Fujitsu D3034 Manuel utilisateur

Technical Manual - English

System Board D3034

for PRIMERGY RX100 S7

Technical Manual

Edition August 2012

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected]su.com.

Certified documentation

according to DIN EN ISO 9001:2008

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2008.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

ÊThe contents of this manual may be revised without prior notice.

ÊFujitsu assumes no liability for damages to third party copyrights or other rights arising from

the use of any information in this manual.

ÊNo part of this manual may be reproduced in any form without the prior written permission

of Fujitsu.

Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of

Microsoft Corporation in the USA and other countries.

Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries

in the USA and other countries.

D3034 (RX100 S7) Technical Manual

Before reading this manual

For your safety

This manual contains important information for safely and correctly using this

product.

Carefully read the manual before using this product. Pay particular attention to

the accompanying manual "Safety Notes and Regulations" and ensure these

safety notes are understood before using the product. Keep this manual and the

manual "Safety Notes and Regulations" in a safe place for easy reference while

using this product.

Radio interference

This product is a "Class A" ITE (Information Technology Equipment). In a

domestic environment this product may cause radio interference, in which case

the user may be required to take appropriate measures. VCCI-A

Aluminum electrolytic capacitors

The aluminum electrolytic capacitors used in the product's printed circuit board

assemblies and in the mouse and keyboard are limited-life components. Use of

these components beyond their operating life may result in electrolyte leakage

or depletion, potentially causing emission of foul odor or smoke.

As a guideline, in a normal office environment (25°C) operating life is not

expected to be reached within the maintenance support period (5 years).

However, operating life may be reached more quickly if, for example, the

product is used in a hot environment. The customer shall bear the cost of

replacing replaceable components which have exceeded their operating life.

Note that these are only guidelines, and do not constitute a guarantee of

trouble-free operation during the maintenance support period.

High safety use

This product has been designed and manufactured to be used in commercial

and/or industrial areas as a server.

When used as visual display workplace, it must not be placed in the direct field

of view to avoid incommoding reflections (applies only to TX server systems).

The device has not been designed or manufactured for uses which demand an

extremely high level of safety and carry a direct and serious risk of life or body

if such safety cannot be assured.

Technical Manual D3034 (RX100 S7)

These uses include control of nuclear reactions in nuclear power plants,

automatic airplane flight control, air traffic control, traffic control in mass

transport systems, medical devices for life support, and missile guidance

control in weapons systems (hereafter, "high safety use"). Customers should

not use this product for high safety use unless measures are in place for

ensuring the level of safety demanded of such use. Please consult the sales

staff of Fujitsu if intending to use this product for high safety use.

Measures against momentary voltage drop

This product may be affected by a momentary voltage drop in the power supply

caused by lightning. To prevent a momentary voltage drop, use of an AC

uninterruptible power supply is recommended.

(This notice follows the guidelines of Voltage Dip Immunity of Personal

Computer issued by JEITA, the Japan Electronics and Information Technology

Industries Association.)

Technology controlled by the Foreign Exchange and Foreign Trade

Control Law of Japan

Documents produced by Fujitsu may contain technology controlled by the

Foreign Exchange and Foreign Trade Control Law of Japan. Documents which

contain such technology should not be exported from Japan or transferred to

non-residents of Japan without first obtaining authorization in accordance with

the above law.

Harmonic Current Standards

This product conforms to harmonic current standard JIS C 61000-3-2.

Only for the Japanese market:

About SATA hard disk drives

The SATA version of this server supports hard disk drives with SATA / BC-SATA

storage interfaces. Please note that the usage and operation conditions differ

depending on the type of hard disk drive used.

Please refer to the following internet address for further information on the

usage and operation conditions of each available type of hard disk drive:

http://jp.fujitsu.com/platform/server/primergy/harddisk/

D3034 (RX100 S7) Technical Manual

Only for the Japanese market:

Shielded LAN cables should be used in this product.

Only for the Japanese market:

IAlthough described in this manual, some sections do not apply to the

Japanese market. These options and routines include:

– USB Flash Module (UFM)

– CSS (Customer Self Service)

Technical Manual D3034 (RX100 S7)

D3034 (RX100 S7) Technical Manual

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.1 Notational conventions . . . . . . . . . . . . . . . . . . . . 10

2 Important information . . . . . . . . . . . . . . . . . . . . . 11

2.1 CE certificate of conformity . . . . . . . . . . . . . . . . . . 11

2.2 Environmental protection . . . . . . . . . . . . . . . . . . . 12

3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.2 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.2.1 Module population . . . . . . . . . . . . . . . . . . . . . . . . 21

3.2.1.1 Types of memory modules . . . . . . . . . . . . . . . . . . 21

3.2.1.2 Modes of operation . . . . . . . . . . . . . . . . . . . . . . 22

3.3 PCI slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3.4 Screen resolution . . . . . . . . . . . . . . . . . . . . . . . 25

3.5 Temperature / system monitoring . . . . . . . . . . . . . . . 26

3.6 Connectors and indicators . . . . . . . . . . . . . . . . . . 27

3.6.1 System board . . . . . . . . . . . . . . . . . . . . . . . . . . 27

3.6.2 Connector panel . . . . . . . . . . . . . . . . . . . . . . . . . 31

3.7 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

3.7.1 Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Technical Manual D3034 (RX100 S7)

Contents

D3034 (RX100 S7) Technical Manual 9

1 Introduction

This technical manual describes the system board D3034, which can be

equipped with one processor.

For additional driver information (if available), refer to the Readme files located

on the server hard disk and on the supplied DVDs (see Installation DVD of

ServerView Suite - ServerView Software Products).

You will find further information about the BIOS setup in the "D3034 BIOS Setup

Utility for PRIMERGY RX100 S7" manual.

IPRIMERGY manuals are available in PDF format on the PRIMERGY

ServerView Suite DVD 2. The PRIMERGY ServerView Suite DVD 2 is

part of the PRIMERGY ServerView Suite supplied with every server.

PRIMERGY Abbreviations and Glossary can also be found on the PRIMERGY

ServerView Suite DVD 2.

Model lines for RX100 S7

There are two model lines for the RX100 S7 server:

– RX100 S7

– RX100 S7p

IFor the European market:

You can identify the model line by the model name "RX100 S7p" printed

on the identification rating plate and on the ID card.

IFor the Japanese market:

"RX100 S7p" is not used as the model name in the Japanese market.

You can identify the model line by the product number; The product

number "PYR10Pxxx" means RX100 S7p.

For an overview of the different features please refer to table 1 on page 15.

10 Technical Manual D3034 (RX100 S7)

Introduction

1.1 Notational conventions

The following notational conventions are used in this manual:

Text in italics indicates commands or menu items.

"Quotation marks" indicate names of chapters and terms that are being

emphasized.

Êdescribes activities that must be performed in the order

shown.

VCAUTION! pay particular attention to texts marked with this symbol.

Failure to observe this warning may endanger your life,

destroy the system or lead to the loss of data.

Iindicates additional information, notes and tips.
