumables as soon as possible.
7
fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
Note:
Afterreplacement ofany consumable resetthe counter forthat
consumableby followingtheinstructions inyour Operator’s Guide.
Detailedinstructions can befoundunder the“Replacing Consumables”
section of the Operator’s Guide as well as at the begining of this section
ofthisfi-71x0/fi-72x0Consumable Replacement andCleaning
Instructions.
REPLACING THE PICK ROLLER
Removeall documentsfromtheADFpaperchute (feeder)
Remove theADF paper chute (feeder).
Hold both ends of theADF paper chute (feeder), then lift it in the direction
of arrow 1 and pull it out in the direction of arrow 2
Pull theADF release tab towards you and then open theADF
fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
8
Liftup theshaft indirection 1 (about5mm), andslide theshaft
indirection 2to pullout theleading endfrom theslot, thenlift
theshaft indirection 3to remove it.
Openthe sheetguide bylifting thetab
Rotatethe bushingon the shaftto releasethe pickshaft
9
fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
Remove the two Pick Rollers from the shaft one
at a time.
Pulloutthe pickroller fromtheshaft asyou liftthe
retainingclip.
Pullout the otherpick rollerfrom theshaftas
youliftthe retainingclip.
fi-71X0/fi-72X0CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
10
Attach the two new Pick Rollers onto the shaft one at a
time.
Insert the retaining clip of the pick roller into the slot
Insert the retaining clip of the other pick roller into the slot.
Re-install the pick shaft by inserting the left end into the slot, and
gradually lower the other end.
