Fujitsu D2860 Manuel utilisateur

System Board D2860

for BX920

Technical Manual

Edition January 2010

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected].

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

D2860 (BX920) Technical Manual

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.1 Notes on safety . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.2 CE Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.3 Environmental Protection . . . . . . . . . . . . . . . . . . . 11

3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.2 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.3 Screen resolution . . . . . . . . . . . . . . . . . . . . . . . 23

3.4 Temperature/system monitoring . . . . . . . . . . . . . . . 23

3.5 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

3.6 Interfaces and connectors . . . . . . . . . . . . . . . . . . . 26

3.6.1 External ports . . . . . . . . . . . . . . . . . . . . . . . . . . 27

3.7 Settings with switches and jumpers . . . . . . . . . . . . . 28

4 Replacing the lithium battery . . . . . . . . . . . . . . . . . 31

D2860 (BX920) Technical Manual 5

1 Introduction

This technical manual describes the system board D2860, which is equipped

with one Intel®processor.

Further information about drivers is provided in the readme files on the hard

disk, on the supplied “ServerStart“ or “Update“ CDs.

You will find further information in the BIOS description.

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

italics indicates commands, menu items, file and path

names or software programs.

fixed font indicate system output on the monitor.

semi-bold fixed

font

indicates values to be entered through the keyboard.

[Key symbol] indicates keys according to their representation on the

keyboard.

If capital letters are to be entered explicitly, then the

Shift key is shown, e.g. [SHIFT] - [A] for A.

If two keys need to be pressed at the same time, then

this is shown by placing a hyphen between the two key

symbols.

“quotation marks” indicates names and terms that are being empha-

sized.

Êindicates an operation that to be performed.

VCAUTION! indicates warnings, which, if ignored, will endanger

your health, destroy the system or lead to the loss of

data.

Iindicates additional information, notes and tips.

Table 1: Notational conventions

D2860 (BX920) Technical Manual 7

2 Important notes

In this chapter you will find essential information regarding safety when working

with your server.

VCAUTION!

With the system board installed you must open the system to access the

system board. How to access the system board of your system is

described in the appropriate service supplement.

When handling the system board, refer to the specific notes on safety in

the operating manual and/or service supplement for the respective

server.

2.1 Notes on safety

VCAUTION!

●The actions described in these instructions should only be performed

by authorized, qualified personnel. Equipment repairs should only be

performed by qualified staff. Any failure to observe the guidelines in

this manual, and any unauthorized openings and improper repairs

could expose the user to risks (electric shock, fire hazards) and could

also damage the equipment. Please note that any unauthorized

openings of the device will result in the invalidation of the warranty

and exclusion from all liability.

●Transport the device only in the antistatic original packaging or in

packaging that protects it from knocks and jolts.

●Only install expansions that are allowed for the system board. If you

install other expansions, you may damage the requirements and rules

governing safety and electromagnetic compatibility or your system.

Information on which system expansions are suitable can be

obtained from the customer service centre or your sales outlet.

●The warranty expires if the device is damaged during the installation

or replacement of system expansions.

8 Technical Manual D2860 (BX920)

Notes on safety Important notes

V●Components can become very hot during operation. Ensure you do

not touch components when making extensions to the system board.

There is a danger of burns!

●Transmission lines to peripheral devices must be adequately

shielded.

●To the LAN wiring the requirements apply in accordance with the

standards EN 50173 and EN 50174-1/2. As minimum requirement

the use of a protected LAN line of category 5 for 10/100 MBit/s

Ethernet, and/or of category 5e for Gigabit Ethernet is considered.

The requirements of the specification ISO/IEC 11801 are to be

considered.

●Never connect or disconnect data transmission lines during a storm

(lightning hazard).

Batteries

VCAUTION!

●Incorrect replacement of lithium battery may lead to a risk of

explosion. The batteries may only be replaced with identical batteries

or with a type recommended by the manufacturer.

It is essential to observe the instructions in chapter “Replacing the

lithium battery”.

D2860 (BX920) Technical Manual 9

Important notes Notes on safety

Modules with electrostatic-sensitive components

Systems and components that might be damaged by electrostatic discharge

(ESD) are marked with the following label:

Figure 1: ESD label

When you handle components fitted with ESDs, you must observe the following

points under all circumstances:

●You must always discharge yourself of static charges (e.g. by touching a

grounded object) before working.

●The equipment and tools you use must be free of static charges.

●Remove the power plug from the power socket before inserting or removing

boards containing ESDs.

●Always hold boards with ESDs by their edges.

●Never touch pins or conductors on boards fitted with ESDs.

●Use a grounding cable designed for this purpose to connect yourself to the

system unit as you install/deinstall the board.

●Place all components on a static-safe base.

IYou will find a detailed description for handling ESD components in the

relevant European or international standards (EN 61340-5-1,

ANSI/ESD S20.20).

10 Technical Manual D2860 (BX920)

CE Certificate Important notes

Notes about boards

●During installation/deinstallation of the system board, observe the specific

instructions described in the service manual for the server.

●Remove the plug from the mains outlet so that system and system board are

totally disconnected from the mains voltage.

●To prevent damage to the system board, the components and conductors on

it, please take great care when you insert or remove boards. Take great care

to ensure that extension boards are slotted in straight, without damaging

components or conductors on the system board, or any other components,

for example EMI spring contacts.

●Be careful with the locking mechanisms (catches, centring pins etc.) when

you replace the system board or components on it, for example memory

modules or processors.

●Never use sharp objects (screwdrivers) for leverage.

2.2 CE Certificate

The board complies with the requirements of the EC directives

2004/108/EC regarding “Electromagnetic Compatibility” and

2006/95/EC “Low Voltage Directive”. This is indicated by the CE

marking (CE = Communauté Européenne).

Compliance was tested in a typical PRIMERGY configuration.
