FTP-627USL401/402

Overview

The FTP-627 USL Series are 24V driven high-speed printers

with a ultra low prole auto cutter and long life.

The FTP-627 USL Series can be used for a variety of applica-

tions, such as POS terminals, ticket vending machines, label

printers, banking terminals, and measurement and medical

equipment.

HiGHLiGHTS

Ultra low prole

Height 108 mm, width 100 mm, depth 94 mm

High speed printing

It can print at 100 mm/s (800 dotlines/s) maximum by using

Fujitsu's unique head drive control.

Windows® 2000/XP, Linux and OPOS drivers

Auto Cutter

Long life and high reliable guilotine with dedicated motor.

Easy paper loading

Our lever platen release mechanism allows a

wide paper route, so 60 mm diameter paper can be easily

inserted.

Multifunctional die-cast frame

Wide operating temperature range, long continuous

printing, high ESD absorbtion and discharge of static

electricity vibration and shock resistant.

Barcodes

Prints standard, extended and 2-D types

RoHS compliant

■

•

24v drive, reCeiPT PriNTer MiCrO UNiT

2” HiGH SPeed THerMaL PriNTer

FTP-627USL401 platen/cutter closed

FTP-627USL401 platen/cutter open

FTP-627USL401/402

nParT NUMberS

* Interface board is the : FTP-627DSL601 (Serial/ USB), FTP-627DSL603 (USB), FTP-627DSL605 (Serial)

nSPeCiFiCaTiONS

Part Number Power

Printer mechanism with cutter and board FTP-627USL401 (USB interface) 5V / 24V

FTP-627USL402 (Serial interface) 5V / 24V

FTP-627USL410 (USB/Serial) 24V only

Length

Interface cables Serial (RS-232) FTP-628Y302 500mm

USB (V.1.1) FTP-629Y301 600mm

Power cables Logic FTP-629Y401 300mm

Head, motor FTP-629Y601 300mm

Part number FTP-627USL401/402

Printing method Thermal-line dot method

Dot structure 432 dots/line

Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density

Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch

Effective printing area 54 mm

Number of columns ANK 36 columns/line (maximum 12 x 24 dot font)

Paper width 58 mm

Paper diameter 60 mm

Paper thickness 60 to 90 µ m (some paper in this range may not be used because

of paper characteristics)

Printing Speed Maximum 100mm/sec. (800 dot line/sec.) at 24V, 25oC

Alphanumeric, kana: 159 types

International characters: 195 types

JIS Kanji (Kanji CG loaded board): about 6800 types

12 × 24 dots, (1.5 × 3.0 mm), 36 columns: ANK

24 × 24 dots, (3.0 × 3.0 mm), 18 columns: ANK

8 × 16 dots, (1.0 × 2.0 mm), 54 columns: ANK

16 × 16 dots, (2.0 × 2.0 mm), 27 columns: ANK

Barcodes

UPC-A, UPC-E, JAN (EAN) 13, JAN (EAN) 8, Code 39, 1TF CODABAR

CODE128

QR, Maxi , PDF417

Printing mode Page mode, line mode

SpecicationsItem

Character types

Character, dimensions (W×H), number

of columns

Standard

Extended

2-D

FTP-627USL401/402

nSPeCiFiCaTiONS

*+5˚C to +40˚C printing density assurance range.

Item Specication

Iterface Conforms to USB/Serial

Power

supply

For print head 24 VDC average current, 0.5A (0.9A peak)

(print ratio: 12.5%, print speed 100mm/sec.)

For motor 24 VDC ±5%, 0.9 A maximum

For cutter 24 VDC ±5%, 1.1 A maximum

For logic 4.75 to 5.25VDC, 0.2 A maximum

Dimensions Mechanism and board 100 x 94 x 108 mm (WxDxH)

Weight Mechanism and board Approximately 310g

Life Head Pulse durability: 50 million pulses/dot (under our standard

conditions); Abrasion resistance: paper traveling distance

50km (print ratio: 12.5% or less).

Cutter 500,000 cuts (20 cuts/minute)

Platen 5,000 (open/close)

MTBF Mechanism 3,000 hours

Circuit board 500,000 hours

Operating

environment

Operating temperature* 0ºC to +50ºC

Operating humidity 20 to 85% RH (no condensation)

Storage temperature -20ºC to +60ºC (paper not included)

Storage humidity 5 to 95% RH (no condensation)

Detection

function

Head temperature detection Detected by thermistor

Paper out/mark detection Detected by photo-interruptor

Platen release Detected by sliding switch

Recommended thermal sensitive paper High sensitive paper TF50KS-E4 (Nippon paper)

Standard paper TF60KS-E (Nippon paper),

FTP-020PU001 (58mm)

PD105R (Oji paper)

FTP-020P0701 (58mm)

Medium life paper TF60KS-F1 (Nippon paper)

FTP-020P0102 (58mm)

PD170R (Oji paper)

P220VBB-1 (Mitsubishi paper)

Long life paper PD160R (Oji paper)

AFP-235 (Mitsubishi paper)

TP50KJ-R (Nippon paper)

HA220AA (Nippon paper)

FTP-627USL401/402

Name Functions Remarks Note

CN1 +24V power supply connector Connection for +24V power supply

CN2 RS-232C Connection for serial interface *2

CN3 USB I/F connector Connection for USB interface *2

CN4 - -

CN5 Cutter connector Connection for paper cutter

CN6 Operation panel connector Connection for operation panel *1

CN7 Near end sensor connector Connection for near end switch

CN8 - -

CN9 Logic power connector Connection for +5V power Supply *1

CN10 Head/motor connector Connection for thermal head & paper feed motor 2-inch, 24 pin

niNTerFaCe, COMMaNd, OPTiONS

nFUNCTiON OF iNTerFaCe bOard

metI metI

.1 noitcnuftnirptseT .8 tcetedelbuortrettuC

.2 noitcetedtuorepaP .9 noitcnufgnivasrewoprotoM

.3 noitceteddneraenrepaP .01 noitcnufnoitcetedkraM

.4 noitcetedneponetalP .11 noitcetedytilamronbanoitarepoUCM

.5 noitcetedytilamronbaerutarepmetdaehlamrehT .21 noitcetorpecneuqesFFO/NOrewoP

.6 noitcetedesuftuo-wolB .31 noitcetorptnerruc-revorotoM

.7 noitcetedytilamronbaegatlovdaeH .41 remiterawdraH

Connectors on Control Board

Note: *1: Option

*2: Depends on P/N

FTP-627USL401/402

Note: 1. The cable size and FPC are not included in this drawing.

2. Do not mount anything in the shaded area except the printer.

3. Connect to the body with 2 screws at 2 hooks.

ndiMeNSiONS

1. Printer mechanism

Unit: mm

FTP-627 Unit Paper ø60 *2

2-screw holes *3

(Cross section)

Hook depth 6 *3

86 (paper presenting area)

86 (paper presenting area) Paper

FTP-627USL401/402

Command Contents

HT Moves print position to the next tab.

LF Line feed.

FF Feeds forms (new page).

ESC FF Data printing in page printing mode.

ECS RS Sets reverse printing.

ESC US Resets reverse printing.

ESC SP+n Character spacing setting.

ESC ! + n Sets print mode.

ESC $+n1+n2 Absolute position spacing.

ESC % + n External registration character specication/cancellation.

ESC & +y+c1+c2+x+d1to dn External registration character denition.

ESC *+m+n1+n2+d1+dN Sets bit image mode.

ESC - +n Undeline setting.

ESC 2 Sets 1/6 inch line feed length.

ESC 3+n Sets the line feed length.

ESC ? + n External registration character deletion.

ESC @ Printer initialization.

ESC A+n Sets the space between the line.

ESC C+n Sets the page length by character line.

ESC D+d1+dN +NUL Sets the tab position.

ESC E+n Highlighted printing specication/cancellation

ESC J+n Feeds paper in forward direction and prints.

ESC K+n Reverse paper feed.

ESC L Page printing mode selection.

ESC Q+n+!+j Frame overlay function.

ESC R+n Selects international character.

ESC S Line printing mode.

ESC T+n Print direction setting (only page mode).

ESC V+n Right Rotation 90° specication / cancellation.

nCOMMaNdS

FTP-627USL401/402

Command Contents

ESC W+X1+X2+1+Y2+dX1+dX2+dX1+dY2 Page printing mode printing area setting.

ESC X+m+n Setting the turning time of the motor excitation.

ESC Y+01h+ESC+x+a+m+d~ Program download.

ESCY+n1+n2 Relative position setting.

ESC a+n Positional alignment.

ESC c+1+n Sets internal processing.

ESC c+5+n Panel switch enable/disable setting.

ESC d+n Printing and n-line feeding.

ESC i Full cut

ESC m Partial cut

ECS s+n Sets printing speed.

ECS t+n Character code table selection.

ESC {+n Sets/resets upside down printing.

ESC DEL+n Flash memory delete.

FS !+n Kanji printing mode collective specication.

FS & Kanji printing mode specication.

FS_+n Kanji underline specication/cancellation.

FS *+ m+n1+n2+d1 to dn High speed collective image printing specied.

FS . Kanji printing mode cancellation.

FS 2+c1+c2+d1 to dn External character denition.

FS 9+n Sets the detection functions.

FS C+n Kanji code system selection.

FS E+n Correction of impressed energy.

FS S+n+n1+n2 Kanji spacing setting.

FS W+n Kanji double height adn width printing specication/cancellation.

FS r+n*1 Parameter transmission.

GS ! + n Character size specication.

Commands continued

FTP-627USL401/402

Command Contents

GS $ + n1 + n2 Vertical absolute position specication in page printing mode.

GS & +m + x + y1 + y2 + d1 to dn Registered bit image denition.

GS' + m + n Registered bit image printing.

GS *+x+y1+y2 +d1+dn Registered bit image denition.

GS/ +m Registered bit image printing.

GS < Line feeds to the next mark.

GS A+m+n Sets the line feed length after mark detection.

GS B+m Angle setting of bar code.

GS E+n Sets print quality.

GS H+n HRI character printing position selection.

GS L+n1+n2 Left margin position setting.

GS M+n Printer ID demand.

GS W + n1 + n2 Printing area width setting.

GS Y +n1 + n2 Vertical relative position specication in page printing mode (vertical

direction of characters).

GS e+n+m Sets bar code width.

GS f + n HRI character font selection.

GS h+n Sets bar code height.

y) GS k+m +d1to dk + NUL Bar code printing.

x) GS k+m+n+ d1 to dn

GS k+m+k1+k2+k3+k4+{[p1][d(1,1)] ~ Print of 2Dcode (QR).

[d(1,i)} ~ {[pi][d(i,1)]~[d(i,j)} [00]16

GS k+m+k1+k2+k3+k4+k5+d1~dn Print of 2 Dcode (maxi).

GS k+m+k1+k2+k3+k4+k5+k6+d1~dn Print of 2 Dcode (PDF417).

GS w+n Sets bar code length.

GS C+C+n1+n2+m+fn+b+d1~dn Customize printer.

Commands continued

*1: These commands are valid with FTP-627DSL600 series.

FTP-627USL401/402

Japan

Fujitsu Component Limited

Gotanda-Chuo Building

3-5, Higashigotanda 2-chome, Shinagawa-ku

Tokyo 141 8630, Japan

Tel: (81-3) 5449-7010

Fax: (81-3) 5449-2626

Email: [email protected]

Web: www.fcl.fujitsu.com

North and South America

Fujitsu Components America, Inc.

250 E. Caribbean Drive

Sunnyvale, CA 94089 U.S.A.

Tel: (1-408) 745-4900

Fax: (1-408) 745-4970

Email: [email protected]

Web: http://us.fujitsu.com/components/

Europe

Fujitsu Components Europe B.V.

Diamantlaan 25

2132 WV Hoofddorp

Netherlands

Tel: (31-23) 5560910

Fax: (31-23) 5560950

Email: [email protected]

Web: emea.fujitsu.com/components/

Asia Pacic

Fujitsu Components Asia Ltd.

102E Pasir Panjang Road

#01-01 Citilink Warehouse Complex

Singapore 118529

Tel: (65) 6375-8560

Fax: (65) 6273-3021

Email: [email protected]

Web: http://www.fujitsu.com/sg/services/micro/components/

Fujitsu Components International Headquarter Ofces

owners.

Fujitsu Components America or its afliates do not warrant that the content of datasheet is error free. In a continuing effort to improve our

products Fujitsu Components America, Inc. or its afliates reserve the right to change specications/datasheets without prior notice.

Rev. February 26, 2009.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Fujitsu Imprimante

Fujitsu

Fujitsu FTP-608 Series Manuel utilisateur

Fujitsu

Fujitsu FTP-624CU102 Manuel utilisateur

Fujitsu

Fujitsu TM 14ADV Manuel utilisateur

Fujitsu

Fujitsu FTP-631MCL101 Manuel utilisateur

Fujitsu

Fujitsu S510 - ScanSnap - Document Scanner Guide de configuration

Fujitsu

Fujitsu FTP-622MCL101 Guide d'installation

Fujitsu

Fujitsu KD96009-0648 Manuel utilisateur

Fujitsu

Fujitsu DL3750+/3850+ Manuel utilisateur

Fujitsu

Fujitsu fi-7480 Manuel utilisateur

Fujitsu

Fujitsu DL2400 Manuel utilisateur

Fujitsu

Fujitsu DL7600 Manuel utilisateur

Fujitsu

Fujitsu FTP-627MCL054 Manuel utilisateur

Fujitsu

Fujitsu DL5800 Manuel utilisateur

Fujitsu

Fujitsu FTP-627USL431 Manuel utilisateur

Fujitsu

Fujitsu DL Series Instructions de montage

Fujitsu

Fujitsu DL4400 Manuel utilisateur

Fujitsu

Fujitsu FTP-631MCL201 Manuel utilisateur

Fujitsu

Fujitsu FTP-627MCL103 Manuel utilisateur

Fujitsu

Fujitsu DL3800 Pro Manuel utilisateur

Fujitsu

Fujitsu FTP-642MCL001 Manuel utilisateur

Fujitsu

Fujitsu FTP628WSL221A Manuel utilisateur

Fujitsu

Fujitsu FTP-621DCL003 Manuel utilisateur

Fujitsu

Fujitsu SP-1120 Manuel

Fujitsu

Fujitsu fi-748PRB Manuel

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
