CHAPTER 1

INTRODUCTION

This user's manual explains connection, configuration, and operation information specific to

the HC05P3EM Emulator Module (P3EM). The P3EM makes possible emulation and

debugging of target systems based on these microcontroller units (MCUs):

MC68HC05P3 MC68HC705P3

The P3EM can be part of two development systems. This chapter describes those systems and

explains the layout of the P3EM.

1.1 DEVELOPMENT SYSTEMS

Your P3EM can be part of two Motorola development tools: the HC05 Motorola Modular

Development System (MMDS05) or the M68HC05EVS Evaluation System (HC05EVS).

1.1.1 Motorola Modular Development System (MMDS05)

The MMDS05 is an emulator system that provides a bus state analyzer and real-time memory

windows. The unit's integrated design environment includes an editor, an assembler, user

interface, and source-level debug. A complete MMDS05 consists of:

•a station module — the metal MMDS05 enclosure, containing the control board and

the internal power supply. Most system cables connect to the MMDS05 station module.

(The cable to an optional target system, however, runs through an aperture in the station

module enclosure to connect directly to the emulator module.)

•an emulator module (EM) — such as the P3EM: a printed circuit board that enables

system functionality for a specific set of MCUs. The EM fits into the station module

through a sliding panel in the enclosure top. The EM has a connector for the target

cable.

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC05P3EM/D 3-6 MOTOROLA

•two logic clip cable assemblies — twisted-pair cables that connect the station

module to your target system, a test fixture, a clock, or any other circuitry useful for

evaluation or analysis. One end of each cable assembly has a molded connector, which

fits into station-module pod A or pod B. Leads at the other end of each cable terminate

in female probe tips. Ball clips come with the cable assemblies.

•a 9-lead RS-232 serial cable — the cable that connects the station module to the

host computer RS-232 port.

•a 9- to 25-pin adapter — a molded assembly that lets you connect the 9-lead cable to

a 25-pin serial port.

•system software — software, on 3-1/2 inch diskettes.

•MMDS05 documentation — an MMDS05 operations manual (MMDS05OM/D) and

the appropriate EM user's manual.

As mentioned, your P3EM gives the MMDS05 the ability to emulate the MC68HC(7)05P3

MCU(s). By substituting a different EM, you can enable your MMDS05 to emulate an MCU

of a different series. (Your Motorola representative can explain all the EMs available.)

Chapter 2 explains how to configure and use your P3EM as part of an MMDS05 system. For

information about MMDS05 software or the station module, see the MMDS05 operations

manual. For layout and configuration information pertaining to a different EM, see the

corresponding EM user's manual.

1.1.2 M68HC05EVS Evaluation System (HC05EVS)

An HC05EVS is an economical, two-board tool for designing, debugging, and evaluating

target systems based on an MC68HC05 MCU. A complete HC05EVS consists of:

•a platform board (PFB) — the bottom board, which supports the emulator module.

The platform board has connectors for power and for the terminal or host computer.

•an emulator module (EM) — such as the P3EM: a printed circuit board that enables

system functionality for a specific set of MCUs. The EM fits onto the PFB. The EM

has connectors for a target cable and for a cable to a logic analyzer.

•an RS-232 serial cable — the cable that connects the PFB to the host computer RS-

232 port.

•system software — software, on 3-1/2 inch diskettes.

•HC05EVS documentation — an HC05EVS operations manual (HC05EVSOM/D)

and the appropriate EM user's manual.

As mentioned, your HC05P3 EVS emulates the MC68HC(7)05P3 MCU(s). By substituting a

different EM, you can enable your HC05EVS to emulate an MCU of a different series. (Your

Motorola representative can explain all the EMs available.)

Chapter 3 explains how to configure and use your P3EM as part of an HC05EVS system. For

information about HC05EVS software or the platform board, see the HC05EVS operations

manual. For layout and configuration information pertaining to a different EM, see the

corresponding EM user's manual.

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC05P3EM/D 3-7 MOTOROLA

1.2 EM LAYOUT

Figure 1-1 shows the layout of the P3EM. Jumper headers J1 and J2 let the user select the

clock source; on board oscillator, target oscillator or MMDS05 oscillator. Note that the target

oscillator requires a single clock supply, it is not suitable to connect a crystal external to the EM

board. Jumper J3 determines the logic direction of the RESET signal at the target connector.

Jumper J4 selects the correct sense of the CPU LIR signal depending on the resident MCU.

Connector P4 is the interface to a target system. This connector can either use a separately

supplied target cable from Motorola or a user-supplied ribbon cable to DIP head. If you install

the P3EM in the MMDS05 station module, the target cable passes through the slit in the station

module enclosure. Connector P1 connects to a logic analyzer. (Connector P1 has more

significance for an EVS system, as an MMDS05 system includes a bus analyzer.) Expansion

header connectors P2 and P3 connect together the EM and the control board (for an MMDS05)

or the EM and the platform board (for an EVS).

P3P2

1 1

J1 J2

MC68HC(7)05P3

Figure 1-1. HC05P3 Emulator Module

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC05P3EM/D 3-8 MOTOROLA

1.3 CONNECTOR P4 PIN ASSIGNMENTS

Figure 1-2 shows the pin assignments for connector P4. The italic numbers correlate the P4

pins with the pins of your MCU. For signal descriptions, consult the technical data book for

the specific MCU.

GND

Vdd Detect

PA0

PA1

PA2

PA3

PA4

PA5

PA6

PA7

PC0/TCAP

PC1/TCMP

PC2

PC3

GND

IRQ*

RESET*

OSC1

PB7

PB6

PB5

PB4

PB3

PB2

PB1

PB0

PC5

PC4

GND

Figure 1-2. Connector P4 Pin Assignments

As connector P1 has more importance to an HC05EVS than to an MMDS05, pin assignments

for connector P1 are in Chapter 3.

To configure your P3EM for use as part of an MMDS05, follow the instructions of Chapter 2.

To configure your P3EM for use as part of an HC05EVS, follow the instructions of Chapter 3.

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC05P3EM/D 3-9 MOTOROLA

CHAPTER 2

MMDS05 CONFIGURATION AND OPERATION

This chapter explains how to configure and use your P3EM as part of an MMDS05. For other

parts of system installation or configuration, see the MMDS05 operations manual

(MMDS05OM/D). (If you will use your P3EM as part of an HC05EVS system, go to Chapter

3 for corresponding information.)

Paragraph 2.1 explains how to set P3EM jumper headers. Paragraph 2.2 explains

considerations pertaining to the MCU you emulate. Paragraph 2.3 explains remaining system

installation.

Note that you can configure a P3EM already installed in the MMDS05 station module

enclosure. To do so, switch off station-module power, remove the panel, then follow the

guidance of this chapter.

CAUTION

Be sure to switch off power if you reconfigure an installed EM. Reconfiguring

EM jumper headers with power left on can damage MMDS05 circuits.

2.1 SETTING P3EM JUMPER HEADERS

Your P3EM has four jumper headers, J1 through J4. Paragraphs 2.1.1., 2.1.2. and 2.1.3

explain how to configure these headers.

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC05P3EM/D 3-10 MOTOROLA

2.1.1 Clock Source Select Headers (J1 and J2)

Jumper headers J1 and J2 determine the source of the clock signal. The diagram below shows

the factory configuration: the fabricated jumpers select the P3EM canned oscillator clock

source.

TRGT

MMDS

(2)

(3)

FABRICATED

JUMPERS

(J2)

XTAL

(2)

(3)

Alternatively, you may use a clock source originating from the control board. To do so,

reposition the J1 jumper between pins 1 and 2, then use the MMDS05 OSC command to select

a frequency. To use a clock source originating from the target system reposition the J3 jumper

between pins 1 and 2.

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

Table des matières

Autres manuels Freescale Semiconductor Matériel informatique

Freescale Semiconductor

Freescale Semiconductor 802.15.4/Zigbee Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor 1322x-USB Dongle Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor Target Interface MMDS0508 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MPC850 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor FRDM-KE06 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MTRCKTSPS5604P Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor NXP 56F8014 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor e200z3 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor SC140 DSP Core Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor DSP56374 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor EVBCRTOUCH Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor PowerQUICC III Instructions d'installation et d'utilisation

Freescale Semiconductor

Freescale Semiconductor TWR-LS1021A Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MC68HC908MR16 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor i.MX35 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MPC8349EA PowerQUICC II Pro Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MPC8260 PowerQUICC II Family Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor USB-KW24D512 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor TWR-PXD20 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor TWR-VF65GS10 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor i.MX31 PDK 1.4 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MPC8309 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MSC8156EVM Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor i.MX 6SoloLite Linux Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
