Fluke NFK-LAUNCH Series Manuel utilisateur

NFKx-LAUNCH English Instruction Sheet

06/15/06

Dimensions: 5.5" x 8.25"

Page 1

PN 1997795 September 2002, Rev. 2, 6/06

All product names are trademarks of their respective companies.

NFKx-LAUNCH

Launch Fiber

Instruction Sheet

The NFKx-LAUNCH launch fibers are used with the OF-500 OptiFiber™tester during

OTDR tests. Using a launch fiber lets the tester measure the loss of the first

connector in the cabling. You may also use a NFKx-LAUNCH fiber as a receive fiber.

Using a receive fiber lets the tester measure the loss of the last connector in the

cabling.

A launch fiber comes with the following:

•Instruction sheet

•Warranty registration card

Launch Fiber Models and Specifications

Model Zipper Color Specifications

NFK1-LAUNCH Gray 62.5/125 μm multimode launch fiber, 100 m,

SC/SC connectors with UPC polish

NFK2-LAUNCH Aqua 50/125 μm multimode launch fiber, 100 m,

SC/SC connectors with UPC polish

NFK3-LAUNCH Yellow 9/125 μm singlemode launch fiber, 130 m,

SC/SC connectors with UPC polish

NFK1-LAUNCH-ST Gray 62.5/125 μm multimode launch fiber, 100 m,

SC/ST connectors with UPC polish

NFK2-LAUNCH-ST Aqua 50/125 μm multimode launch fiber, 100 m,

SC/ST connectors with UPC polish

NFK3-LAUNCH-ST Yellow 9/125 μm singlemode launch fiber, 130 m,

SC/ST connectors with UPC polish

-continued-

Provided by www.AAATesters.com

NFKx-LAUNCH English Instruction Sheet

06/15/06

Dimensions: 5.5" x 8.25"

Page 2

Launch Fiber Models and Specifications (cont.)

Model Zipper Color Specifications

NFK1-LAUNCH-LC Gray 62.5/125 μm multimode launch fiber, 100 m,

SC/LC connectors with UPC polish

NFK2-LAUNCH-LC Aqua 50/125 μm multimode launch fiber, 100 m,

SC/LC connectors with UPC polish

NFK3-LAUNCH-LC Yellow 9/125 μm singlemode launch fiber, 130 m,

SC/LC connectors with UPC polish

NFK1-LAUNCH-FC Gray 62.5/125 μm multimode launch fiber, 100 m,

SC/FC connectors with UPC polish

NFK2-LAUNCH-FC Aqua 50/125 μm multimode launch fiber, 100 m,

SC/FC connectors with UPC polish

NFK3-LAUNCH-FC Yellow 9/125 μm singlemode launch fiber, 130 m,

SC/FC connectors with UPC polish

NFK2-LAUNCH-E2K Aqua 50/125 μm multimode launch fiber, 100 m,

SC/ E2000 connectors with UPC polish

NFK3-LAUNCH-E2K Yellow 9/125 μm singlemode launch fiber, 130 m,

SC/ E2000 connectors with APC polish

Safety Information

WWarning

To avoid possible eye damage caused by hazardous radiation, never look

directly into optical output connectors. Some sources produce invisible

radiation that can permanently damage your eyes.

Using the Launch Fiber

Figure 1 shows where to connect launch and fibers for OTDR tests. Always clean all

connectors before making connections.

To remove the launch and receive fibers’ losses and lengths from measurements, use

the tester’s launch fiber compensation function. See the OF-500 OptiFiber Users

Manual or the tester’s online help for details and additional information on launch

and receive fibers.

NFKx-LAUNCH English Instruction Sheet

06/15/06

Dimensions: 5.5" x 8.25"

Page 3

Launch

fiber OTDR port

Fiber under test

OF-500 OptiFiber tester

Patch

panel

Patch

panel

Receive fiber

(if used)

apc01f.eps

Figure 1. Launch and Receive Fiber Connections

Maintenance

Always clean and inspect the launch fiber connectors before making connections.

Use either of the following for cleaning:

•Lint-free swabs or wipes moistened with isopropyl alcohol

•Pre-moistened swabs or wipes approved for use on fiber connectors

Use a fiber microscope, such as the Fluke Networks OFTM-5352 FiberInspector™

Video Probe, to inspect fiber endfaces for damage. If a launch fiber endface is

damaged, you should replace the launch fiber as it may cause unreliable test results.

NFKx-LAUNCH English Instruction Sheet

06/15/06

Dimensions: 5.5" x 8.25"

Page 4

Contacting Fluke Networks

www.flukenetworks.com

[email protected]

+1-425-446-4519

•Australia: 61 (2) 8850-3333 or 61 (3) 9329 0244

•Beijing: 86 (10) 6512-3435

•Brazil: 11 3044 1277

•Canada: 1-800-363-5853

•Europe: +44-(0)1923 281 300

•Hong Kong: 852 2721-3228

•Japan: 03-3434-0510

•Korea: 82 2 539-6311

•Singapore: 65-6799-5566

•Taiwan: (886) 2-227-83199

•USA: 1-800-283-5853

Visit our website for a complete list of phone numbers.

LIMITED WARRANTY & LIMITATION OF LIABILITY

Fluke Networks mainframe products will be free from defects in material and

workmanship for one year from the date of purchase. Parts, accessories, product repairs

and services are warranted for 90 days, unless otherwise stated. Ni-Cad, Ni-MH and Li-Ion

batteries, cables or other peripherals are all considered parts or accessories. This warranty

does not cover damage from accident, neglect, misuse, alteration, contamination, or

abnormal conditions of operation or handling. Resellers are not authorized to extend

any other warranty on Fluke Networks’ behalf. To obtain service during the warranty

period, contact your nearest Fluke Networks authorized service center to obtain return

authorization information, then send your defective product to that Service Center with

a description of the problem.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH AS FITNESS

FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE NETWORKS IS NOT

LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR

LOSSES, ARISING FROM ANY CAUSE OR THEORY. Since some states or countries do not

allow the exclusion or limitation of an implied warranty or of incidental or consequential

damages, this limitation of liability may not apply to you.

Fluke Networks

PO Box 777

Everett, WA 98206-0777

USA

4/04
