UNPACKING/INSPECTION
Inspect
•
After unpacking the unit, inspect carefully for any damage that may
have occurred during transit. Check for loose, missing or damaged
parts. Shipping damage claims must be filed withcarrier.
•
See General Safety Instructions, and all Cautions, Warnings, and
Dangers as shown.
INTRODUCTION
The QSI communications module is a multiple capability electronics package. For
the G2 meter, the module is available with the plain cover plate only. The QSI
module has three versions (QSI1, QSI2 or QSI3) available; each with its own mix
of capabilities to better serve the customer (See Versions below).
•
QSI1 is equipped with Bluetooth®, coil/digital pulse input, pulse output (flow or
energy & scalable), RS485 (Modbus® RTU), temperature inputs, BTU
calculator.
•
QSI2 is equipped with Bluetooth, coil/digital pulse input, pulse output (flow or
energy & scalable), temperature inputs, BTU calculator.
•
QSI3 is equipped with Bluetooth, coil/digital pulse input, pulse output (flow
scalable), 4-20mA output.
This manual contains information and meter wiring diagrams for the three different
QSI electronics modules.
IMPORTANT NOTICE
QSI module electronics are very sensitive to electric noise if operated within 6
inches of some electric motors, relays, transformers or other sources of electronic
noise.
If the QSI electronics are used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
GENERAL INFORMATION
QSI electronics are mounted into the cover plate of the meter you ordered. The
QSI electronics converts the voltage (or pulses) from the meter into usable
information.
The QSI module electronics is powered by customer supplied external power.
SAFETY
•This product is not approved for use in hazardous locations.
•Be sure O-rings and seals are kept in good repair.
•When applying power, adhere to specifications in this manual.
•Disconnect external power before attaching or detaching input or output wires.
