Developer’s Manual for the 467 / GDC Board

Summary

This manual provides detailed technical information for system architects, hardware and

software developers, who wor with the 467 / GDC board version PA3 for evaluation and

development purpose.

Enclosures

None.

Product nformation

The 467 / GDC board is populated with the 32-bit CPU MB91F467DAPFV, Flash memory,

SDRAM, SRAM, interfaces as UART, Ethernet, CAN, USB, SD memory card, GPIOs, video

inputs and outputs and an interface for different GDC modules.

Up to now two GDC modules are available for this board, a module with the MINT and a

module with the LIME. For details see the manuals for these modules.

Preliminary 4(36)

Prepared Document Number

Manfred Ortmann

Approved Chec ed Date Revision Storage

2008-05-14 PA 3.5 Mycable01

Revision History

Version Date Sign Description

PA 3.1 2008-03-25 mo Create this document

PA 3.2 2008-04-09 mo 2.2.3 CPU – Mode pin description added

PA 3.3 2008-05-05 mo 2.2.3 CPU – Internal comment removed

PA 3.4 2008-05-06 mo 2.2.3 CPU – Mode pin description corrected

PA 3.5 2008-05-14 mo Product name

Contact nformation

mycable GmbH

Michael Carstens-Behrens

( hardware and commercial )

Email [email protected]

Tel. +49 4321 55956 55

Preliminary 5(36)

Prepared Document Number

Manfred Ortmann

Approved Chec ed Date Revision Storage

2008-05-14 PA 3.5 Mycable01

Table of Contents

1 OVERV EW.................................................................................................................... 6

1.1 Manual Scope........................................................................................................ 6

1.2 Putting into Operation............................................................................................. 6

2 467 / GDC BOARD..................................................................................................... 7

2.1 System Architecture............................................................................................... 7

2.2 Function Units........................................................................................................ 9

2.2.1 Power Supply............................................................................................... 10

2.2.2 Reset........................................................................................................... 10

2.2.3 CPU............................................................................................................. 11

2.2.4 Graphic Display Controller ( GDC ) Module.................................................. 14

2.2.5 Serial Ports................................................................................................... 19

2.2.6 Ethernet........................................................................................................ 20

2.2.7 Universal Serial Bus ( USB )........................................................................ 21

2.2.8 CAN Interfaces............................................................................................. 22

2.2.9 Video Inputs................................................................................................ 24

2.2.10 Video Outputs............................................................................................. 25

2.2.11 Buttons....................................................................................................... 29

2.2.12 LEDs......................................................................................................... 29

2.2.13 GPIOs ...................................................................................................... 30

2.2.14 Secure Digital ( SD ) Memory Card Interface............................................. 32

2.3 Hardware Variants................................................................................................ 33

2.4 Placement of Components................................................................................... 34

2.5 Mechanical Dimensions........................................................................................ 36

Preliminary 6(36)

Prepared Document Number

Manfred Ortmann

Approved Chec ed Date Revision Storage

2008-05-14 PA 3.5 Mycable01

1 Overview

1.1 Manual Scope

This manual provides detailed technical information about the 467 / GDC board for system

architects, hardware and software developers covering:

•System architecture description and users manual

•Hardware architecture

•Mechanical information

It is the engineer’s reference for evaluation, system development and prototyping based on the

module. This document covers all available hardware versions regarding their configuration

options and revision state.

1.2 Putting into Operation

The 467 / GDC board can be used without GDC module.

But do not plug the GDC module if the power supply is

switched on !

Under this condition circuits can be damaged !

Details for power supply connection see chapter power supply.

Preliminary 7(36)

Prepared Document Number

Manfred Ortmann

Approved Chec ed Date Revision Storage

2008-05-14 PA 3.5 Mycable01

2 467 / GDC Board

2.1 System Architecture

The system architecture of the 467 / GDC board is shown in picture 2-1.

Pic. 2-1: 467 / GDC board bloc diagram

Preliminary 8(36)

Prepared Document Number

Manfred Ortmann

Approved Chec ed Date Revision Storage

2008-05-14 PA 3.5 Mycable01

Picture 2-2: 467 / GDC board top side

Picture 2-3: 467 / GDC board bottom side

Preliminary 9(36)

Prepared Document Number

Manfred Ortmann

Approved Chec ed Date Revision Storage

2008-05-14 PA 3.5 Mycable01

2.2 Function Units

Overview in the available interfaces:

–10/100 Ethernet

–2x serial ports

–2x CAN

–DVI-I

–Power supply

–Video Input

–USB

–GPIOs

–Video Output

–SD Memory Card Slot

–GDC module interface

Preliminary 10(36)

Prepared Document Number

Manfred Ortmann

Approved Chec ed Date Revision Storage

2008-05-14 PA 3.5 Mycable01

2.2.1 Power Supply

Connect the 467 / GDC board with a power supply between 6 and 25 V DC and approximate 10

Watt at connector X100.

Be aware to use the correct polarity as shown in picture 2-4.

Pic. 2-4: Polarity of the 467 / GDC board power supply connector

A protection against wrong polarity ( D109 ) and overcurrent ( F100 ) is implemented but a too

high current can damage the power supply or can produce great heat !

Do not plug the GDC module when the power supply is on !

The required voltages + 3.3 V and + 5.0 V will be regulated from the dual switching power

regulator LT1940EFE-PBF from Linear Technologies ( U100 ) on the board.

2.2.2 Reset

The triple processor supervisor TPS3307-33DGN from Texas Instruments ( U102 ) generates

a power-on reset and monitors the + 3.3 and + 5.0 V power supply.

Also if the reset button SW100 will be pressed the supervisor circuit generates a reset.
