Preface

Objective of Manual and Target Audience

The MB90M405 Series is a general-purpose semiconductor device in the F2MC-16LX family. It is a 16-bit

single-chip microcontroller ASIC (Application Specific IC). This manual explains the functionsand

operationsof the MB90M405 Series for engineers who design products using this device.

How to Read This Manual

Page Organization

A summary is given below the title of each section. A title of the main section is noted in the sub-section to

recognize a current-reading section.

Index Organization

(1) Register map index

The register map index formatis similar to the I/O map and it allows search for the page explaining the

bits of each register from the address, register abbreviation, register name, and resource macro name.

Use the register map index at searching for the register function when designing aresource macro.

(2) Pin function index

The pin function index is similar to the explanation ofthe pin function and it allows serch for the block

diagram of each resource macro, the explanation ofthe pin function, and notes from the package pin

number, pin name, circuit type, and resource macro name. Use the pin function index when creating

the system board, etc. (The pin function index will be provided in the next revision of this manual).

Organization of Notes and Checks

Notes :Reference information is given here. Use this as a hint or note when usingthe MB90M405.

This also gives a section(s) to refer.

Check :Precautions when usingthe MB90M405 are given here. Specification restrictions, etc., are

included.

1.1 Features

................................

............

1-3

1.2 Resources.........................................................................1-4

1.3 Product Lineup..................................................................1-5

1.4 Block Diagram...................................................................1-6

1.5 Pin Assignment.................................................................1-7

1.6 Pin Description..................................................................1-8

1.7 I/O Circuit Type...............................................................1-11

1.8 Notes on Handling Devices.............................................1-13

1.9 Clock Supply Map...........................................................1-15

1.10 Low Power Consumption Mode.......................................1-16

1. GENERAL

MB90M405 F2MC-16LX FAMILY HARDWARE MANUAL

1-2

GENERAL

1-3

This chapter explains the features and basic specifications of the Monolith (MB90M405).

The MB90M405 Series is a general-purpose 16-bit microcontroller developed for applications requiring

fluorescent lamp panel control and contains 60 high-voltage withstand output pins required for afluorescent

lamp.

As with the original F2MC-8L and F2MC-16L families, the instruction system inherits the AT architecture, and

has extended high-level language interface instructions and the extended addressing modes, enhanced

multiplication/division instructions (signed), and enhanced bit processing. In addition, a32-bit accumulator

enables handle long word processing.

1.1 Features

•Clock:

•PLL Clock multiplication circuit built-in

•Operating clock (PLL clock) generated by dividing original oscillation by 2 or by multiplying original

oscillation by 1 to 4 (2.1 MHz to 16.8 MHz at original oscillation of 4.2 MHz). Can be selected.

•Minimum instruction execution time is 59.5 ns (when the original oscillation is 4.2 MHz, the PLL clock is

generated by multiplying the original oscillation by 4, and Vcc = 3 V).

•It is possible to generate an external output as a clock output by dividing the original oscillation by 16, 32,

64, or 128.

•Maximum memory space: 16 Mbytes

•24-bit addressing in memory space

•Instruction system suited for controller

•Applicable data types (bit, byte, word, long-word)

•Various addressing modes: 23 types

•High code efficiency

•High-precision operation with 32-bit accumulator

•Signed multiplication and division instructions and enhanced RETI instruction

•Powerful instruction system applicable to high-level language (C) or multitasking

•System stack pointer

•Symmetric instruction set and barrel shift instruction

•Program patch function (2-address pointer)

•Shortened execution time: 4-byte instruction queue

•Powerful interrupt function (eight programmable priority levels)

•Powerful interrupt function for 32 interrupt factors

•Data transfer function (extended intelligent I/O service function: 16 channels maximum)

•Low-power consumption (standby mode)

•Sleep mode (stops CPU operating clock)

•Pseudo-timermode (stops everything except original oscillation and time-base timer)

•Stop mode (stops original oscillation)

•CPU Intermittent operation mode

•Package

•QFP-100 (FPT-100P-M06: 0.65 mm pin pitch)

•Process

•CMOS technology

MB90M405 F2MC-16LX FAMILY HARDWARE MANUAL

1-4

1.2 Resources

•I/O port: 26 pins maximum (All 26 pins can also serve as resource pins).

•18-bit time-base timer: 1 channel

•Watchdog timer: 1 channel

•16-bit reload timer: 3 channels

•16-bit free-run timer: 1 channel

•16-bit output compare: 1 channel

•16-bit input capture: 2 channels

•When the count value of the 16-bit free-run timer matches the setting value of the output compare, the

timer is cleared and an interrupt request is issued.

•Serial I/O: 2 channels

•UART: 2 channels

•Clock-synchronous serial transfer (I/O extended serial) can be used.

•The direction of the shift clock level can be selected arbitrarily (MSB or LSB).

•DTP/external interrupt (4 channels)

•Start extended intelligent I/O services by an external input, and generate an external interrupt.

•Delayed interrupt generation module

•Atask-switching interrupt request is generated.

•8-/10-bit A/D converter (16 channel)

•8- or 10-bit resolution can be selected.

•FL controller

•Enables FL driver control.(The auto display control is performed for 32 digits max. and 59 segments

max.)

1 to 32 digits can be set (can be set on a digit-by-digit basis).

The dimmer can be set.

•Enables LED driver control (Auto display control is performed for 16 segments maximum).

The auto display control can be performed for 16 segments max. at 1/2 duty.

•Timerclock divider

•The original oscillation can be divided by 32, 64, 128, or 256.

GENERAL

1-5

1.3Product Lineup

Table 1-1 lists the Monolith (MB90M405) series product lineup. Functionsother than the ROM/RAM capacity

are shared.

Table 1-1 MB90M405 Series Product Lineup

Product name MB90MV405 MB90MF408 MB90M408 MB90M407

Classification Evaluate Flash Type ROM Mass-produced product (mask ROM)

ROM capacity Not provided 128 Kbytes 96 Kbytes

RAM capacity 4Kbytes 4Kbytes 4Kbytes

CPU Function

Count of basic instructions: 351

Minimum instruction execution time: 59.5 ns (at original oscillation of 4.2 MHz, with

PLL clock generated by multiplying original

oscillation by 4)

Addressing types: 23

Program patch function: 2-address pointer

Maximum memory space: 16 Mbytes

Port I/O port (CMOS) 26 pins (all of 26 pins also serve as resource pins)

FL Controller

60 FL output pins can be used (Under LED control, 43 FL output pins and 17 LED

control pins are required).

Enables FL driver control and LED driver control can be performed.

Under FL driver control, the dimmer can be set for both digits and segments.

Serial I/O (UART) Can also be used as the clock-synchronous method extended I/O serial.

Adedicated baud rate generator is built-in.

Four channels are built-in (two channels also serve as UART channels).

16-bit reload timer 16-bit reload timer operation (Toggle output or one-shot output can be selected.)

An event count function can be selected. Three channels are built-in.

16-bit free-run timer 16-bit output compare x 1 channel (for clearing free-run timer)

16-bit input capture x 2 channels

8-/10-bit A/D

converter 8-/10-bit resolution x 16 channels (input multiplex)

Minimum conversion time: 6.2 µs (at internal operation of 16 MHz)

Timerclock divider The external input clock can be divided and output to the outside.

Clock division rates: 16, 32, 64, or 128 (programmable)

External interrupt Four independent channels (also serve for A/D input)

Interrupt factor: L →H edge, H →L edge, L level, or H level

Low power

consumption mode Sleep mode, stop mode, CPU intermittent mode, or pseudo-timermode

Process CMOS

Package PGA256 QFP-100 (0.65 mm pitch)

Operating voltage 3.3 V ±0.3 V(16.8 MHz: 4.2 MHz multiplied by 4)

MB90M405 F2MC-16LX FAMILY HARDWARE MANUAL

1-6

1.4Block Diagram

FIP0/LED0

FIP16/LED16

FIP17 to FIP59

FL Controller

Timer clock

divider

V-RAM

8-/10-bit A/D

Converter

Serial I/O

(ch 2)

External interrupt

input controller

ROM

(96/128 KB)

RAM

(4 KB)

Clock

controller

CPU

Controller

X0,X1

RSTX

MD2,1,0

16-bit free-run timer

16-bit input capture

(ch 0, 1)

16-bit output

compare

I2C Interface

16-bit reload timer

(ch 0, 1, 2)

FMC-16LX Bus

PA0/AN0/TMCK

PA1/AN1

PA2/AN2

PA3/AN3

PA4/AN4

PA5/AN5

PA6/AN6

PA7/AN7

PB0/AN8

PB1/AN9

PB2/AN10

PB3/AN11/SI2

PB4/AN12/SC2/TIN

PB5/AN13/SO2/TO

PB6/AN14/INT3

PB7/AN15/INT2

P80/IC0/INT0

P81/IC1/INT1

P82/SI0

P83/SC0

P84/SO0

P85/SI1

P86/SI2

P87/SI3

P90/SDA/SO3

P91/SCL/SC3

Port A

Port BPort 8

Port 9

UART

(ch.0,1)

Serial I/O

(ch 3)

Fig. 1.1 Block Diagram (MB90M405)

Table des matières

Autres manuels Fujitsu Microcontrôleur

Fujitsu

Fujitsu MB95630H Series Manuel utilisateur

Fujitsu

Fujitsu MB89140 Series Manuel utilisateur

Fujitsu

Fujitsu MB95200 Series Manuel utilisateur

Fujitsu

Fujitsu MB86R01 Instructions d'installation et d'utilisation

Fujitsu

Fujitsu FR Series Instructions d'installation et d'utilisation

Fujitsu

Fujitsu F2MC-8L Series Manuel utilisateur

Fujitsu

Fujitsu MB95200H Series Manuel utilisateur

Fujitsu

Fujitsu F2MC-8FX Series Manuel utilisateur

Fujitsu

Fujitsu MB90335 Series Manuel utilisateur

Fujitsu

Fujitsu ALL FR 460 Series Instructions d'installation et d'utilisation

Fujitsu

Fujitsu F2MC-8FX Series Manuel utilisateur

Fujitsu

Fujitsu F2MC-8L Family series Manuel utilisateur

Fujitsu

Fujitsu ALL Series Instructions d'installation et d'utilisation

Fujitsu

Fujitsu UTY-TFNXZ1 Manuel de service

Fujitsu

Fujitsu MB88121 SERIES Instructions d'installation et d'utilisation

Fujitsu

Fujitsu MB904 Series Instructions d'installation et d'utilisation

Fujitsu

Fujitsu FR Series Instructions d'installation et d'utilisation

Fujitsu

Fujitsu F2MC-8L Series Manuel utilisateur

Fujitsu

Fujitsu F2MC-8FX MB95200H/210H Series Instructions d'installation et d'utilisation

Fujitsu

Fujitsu F2MC-FR Series Instructions d'installation et d'utilisation

Fujitsu

Fujitsu F2MC-16LX Series Manuel utilisateur

Fujitsu

Fujitsu MB91260B Series Manuel utilisateur

Fujitsu

Fujitsu F2MC-16L Series Manuel utilisateur

Fujitsu

Fujitsu F2MC-8FX MB95200H/210H Series Instructions d'installation et d'utilisation

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Novatek

Novatek NT6861 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur
