Fluke DSP-PM12B Manuel utilisateur

PMxx English Instruction Sheet

Page 1

Panel dimensions: 4-1/8” x 5-1/4”

Flat Size: 12-3/8” x 5-1/4”

01/18/02

Final Version for Translation

PN 1611107 (English) April 2001, Rev. 2, 1/02

All product names are trademarks of their respective companies.

PMxx

Permanent Link Module

for the DSP/OMNI-LIA101

Permanent Link Adapter

Instruction Sheet

The PMxx Permanent Link Module makes a DSP/OMNI-LIA101

Permanent Link Adapter electrically compatible with a particular

manufacturer’s jack.

Refer to the PMxx module list included for applications for this

module and other available modules. For the most recent list of

available modules, visit the Fluke Networks website at

www.flukenetworks.com.

Fluke Networks DSP-PM12B Specs

Provided by www.AAATesters.com

PMxx English Instruction Sheet

Page 2

Panel dimensions: 4-1/8” x 5-1/4”

Flat Size: 12-3/8” x 5-1/4”

01/18/02

Final Version for Translation

Handling Information

hCaution

To avoid latent or immediate damage due to

electrostatic discharge:

•Before handling a module or an adapter with no

module attached, ground yourself when possible by

touching a grounded, conductive surface.

•Always remove the adapter from the test tool before

changing the personality module.

•Always keep a personality module attached to the

adapter cable.

•Always store the personality module in its original,

static protection bag when not in use.

PMxx English Instruction Sheet

Page 3

Panel dimensions: 4-1/8” x 5-1/4”

Flat Size: 12-3/8” x 5-1/4”

01/18/02

Final Version for Translation

Installation

Attach the module to a DSP/OMNI-LIA101 adapter cable as

follows (refer to Figure 1):

1. Ground yourself by touching a grounded, conductive

surface.

2. Remove the link interface adapter from the test tool.

3. Use your fingers to unscrew the screw on the personality

module. If necessary, you can use a flat-blade screwdriver to

loosen the screw.

4. Remove the module; then store it in its original, static

protection bag.

5. Put the new module in place and tighten the screw with

your fingers.

Caution

Tighten the screw with your fingers only. Do not

overtighten. Doing so can damage the module or the

end of the cable.

PMxx English Instruction Sheet

Page 4

Panel dimensions: 4-1/8” x 5-1/4”

Flat Size: 12-3/8” x 5-1/4”

01/18/02

Final Version for Translation

Static sensitive

device

Personality

module

aen01f.eps

Figure 1. Replacing the Personality Module

Maintenance

Always store the module in its original, static protection bag

when not in use.

Clean the module case with a soft cloth dampened with water

or water and a mild soap. Do not use abrasives, solvents, or

alcohol.

PMxx English Instruction Sheet

Page 5

Panel dimensions: 4-1/8” x 5-1/4”

Flat Size: 12-3/8” x 5-1/4”

01/18/02

Final Version for Translation

Contacting Fluke Networks

Visitthe Fluke Networkswebsite atwww.flukenetworks.com.

Send email to fluke-assist@flukenetworks.com.

To order accessories or get the location of the nearest Fluke

Networks distributor or service center, call:

•USA: 1-888-993-5853

•Canada: 1-800-363-5853

•Europe: +31-402-678-200

•Japan: +81-3-3434-0181

•Singapore: +65-738-5655

•Anywhere in the world: +1-425-446-4519

For operating assistance in the USA, call 1-800-283-5853.

Specifications

Refer to the PMxx module list included for applications for this

module. Module information is also posted on the Fluke

Networkswebsiteatwww.flukenetworks.com.

PMxx English Instruction Sheet

Page 6

Panel dimensions: 4-1/8” x 5-1/4”

Flat Size: 12-3/8” x 5-1/4”

01/18/02

Final Version for Translation

LIMITED WARRANTY AND LIMITATION OF LIABILITY

This Fluke Networks product will be free from defects at the time of

purchase. This warranty does not cover damage from accident, neglect,

misuse, alteration, contamination, or abnormal conditions of operation

or handling. Resellers are not authorized to extend any other warranty

on Fluke Networks’ behalf. To obtain service during the warranty period,

contact your nearest Fluke Networks authorized service center to obtain

return authorization information.

Fluke Networks’ warranty obligation is limited, at Fluke Networks’

option, to refund of the purchase price, or free of charge repair or

replacement of a defective product that is returned to an authorized

Fluke Networks Service Center within the warranty period.

Warranty service is available outside the United States only if product

was purchased through a Fluke Networks Authorized Sales Outlet in the

country of use or the applicable Fluke Networks international price was

paid.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES,

SUCH AS FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR

IMPLIED. FLUKE NETWORKS IS NOT LIABLE FOR ANY SPECIAL, INDIRECT,

INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM

ANY CAUSE OR THEORY. Since some states or countries do not allow the

exclusion or limitation of an implied warranty or of incidental or

consequential damages, this limitation of liability may not apply to you.

Fluke Networks, Inc.

P.O. Box 9090

Everett, WA 98206-9090

U.S.A.

Fluke Europe B.V.

P.O. Box 1186

5602 BD Eindhoven

The Netherlands

3/01
