FLASHFORGE 3D PRINTER Adventurer 4 Manuel utilisateur

快速启动指南

Adventurer 4 / 冒险家4

Quick Start Guide

EN/CN/DE/FR/한-A01

本手册仅适用于闪铸科技冒险家4 3D打印机

This guide is only applicable to FLASHFORGE Adventurer 4 3D printer

WARNING

注意事项 1. Do not remove the wrapping around the nozzle.

2. Hot! Avoid touching the heating nozzle in operation.

3. Moving parts in printer may cause injury. Do not

wear gloves or other sources of entanglement in

operation.

1. 切勿去除包裹在喷嘴处的耐高温材料。

2. 高温危险！打印机喷嘴在工作时会被加热，操作时请避免

接触!

3. 可动部件可能会造成卷入挤压和切割伤害。操作机器时请

不要配带手套或缠绕物。

EN P01 / CN P06 / DE P11 / FR P16 / 한 P21

20. Camera

13. Filament guide tube joint

15. Fan for cooling model

12. Extruder

16. Fan for cooling extruder

21. Air filter

17. Buckle 18. Air duct

19. Nozzle

14. Cable slot

Adventurer 4 Quick Start Guide

5. Filament intake cover

7. Platform base

9. Touch screen

4. Spool holder

1. Power switch

2. Power socket

8. Build plate

6. Front cover

11. Ethernet input

10. USB

3. Filament cover

Component Introduction

3D Printer Filament After-Sales

Service Card

Screwdriver

0.4-265 Nozzle

（Adventurer 4 Equipped）

Quick Start Guide Unclogging

Pin Tool

Power Cable

Grease

Allen Wrench

Filament Guide

Tube Joint

Leveling Card

USB Disk

Packing Specification

快速启动指南

Adventurer 4 / 冒险家4

Quick Start Guide

EN/CN/DE/FR/한-A01

本手册仅适用于闪铸科技冒险家4 3D打印机

This guide is only applicable to FLASHFORGE Adventurer 4 3D printer

WARNING

注意事项 1.Do not remove the wrapping aroundthe nozzle.

2.Hot! Avoid touching the heating nozzle in operation.

3.Moving parts in printer may cause injury. Do not

weargloves or other sources of entanglement in

operation.

1. 切勿去除包裹在喷嘴处的耐高温材料。

2. 高温危险！打印机喷嘴在工作时会被加热，操作时请避免

接触!

3. 可动部件可能会造成卷入挤压和切割伤害。操作机器时请

不要配带手套或缠绕物。

EN P01 / CN P0 6 / DE P11 / FR P 16 / 한 P21

The equipment has been leveled and calibrated before

delivery, but due to transportation or other influences,

the distance between nozzle and platform may change.

It is recommended to conduct [Calibration] after

unpacking.

This step is optional, please refer to the interface

function introduction before operation.

Find the FlashPrint installation package in the USB disk and select the version

corresponding to your system to install.

Or you can download it from https://www.flashforge.com/download-center.

Software Installation

Preparation of Device

1.Connect to power.

Connect cable to printer;

turn on the switch, the

screen lights up.

Power Switch

2. Load Filament: open the filament cover on the right side, insert the filament into

the filament intake, push filament into the feeding wheel until some resistance is

felt. Please make sure filaments are in the feeding wheel. Tap

[Prepare]-[Filament]-[Load]. Follow the instruction, filament coming out of the

nozzle indicates a success.

3.Model File Transfer

Method 1: Wi-Fi Connection

Tap [Settings]-[Network]-[WIFI], operate according to the instruction. Open

FlashPrint, click [Print], then click [Machine Type], select [FlashForge Adventurer 4].

You can try to enter the IP address or scan it automatically. The IP address can be

viewed in [settings] - [about].

When the user wants to use

the browser to view images,

the printer and PC must be

in an intranet (that is, the

printer and PC connect to

the same router).

IP Address

IP Port：

192 . . . :168 2122 8899

Auto-scan

Connection

Connect

Note

Import stl or obj file into the slicer; after slicing, the printer will heat up and start

printing automatically.

Method 2: USB Device

Files can be read in USB disk. Insert USB disk and select the files to print.

4.Model Removal

Take out the removable build plate, and bend the plate to get the model.

Nozzle and build plate are still hot after finishing printing, please wait for them to

cool down before you operate.

It is recommended to take the plate to the outside of the equipment for model

removal, otherwise the model debris will remain in the equipment. Please keep

the inside of the printer clean.

Note

20. 摄像头

13.气管接头

15. 模型冷却风扇

12. 喷头

16. 喷头冷却风扇

21. 空气过滤

17. 卡扣

18. 导风嘴 19. 喷嘴

14. 排线槽

冒险家4 快速启动指南

5. 送丝盖板

7. 平台底座

9. 触控屏

4. 料盘架

1. 电源开关

2. 电源插座

8. 平台板

6. 前门

11. 网口

10. USB

3. 丝盘门

整机介绍

3D打印机 3D打印耗材售后服务卡

十字螺丝刀0.4-265喷嘴

（冒险家4 配置）

快速启动指南通针

电源线

润滑脂

内六角扳手

气管接头

调平卡

U盘

装箱清单

快速启动指南

Adventurer 4 / 冒险家4

Quick Start Guide

EN/CN/DE/FR/한-A01

本手册仅适用于闪铸科技冒险家4 3D打印机

This guide is only applicable to FLASHFORGE Adventurer 4 3D printer

WARNING

注意事项 1.Do not remove the wrapping aroundthe nozzle.

2.Hot! Avoid touching the heating nozzle in operation.

3.Moving parts in printer may cause injury. Do not

weargloves or other sources of entanglement in

operation.

1. 切勿去除包裹在喷嘴处的耐高温材料。

2. 高温危险！打印机喷嘴在工作时会被加热，操作时请避免

接触!

3. 可动部件可能会造成卷入挤压和切割伤害。操作机器时请

不要配带手套或缠绕物。

EN P01 / CN P0 6 / DE P11 / FR P 16 / 한 P21

设备出厂经过调平校准，但由于运输等情况，喷嘴与平台间距

可能发生变化，建议在开箱后进行一次【喷头校准】。

此步骤非完全必要操作。具体操作根据界面指引。

方法一：在U盘中找到FlashPrint软件安装包，选择对应的系统版本进行安装。

方法二：从官方网站 www.sz3dp.com 下载最新的切片软件。

注：官网可下载到最新的切片软件。

软件安装

设备预准备

1.连接电源。

通过电源线连接电源与打印机；

开启开关，屏幕点亮。

电源开关

首次打印
