Fujitsu D3230 Manuel utilisateur

Mainboard

Short Description

Mainboard D3230/D3240

Congratulations on buying an innovative

product from Fujitsu.

The latest information about our products, tips, updates etc. can be found

on the Internet at: "http://www.fujitsu.com/fts/"

For driver updates, go to: "http://support.ts.fujitsu.com/download"

Should you have any technical questions, please contact:

• our Hotline/Service Desk (see the Service Desk list or visit:

"http://support.ts.fujitsu.com/contact/servicedesk")

• Your sales partner

• Your sales ofﬁce

We hope you enjoy working with your new Fujitsu system!

Published by / Contact address in the EU

Fujitsu Technology Solutions GmbH

Mies-van-der-Rohe-Straße 8

80807 Munich, Germany

"http://www.fujitsu.com/fts/"

©Fujits

Publication Date

02/2014

Order No.: A26361-D3230-Z320-1-7419, edition 2

Internal connectors and slots

USB 3.0 1 = 5V USB

2 = USB3_RX negative (P2)

3 = USB3_RX positive (P2)

4 = GND

USB3_TX negative (P2)

5 =

6 = USB3_TX positive (P2)

7 = GND

8 = Data negative (P2)

9 = Data positive (P2)

10 = FP Detect

11 = Data positive (P3)

12 = Data negative (P3)

13 = GND

14 = USB3_TX positive (P3)

USB3_TX negative (P3)

15 =

16 = GND

17 = USB3_RX positive (P3)

18 = USB3_RX negative (P3)

19 = 5V USB

20 = Not connected

1 =

2 =

3 =

Audio Front Panel Connector

Mic Left

Mic Right

FP Present Detect

Headphone out Right 8 =

Analog GND

4 =

5 =

6 =

7 =

9 =

Jack Detect Mic

Analog GND

Key

Jack Detect Headphone

External connectors rear

1 = 5V USB

2 = 5V USB

3 = Data negative Port X

4 = Data negative Port Y

6 = Data positive Port Y

Data positive Port X

7 =

5 =

GND

8 = GND

9 = Key

10 = Not connected

Front panel

USB 3.0/ USB 2.0

DVI-D

USB 2.0

Recovery inserted = The system starts

HD-LED

Recovery

Reset

Power

On/Off

Power LED

from USB stick and allows a BIOS recovery.

Details can be found in the BIOS manual.

Speaker -

Speaker +

PS2 D3230-A:

VGA

DVI-D

SIO

FAN1

PCle x1

Buzzer*

PCle x16

Realtek

LAN 8111G

D3230-A/B:

USB3.0

D3240-B:

USB2.0

D3230-B:

Intel LAN

AFP P1P0

SATA

Front

Panel Con.

D3240-B:

USB_1/2_x

FAN2

A, Slot 1

Audio Descr.

Override

TPM*

TPM

Disable*

PCle x1

Audio

USB2.0

D3230-A:

USB_5/6_i

USB_3/4_x

P4P5

D3230-B

D3240-B:

SATA

Power

D3230-B

D3240-B:

Multirail

Power

Supply

Channel

Channel B, Slot 2

* Layout Prepared

12 V Power Rail

D3230-A:

Fujitsu

Internal connectors and slots

List of onboard Features D3230-A D3230-B D3240-B

CPU Socket LGA1150 LGA1150 LGA1150

Chipset Intel® H81 Intel® H81 Intel® H81

Board size Ultra small

μATX

Ultra small

μATX

Ultra small

μATX

DVI-D / DVI-I / VGA / DP (DisplayPort) / HDMI /-/ /-/- /-/ /-/- /-/ /-/-

Stereo Audio / 5.1 Multichannel Audio / S/PDIF -/ /- -/ /- -/ /-

Buzzer / int. Speaker Support - / *** - / - - / -

LAN: 1 Gbit / 100 Mbit / 10 Mbit / / / / / /

LAN: WoL / Remote Boot / / /

LAN: iAMT / DASH - / - - / - - / -

SATA*: 6 Gb/s (Ports) / 3 Gb/s (Ports) 2 / 1 2 / 2 2 / 2

PCIe 3.0 / PCIe 2.0 - / -/ -/

Intel® Smart Response Technology ---

USB 2.0 / USB 3.0 (Rear) / USB 3.0 (Internal/Front) //- //- /-/

PS2 / COM Port /- /- /-

FAN monitored and controlled: PSU** / CPU (FAN1) /

System (FAN2) / AUX2 (FAN3) -/ //- -/ //- -/ //-

TEMP monitored: CPU / Onboard 1 / Onboard 2 /

Onboard 3 / Chipset / Super I/O

//-/

-/-/-

//-/

-/-/-

//-/

-/-/-

Special onboard features D3230-A D3230-B D3240-B

Green Edition ---

Silent Fan / Silent Fan LT / System Guard / Silent

Drives -/ / / -/ / / -/ / /

Recovery BIOS / Desk Update / Multi Boot / / / / / /

HDD Password

Keyboard Power Button / Low Power Soft Off / USB

Power Off / / //-(o

in S5) / /

* maximum supported Transfer Rate per Port

** not supported by standard Power Supplies

*** from WGS3 / from WGS2 Layout prepared

Fujitsu

Internal connectors and slots

Special Features

Green Edition Halogen-free product

Silent Fan OS Independent, temperature related full featured silent fan control

System Guard View and adjust Silent Fan (only OEM version) / Silent Fan LT

Silent Drives Noise reduction for optical and hard disk drives

Recovery BIOS Restores a corrupted BIOS

Desk Update Simple driver update with DU DVD

Multi Boot Comfortable boot from any boot device

HDD Passwort Access protection for disk drives

Silent Fan LT OS Independent, temperature related silent fan control

Keyboard Power

Button Fujitsu Technology Solutions Keyboard Power Button Support

Low Power Soft Off Reduced Energy consumption in shut down

USB Power Off Enable/Disable USB Power via BIOS in shut down mode

Risk of Explosion if battery is replaced by an incorrect type.

Dispose of used batteries according to the instructions.

Il y a risque d’explosion si la batterie est remplacée par une batterie de type incorrect.

Mettre au rebut les batteries usagées conformément aux instructions.

Explosionsgefahr, wenn die Batterie mit einem inkorrekten Batterietyp ersetzt wird.

Alte Batterien gemäß Gebrauchsanweisung entsorgen.

Fujitsu

Internal connectors and slots
