Freescale Semiconductor TWR-S12GN32 Manuel utilisateur

TOWER SYSTEMQuick Start Guide for TWR-S12GN32

TWR-S12GN32

Scalable platform for

automotive applications

TOWER SYSTEM

Get to Know the TWR-S12GN32

TWR-S12GN32

Freescale Tower System

The TWR-S12GN32 module is a single board computer as well as

part of the Freescale Tower System, a modular development platform

that enables rapid prototyping and tool re-use through reconfigurable

hardware. Elevate your design to the next level and begin constructing

your Tower System today.

Secondary

Connector

Headers

LIN Connectors

Primary

Connector

Optional BDM

Connecctor

On-Board

OSBDM

Optional External

Power Supply

Serial Port

Potentiometer

Push Buttons

LEDs

TOWER SYSTEMQuick Start Guide for TWR-S12GN32

Install Software

and Tools

•InstallCodeWarriorDevelopment

Studio for S12 v5.1 or later

A30evaluationlicenseofCodeWarriorisincluded

ontheDVDforyourconvenience.Forupdates,

please visit freescale.com/TWR-S12GN32.

Connect the USB Cable

ConnectoneendoftheUSB

cabletothePCandtheotherendtothe

mini-BconnectorontheTWR-S12GN32

board.AllowthePCtoautomatically

configuretheUSBdriversifneeded.

• S12GN32seriesmicrocontroller

(48-pin LQFP)

• On-boardJTAGconnectionviaopen

sourceOSBDMcircuitusingthe

MPC9S08JMmicrocontroller

See pemicro.com/osbdm for

source code

• High-speedCANinterface

•LINinterface

•PotentiometerwithLPfilter

•LEDindicators

•RS-232serialcommunication

interface

Step-by-Step Installation Instructions

TWR-S12GN32 Features

In this Quick Start Guide, you will learn how to set up the

TWR-S12GN32 board and run the default exercise.

STEP

Using the

Example Project

The pre-loaded example utilizes the TWR-

S12GN32’s push button switches, serial

communicationsinterfaceandLEDs.

Oncetheboardispluggedinyoucan

controlthebankoffourLEDsbypushing

one of the four on-board push buttons

(SW1–4).Connecttheincludedserial

adaptertoJ8andstartaterminalinyour

computer(9600bauds,eightdatabits,

one stop bit, no parity). You should see

the keystrokes echoed by the device.

Learn More About the

S12GN32

Release notes and documentation are

availableontheDVDandat

freescale.com/S12G.

• The Processor Expert graphical

initialization software included in your

CodeWarriorinstallationwillhelpreduce

your time to market

• CodeWarriorforS12withexamples

TOWER SYSTEM

STEP

TOWER SYSTEMQuick Start Guide for TWR-S12GN32

TWR-S12GN32 Jumper Options

The following is a list of all jumper options.

Jumper Option Setting Description

JP2 Option Header

1-2 Connect PAD4 pin to SW1

3-4 Connect PAD5 pin to SW2

5-6 Connect PAD6 pin to SW3

7-8 Connect PAD7 pin to SW4

9-10 Connect PAD10 to POT

11-12 Connect PT2 pin to LED1

13-14 Connect PT3 pin to LED2

15-16 Connect PT4 pin to LED3

17-18 Connect PT5 pin to LED4

JP1 COM_EN

3-5, 4-6 Connects target MCU SCI port to RS-232 PHY to

enable LIN bus communications

1-3, 2-4 Connects target MCU SCI port to LIN PHY to enable

LIN bus communications

J3 BDM_PORT 1-2 Ground

3-4 Reset

JP401 Bootloader 1-2 Not populated. Enables bootloader at startup.

TOWER SYSTEM

TWR-S12GN32 Jumper Options

(continued from previous page)

The following is a list of all jumper options.

Jumper Option Setting Description

JP4 PWR_SEL

1-2 Selects the board to be powered from the 3.3V

elevator card rail

3-4 Selects the board to be powered from the USB 5V

(OSBDM)

5-6 Selects the board to be powered from externally

provided power source on E1 and E2

JP3 LIN_PWR 1-2 Connect LIN bus to +V input

3-4 Enables LIN Master mode functionality

TOWER SYSTEMQuick Start Guide for TWR-S12GN32

TOWER SYSTEM

Freescale,theFreescalelogoandCodeWarrioraretrademarks

orregisteredtrademarksofFreescaleSemiconductor,Inc.

Reg.U.S.Pat.&Tm.Off.ProcessorExpertisatrademarkof

FreescaleSemiconductor,Inc.Allotherproductorservice

names are the property of their respective owners.

©2011FreescaleSemiconductor,Inc.

DocNumber:TWRS12GN32QSG/REV0

AgileNumber:926-26647/REVA

To learn more, please visit freescale.com/Tower or freescale.com/TWR-S12GN32.
