FS S1900-8TP Manuel utilisateur
S1900-8TP
ETHERNET UNMANAGED POE SWITCH
ETHERNET UNMANAGED POE SWITCH
SWITCH POE ETHERNET NON GÉRÉ
Quick Start Guide V1.1
Quick-Start Anleitung
Guide de Démarrage Rapide
S1900-8TP PoE+
PWR
Left LED: Link/Act Mode Right LED: PoE Mode
1 2 3 4 5 6 7 8
Introduction
Accessories
S1900-8TP
Thank you for choosing S1900-8TP switch. This guide is designed to familiarize you with the layout of
the switch and describes how to deploy the switch in your network.
Grounding Cable x1
1
EN
S1900-8TP PoE+ PWR
Left LED: Link/Act Mode Right LED: PoE Mode
1 2 3 4 5 6 7 8
M3 Screw x8
Power Cord x1
Rubber Pad x4 Mounting Bracket x2
Grounding Screw x1
Front Panel Ports
Front Panel LEDs
Hardware Overview
Description
Ports
RJ45/PoE 10/100/1000BASE-T ports for Ethernet connection. All ports support PoE function.
RJ45/PoE
Green
PWR
RJ45
PoE
Switch is powered on.
Power supply is absent or abnormal.
10/100/1000BASE-T port is linked.
The RJ45 port is transmitting or receiving packets at
10/100/1000Mbps.
O
Green
Blinking Green
DescriptionStatusLEDs
Port is not linked.
Connected PoE PD device, working properly.
O
Yellow
No PoE PD device connected or no power supplied.O
2
EN
S1900-8TP PoE+ PWR
Left LED: Link/Act Mode Right LED: PoE Mode
1 2 3 4 5 6 7 8
S1900-8TP PoE+ PWR
Left LED: Link/Act Mode Right LED: PoE Mode
1 2 3 4 5 6 7 8
PWR
RJ45
PoE
S1900-8TP
PoE+
PWR
Left LED: Link/Act Mode Right LED: PoE Mode
1 2 3 4
Back Panel
Power Supply Fan Port
Grounding Point
3
EN
100-240V AC
50 / 60HZ
Installation Requirements
Site Environment:
Do not operate it in an area that exceeds an ambient temperature of 45°C.
The installation site must be free from leaking or dripping water, heavy dew, and humidity.
Ensure rack and working platforms are well earthed.
The installation site must be well ventilated. Ensure that there is adequate air ow around the
switch.
Be sure that the switch is level and stable to avoid any hazardous conditions.
Do not install the equipment in a dusty environment.
Desktop mounting: ESD bracelet (or ESD gloves)
Rack mounting: ESD bracelet (or ESD gloves), Phillips screwdriver, M6 Screws, Standard-sized 19"
wide rack with a minimum of 1U height available
Before you begin the installation, make sure that you have the following:
4 5 6 7 8
4
EN
Desk Mounting
Rack Mounting
1. Attach four rubber pads to the bottom.
2. Place the chassis on a desk.
1. Secure the mounting brackets to the two sides of the switch with eight M3 screws.
Mounting the Switch
S1900-8TP
PoE+
PWR
LeftLED: Link/Act Mode RightLED: PoE Mode
1 2 3 4 5 6 7 8
100-240V AC
50 / 60HZ
5
EN
Grounding the Switch
2. Attach the switch to the rack using the screws and tighten it.
1. Connect one end of the grounding cable to a proper earth ground, such as the wall in which the
switch is mounted.
2. Secure the grounding lug to the grounding point on the back of the switch with the washer and
screws.
CAUTION: The earth connection must not be removed unless all supply connections have
been disconnected.
S1900-8TP PoE+
PWR
Left LED: Link/Act Mode Right LED: PoE Mode
1 2 3 4 5 6 7 8
100-240V AC
50 / 60HZ
6
EN
1. Plug the AC power cord into the power port on the back of the switch.
2. Connect the other end of the power cord to an AC power source.
1. Connect an Ethernet cable to the RJ45 port of a computer, printer, network storage, or other
network devices.
2. Connect the other end of the Ethernet cable to the RJ45 port of the switch.
Connecting the Power
WARNING: Do not install power cable while the power is on.
Connecting the RJ45 Ports
7
EN
1. Connect an Ethernet cable to the PD devices, such as internet phone, network camera, wireless
access point device.
2. Connect the other end of the Ethernet cable to the RJ45 port of the switch.
Connecting the PD
FS ensures our customers that any damage or faulty items due to our workmanship, we will oer a
free return within 30 Days from the day you receive your goods. This excludes any custom made items
or tailored solutions.
Support and Other Resources
Download https://www.fs.com/download.html
Help Center https://www.fs.com/service/help_center.html
Contact Us https://www.fs.com/contact_us.html
Product Warranty
Warranty: S1900-8TP Switch enjoys 2 years limited warranty against defect in
materials or workmanship. For more details about warranty, please check at
https://www.fs.com/policies/warranty.html
Return: If you want to return item(s), information on how to return can be found at
https://www.fs.com/policies/day_return_policy.html
2
8
EN
Einführung
Zubehör
S1900-8TP
Vielen Dank, dass Sie sich für den S1900-8TP Switch entschieden haben. Diese Anleitung soll Sie mit
dem Aufbau des Switches vertraut machen und beschreibt, wie Sie den Switch in Ihrem Netzwerk
einsetzen.
Erdungskabel x1
S1900-8TP PoE+ PWR
Left LED: Link/Act Mode Right LED: PoE Mode
1 2 3 4 5 6 7 8
M3-Schraube x8
Netzkabel x1
Gummipad x4 Montagebügel x2
Erdungsschraube x1
9
DE
