Frigidaire FGF358CGSC Manuel utilisateur

FACTORY PARTS CATALOG

GAS RANGE

P.O. Box 212378

Augusta, Georgia 30917

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FGF358CGSC FGF358CG WHITE/WHITE USA

Publication No.

5995313441

980731

-EN/SERVICE /VLM

369

WIRING DIAGRAM # - 316002169

OWNER’S GUIDE # - 316000272

INSTALLATION GUIDE # - 316002989 GAS - RANGE

FGF358CGSC

10/98 2

Publication number

5995313441 FGF358CGSC

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

# - Fast Moving Parts

* - Non Illustrated Parts 3 6/98

Publication number

FGF358CGSC 5995313441

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

POS. NO PART NO DESCRIPTION

* 316002169 Wiring diagram

* 316002989 Instructions,installation

* 316021108 Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 Screw-8-18x1/2 Tr Sqd black

* 316071902 Gasket-edge

1 316028701 Shield-backguard,rear wall

2A 316053802 Shield-backguard,inner/top

11 316083722 Trim-wrapper gas white w/hole,textured ,

white

14A 316022500 Light/Lamp, indicator , WARMER ZONE ,

125 V

15 316023108 Support-backguard,RH

15A 316023109 Support-backguard,LH

19 316100524 Panel-control, metal,white

20 # 316101000 Clock/Timer,electronic

20* 316101502 Overlay-clock

23 316100300 Bracket-clock mtg

24 # 316005607 Switch-rocker,oven light ,white

31 316095601 Knob-warmer,white

36 316109503 Knob-top valve,white

40 316086822 Panel-manifold

42 316055201 Trim-vent

46 316040201 Lens-light/lamp,indicator ,red

54B 316095500 Switch-warmer,infinite ,drawer/zone

56 316074907 Deflector-flue,black

69 5303292005 Screw-switch mounting

10/98 4

Publication number

5995313441 FGF358CGSC

CAUTION: Use the part number on all orders, not the position number.

BURNER

# - Fast Moving Parts

* - Non Illustrated Parts 5 10/98

Publication number

FGF358CGSC 5995313441

CAUTION: Use the part number on all orders, not the position number.

POS. NO PART NO DESCRIPTION

* 5303271648 Screw,wafer hd sq dr ,8-18AB x 1/2

1 # 316066201 Manifold Pipe

2 # 5303935130 Valve-top burner

2* 316048200 Screw-top valve mtg,hex washer head ,

1/4-20 x 0.31,w/gasket

3 # 316103600 Switch-ignitor,(4)

4 # 316059612 Tube-burner,red ,RF

5 # 316059613 Tube-burner,green ,LF

6 # 316059614 Tube-burner,nat. ,RR

7 # 316059615 Tube-burner,black ,LR

8 # 5303280394 Spark Module

8* 5303289034 Harness-wiring,module/igniter

10 # 5303935025 Burner Assy-top,sealed ,small ,9000 BTU

11 316011200 Ignitor-top burner,(4) ,w/mtg bracket

13 # 316065005 Tube,aluminum ,rgltr to manf ,

with fittings

14 # 316091706 Regulator-pressure

14* 316021104 Screw-regulator/brkt,hex ,8-18 x 3/8 ,

nick, 3

15 316091600 Bracket-regulator

16 # 316065003 Tube-valve to rgltr,3/8

17 # 5303208499 Valve-safety,dual

18 # 3131290 Burner-oven

19 # 5303935066 Ignitor-oven

20 3131284 Baffle-oven burner

21 5303013272 Nut,hex head sems

22 # 316065002 Tube-valve to mixer

23 # 316087900 Burner-broiler

24 # 316070400 Mixer Elbow

25 5303210379 Baffle-broiler

26 # 5308067970 Ignitor-broiler

37 316069301 Screw-burner mtg

44 5303210090 Orifice-top burner,small

45 316011100 Screw-ignitor mtg,self-tapping ,M3x5.8

46 316074700 Plate-burner tube

BURNER

10/98 6

Publication number

5995313441 FGF358CGSC

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 7 10/98

Publication number

FGF358CGSC 5995313441

CAUTION: Use the part number on all orders, not the position number.

BODY

POS. NO PART NO DESCRIPTION

* 316021108 Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

1 316029412 Back-main

2 3131314 Shield-oven top

3 316081028 Panel-bodyside,white ,RH

3* 316081029 Panel-bodyside,white ,LH

4 316011914 Burner Box

5 5303203397 Screw-leveling

5* 3934058 Anti-tip Kit

5* 316078600 Screw,anti-tip ,(4)

5A 5303288460 Nut,T-type ,leveling screw

6 316067902 Rack-oven

7 316007002 Hinge-oven door,(2)

8 5303212540 Panel-oven bottom

8* 316064600 Support-oven bottom

9 316073800 Pan-broiler

10 3205234 Insert-broiler pan

12 # 316027701 Switch-oven light

13 316026800 Rod-light switch /door

14 3014073 Socket-light/lamp,oven

15 5303013071 Light Bulb/Lamp

16 08011086 Lens-light/lamp,glass ,oven

17 316087500 Retainer-lens

18 # 316036300 Latch-door

21 3014099 Spacer-bodyside,(8)

25A 316092300 Shield-warmer,upper

28 3011813 Clip-wire,bodyside

30 316059200 Bracket-main top,RH

30A 316059201 Bracket-main top,LH

33 316014401 Shield,rear wall

35 08067965 Gasket-flue

36 5303272844 Flue

37 # 316111200 Probe-oven temp

38 316051700 Shield-heat

38A 316097100 Insulator,shield

39 # 3131425 Cord-electric power

40 3200836 Shield-heat baffle

40* 5303288570 Screw-heat shield,hd shldr sqdr ,

8-18 X 1/2

41 3131570 Cover-hinge cutout

42 5303288578 Shield-bake burner

43 3131732 Screw-oven bottom,8-18 x 1.438

44 3131903 Bumper-door/drawer,rubber

49 3051124 Clip-spring mtg

53 5303288579 Shield-main front

53A 08067992 Shield-insulation

55 316107800 Shield-flue

58A 316047708 Insulation,oven wrapper

58B 316054200 Insulation,oven back

58G 08067973 Insulation,main front

72 5303285692 Cover-light/switch rod

77 316105500 Glide-warmer,outer/RH & LH ,(2)

88 316026400 Rod-latch,auto

89 # 316028103 Motor-latch/lock

155 316095201 Shield-drawer,front warmer

10/98 8

Publication number

5995313441 FGF358CGSC

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

# - Fast Moving Parts

* - Non Illustrated Parts 9 10/98

Publication number

FGF358CGSC 5995313441

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

POS. NO PART NO DESCRIPTION

* 316021108 Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 Screw-8-18x1/2 Tr Sqd black

* 316021112 Screw-8-18x1/2 Tr Sqd White

* 5303280311 Screw,waf hd sdr ,10-32 x 5/16 ,(2)

1 316094601 Drawer-warmer

2 316092901 Liner,drawer

4 316056201 Panel-drawer,white

10 5303280308 Screw-handle mtg,wafer head ,10-24T x 2

13 316105600 Glide-drawer,rear,RH

13A 316105601 Glide-drawer,rear,LH

14 3206216 Plug-button,glide

16 5303301546 Main Top,white

19 # 316011409 Pan-burner,gray ,(4)

20 # 316085304 Grate,(4)

21 316098508 Cap-burner,small ,gloss gray

39 316026106 Handle-drawer,white

44 3131903 Bumper-door/drawer,rubber

80 316109700 Seal-door,warmer drawer

81 # 316093100 Element,warmer drawer

82 316093200 Bracket-mounting,warmer element

83 316093300 Shield-terminal,warmer

84 316093500 Thermo disc,warmer

85 316093600 Rack,warmer drawer

86 316095800 Clip-hold down,warmer element

87 316091900 Base-warmer

10/98 10

Publication number

5995313441 FGF358CGSC

CAUTION: Use the part number on all orders, not the position number.

DOOR
