Fluke 572 Manuel utilisateur

572/574/576

Precision Infrared Thermometers

March 2005

All product names are trademarks of their respective companies.

Getting Started

This booklet includes the de-

scription of the basic functions

of the units and the software.

The complete manual is on the

companion CD.

LIMITED WARRANTY AND

LIMITATION OF LIABILITY

This Fluke product will be free from defects in

material and workmanship for one year from the

date of purchase. This warranty does not cover

fuses, disposable batteries, or damage from

accident, neglect, misuse, alteration, contami-

nation, or abnormal conditions of operation or

handling. Resellers are not authorized to extend

any other warranty on Fluke’s behalf. To obtain

service during the warranty period, contact your

nearest Fluke authorized service center to obtain

return authorization information, then send the

product to that Service Center with a description

of the problem.

THIS WARRANTY IS YOUR ONLY REMEDY. NO

OTHER WARRANTIES, SUCH AS FITNESS FOR

A PARTICULAR PURPOSE, ARE EXPRESSED

OR IMPLIED. FLUKE IS NOT LIABLE FOR ANY

SPECIAL, INDIRECT, INCIDENTAL OR CONSE-

QUENTIAL DAMAGES OR LOSSES, ARISING

FROM ANY CAUSE OR THEORY. Since some

states or countries do not allow the exclusion or

limitation of an implied warranty or of incidental

or consequential damages, this limitation of liabi-

lity may not apply to you.

572/574/576

Warning

A Warning identiﬁes conditions and actions that pose ha-

zards to the user. To avoid electrical shock or personal injury,

follow these guidelines:

• Do not point laser directly at eye or indirectly off

reﬂective surfaces.

• Before using the thermometer inspect the case. Do not

use the thermometer if it appears damaged. Look

for cracks or missing plastic.

• Replace the batteries as soon as the battery indicator

two or less segments.

• Do not use the thermometer if it operates abnormally.

Protection may be impaired. When in doubt, have the

thermometer serviced.

• Do not operate the thermometer around explosive gas,

vapor, or dust. (see the special warning for the NI model)

• Do not connect the optional external probe to live

electrical circuits.

• To avoid a burn hazard, remember that highly reﬂective

objects will result in lower than actual temperature

measurements.

• Do not use in a manner not speciﬁed by this manual or the

protection supplied by the equipment may be impaired.

Caution

To avoid damaging the thermometer or the equipment under

test protect them from the following:

• EMF (electro-magnetic ﬁelds) from arc welders,

induction heaters, etc.

• Static electricity

• Thermal shock (caused by large or abrupt

ambient temperature changes- allow 30 minutes

for thermometer to stabilize before use).

• Do not leave the thermometer on or near

objects of high temperature.

Safety Information

572/574/576

Table of Contents

Introduction ............................................................ 6

Warning for the Model 574 NI ................................ 7

Symbols and Safety Markings ............................... 8

Laser Warning and Serial Number Labels .............. 9

Features and Requirements ................................... 10

Delivery Content ..................................................... 11

Batteries ................................................................. 12

Measurement .......................................................... 13

Field of View and Emissivity ................................... 14

Spot Size ................................................................ 15

Additional Functions ............................................... 16

DIP Switches .......................................................... 17

Hardware and Software Setup ............................... 18

Using the Camera (Model 576) ............................... 20

Uploading Data and Pictures (Model 576) ............. 22

Troubleshooting ...................................................... 23

Maintenance ........................................................... 24

CE Conﬁrmity ......................................................... 25

Speciﬁcation of the Thermometers ........................ 26

Speciﬁcation of the Camera (Model 576) ............... 27

Factory Defaults ..................................................... 28

572/574/576

The Fluke Models 572, 574, and 576 Infrared Thermo-

meters (“the thermometers”) are for non-contact tem-

perature measurement. These thermometers deter-

mine an object’s surface temperature by measuring

the amount of infrared energy radiated by the object’s

surface.

Contacting Fluke

To contact Fluke, call one of the following

telephone numbers:

USA: 1-888-44-FLUKE (1-888-443-5853)

Canada: 1-800-36-FLUKE (1-800-363-5853)

Europe: +31 402-675-200

Japan: +81-3-3434-0181

Singapore: +65-738-5655

Anywhere in the world: +1-425-446-5500

For USA Service: 1-888-99-FLUKE (1-888-993-5853)

Or, visit Fluke's Web site at www.ﬂuke.com

To register your product, visit register.ﬂuke.com

Introduction

572/574/576

Concerning Factory Mutual Approved

Nonincendive Devices:

Operation in Environments that Require

Nonincendive Devices

WARNING

IN HAZARDOUS LOCATIONS DO NOT use serial port con-

nections, change batteries or open serial port cover. To re-

duce risk of explosion in hazardous locations, use only Fluke

temp probe part 2432508 and do not use other accessories,

such as power supply and cables.

A nonincendive rating (NI) indicates that this infrared thermo-

meter has been tested to standards for preventing explosi-

ons in hazardous areas by limiting the ability of equipment

to ignite a speciﬁed ﬂammable gas or vapor-in-air mixture.

Nonincendive equipment is incapable of releasing sufﬁcient

electrical or thermal energy to ignite ﬂammable gases or

vapors under NORMAL operation and environmental condi-

tions.

This noncontact thermometer has a Factory Mutual Nonin-

cendive rating. The rating from this USA organization reads:

“Nonincendive, Class I, Division 2, Groups A, B, C, D; Class

I, Zone 2 IIC; T4 Ta = 50ºC when used with 1.5V alkaline

batteries.“

A Class I, Division 2 location is a location:

• where volatile ﬂammable liquids or ﬂammable gases

or vapors exist, but are normally conﬁned within

closed containers;

• where ignitable concentrations of gases, vapors or liquids

are normally prevented by positive mechanical

ventilation; or

• adjacent to a Class I, Division 1 location, where ignitable

concentrations might be occasionally communicated

• groups A, B, C, D refers to: Acetylene, Hydrogen,

Ethylene, and Propane.

Warning for the Model 574 NI

572/574/576



Symbol Explanation



Risk of danger. Important information. See

Manual.

Risk of danger. Important information. See

Manual.

Risk of danger. Important information. See



Hazardous voltage. Precedes warning



Warning. Laser.



Conforms to requirements of European Union

and European Free Trade Association (EFTA)

Conforms to requirements of European Union

and European Free Trade Association (EFTA)

Conforms to requirements of European Union

Celsius

Fahrenheit



Battery

Symbols and Safety Markings

572/574/576

Laser Warning and Serial Number Labels

572/574/576

Features and Requirements

Note! The factory default setting of your

unit is Centigrade. This can be changed into

Fahrenheit by switching the appropriate DIP

switch. See Chapter “DIP Switch Settings”.

Your thermometers include:

• Coaxial Laser sighting

• Adjustable emissivity

• High Alarm

• 7 Second Hold

• Trigger Lock

• Tripod Mount

• Graphic Display

• Low Alarm (574/576)

• MAX, MIN, DIF, AVG (574/576)

• Data Logger (574/576)

• Probe Jack (574/576)

• Companion Software (574/576)

• Digital Camera (576)

Requirements to use the software of the

thermometers (Models 574/576)

• 200 Mhz processor (400 Mhz

recommended)

• CD/DVD drive

• RS232 COM port (model 574)

• USB 1.1 - port (model 576)

• 15 MByte free diskspace on the

hard drive

The software works with Microsoft® Windows®

NT (for model 574 only), 2000, or XP.
