Festo ERMB Manuel utilisateur
(en) Operating
instructions
Rotary module
ERMB
8103858
2018-12a
[8103860]
ERMB
Festo ERMB 2018-12a
2
Translation of the original instructions
Identification of hazards and instructions on how to prevent them:
Danger
Immediate dangers which can lead to death or serious injuries
Warning
Hazards that can cause death or serious injuries
Caution
Hazards that can cause minor injuries
Other symbols:
Note
Material damage or loss of function
Recommendations, tips, references to other documentation
Essential or useful accessories
Information on environmentally sound usage
Text designations:
Activities that may be carried out in any order
1. Activities that should be carried out in the order stated
– General lists
èResult of an action/References to more detailed information
ERMB
Festo ERMB 2018-12a English 3
Rotary module ERMBEnglish
Contents
1 Operating parts and connections 4................................
2 Function and application 5.......................................
3 Transport and storage 5.........................................
4 Conditions of use 6.............................................
5 Fitting 7......................................................
Fitting mechanical components 7..................................
Fitting electric components 9.....................................
Fitting electric components 10.....................................
6 Commissioning 11...............................................
Commissioning – carrying out 12...................................
7 Operation 12...................................................
8 Care and maintenance 13.........................................
9 Repairs 13.....................................................
10 Accessories 14..................................................
11 Eliminating faults 14.............................................
12 Technical specifications 15.......................................
Characteristic curves 17..........................................
ERMB
Festo ERMB 2018-12a English
4
For all available product documentation èwww.festo.com/pk
1 Operating parts and connections
235641
Fig. 1
7
891 aJ
1Centring holes and threaded holes for
fastening (on 6 sides)
2Drive shaft (hollow shaft) with thread for
accessories, rear side
3Threaded holes for kits for connecting
the motor
4Drive shaft
5Drive shaft with centring holes and
threaded holes for work load, front
6Threaded hole for proximity switch
(covered)
7Toothed belt tension pulley with locking
screw for service personnel
8Through hole for fastening
9Marking hole on connector ring for switch
ing cam lying behind
aJ Holes for service personnel
ERMB
Festo ERMB 2018-12a English 5
2 Function and application
A toothed belt transfers the rotary movement of a motor to a hollow shaft.
The shafts have ball bearings. The reference position of the hollow shaft can
be scanned with the aid of an inductive proximity switch in the threaded hole 6.
The rotary module type ERMB is intended for turning work loads (e. g. with
grippers). The ERMB is not permitted for application conditions in which vegetable
and water-soluble greases or oils can penetrate into the axis. Vegetable greases or
oils can reduce the capacity of the toothed belt.
Note
The ERMB is not fitted with a brake. When the input torque is not applied,
the rotary module can be moved freely. Generally self-locking of the complete
system can be achieved with motors with integrated holding brake or with high
self-braking torque.
SUse the motors specified in the Festo (ècatalogue.
www.festo.com/catalogue).
You will then be operating two devices which are especially matched to each
other.
When using other motors:
SObserve the maximum values for torques and speeds èchapter “12 Technical
specifications.”
SNote the interface geometries (e.g. for the drive shafts) ècatalogue
specifications under www.festo.com/catalogue
3 Transport and storage
STake into account the weight of the rotary module. Depending on the design
the ERMB can weigh up to 3.3 kg.
SEnsure storage conditions as follows:
– Storage times should be kept to a minimum
– cool, dry, shaded, corrosion-protected storage locations
ERMB
Festo ERMB 2018-12a English
6
4 Conditions of use
Warning
Uncontrolled moving masses can cause in
jury to people or damage to property
(danger of fingers being squashed).
SApply power to the drive motor, at first
limited to low speeds and torques.
Note
The positioning times and permitted mass moments of inertia on the drive
depend to a large extent on the flange-mounted motor.
SUse the design tool “Positioning Drives” from Festo for ascertaining the
optimum combination of the products (èwww.festo.com).
Make sure that the following specifications are observed:
SCompare the maximum values specified in these operating instructions with
those of your actual application (e.g. forces, torques, temperatures, masses,
speeds).
The product can only be operated in compliance with the relevant safety
regulations if the maximum loading limits are observed.
STake into consideration the ambient conditions at the location of use.
Corrosive environments reduce the service life of the product (e.g. ozone).
SPlease comply with national and local safety laws and regulations.
SRemove transport packaging such as foils (polyethylene) and cardboard.
The packing is intended for recycling (except for: oiled paper = other waste).
SUse the product in its original state. Unauthorised modification is not per
mitted.
STake the tolerance of the tightening torques into consideration. Without
special specification the tolerance is ±20 %.
Fig. 2
ERMB
Festo ERMB 2018-12a English 7
5 Fitting
Fitting mechanical components
SDo not modify the settings of screws and threaded pins if there is no request to
do this in these operating instructions.
SFit the motor onto the rotary module in
accordance with the assembly instruc
tions for the kit recommended in the cata
logue.
Fitting the product:
Note
External stops can cause the toothed belt to tear due to excessive forces.
SUse only the motor controller for braking the ERMB.
SPosition the ERMB so that all the operating parts are accessible.
SFasten the ERMB with 4 screws and
2 centring sleeves (diagonal) or with the
aid of kits to the threaded holes 1or 8.
Fastening is possible on all six side sur
faces.
Fig. 3
Fig. 4
ERMB
Festo ERMB 2018-12a English
8
STighten the fastening screws evenly.
Observe the max. screw-in depth D on the base surface (èFig. 5).
ERMB-... 20 25 32
Tightening
torque
M4
M5
M6
[Nm] 2.9
5.9
–
–
5.9
9.9
–
5.9
9.9
Max. screw-
in depth D
[mm] 10
Centring
sleeves
[mm] Dia. 9x4
Fig. 5
Eccentric loads fitted in a vertical or sloping position:
Warning
Uncontrolled moving masses can cause
injury to people or damage to property
(danger of fingers being squashed).
If there is a power failure or if the toothed
belt breaks inside the ERMB, the work load
will slide down.
SMake sure that the ERMB is driven only
by motors with an integrated spring-
loaded holding brake.
SCheck whether external safety measures
against damage due to toothed-belt frac
ture are necessary (e.g. toothed latches
or moving bolts).
In this way you can prevent the work
load from sliding down.
Fig. 6
ERMB
Festo ERMB 2018-12a English 9
Fitting the work load
SPlace the centre of gravity of the work
load if possible centrically to the drive
shaft.
SFasten the work load to the drive shaft
with at least 2 screws and 2 centring
sleeves (diagonal) or with the aid of kits.
ERMB-... 20 25 32
Screw M4 M6 M6
Tightening
torque
[Nm] 2.9 9.9 9.9
Max. screw-
in depth E
[mm] 9.6 12 12
Centring
sleeves
[mm] dia.
7x3
dia.
9x4
dia.
9x4
Fig. 8
Fitting electric components
Fitting an inductive proximity switch as reference switch:
1. Turn the drive shaft until the marking
hole (A) reaches the threaded hole 6.
2. Push the clamping element (C) into the
recess intended for this.
3. Screw the proximity switch (D):
– at first into the hole 6until it touches
the switching cam (B).
– then unscrew it approx. 0.6 of a turn
(o0.6 mm).
4. Screw the threaded pin (ß2.5) into the
clamping unit (C). The tightening torque
is 0.8 Nm.
Fig. 7
Fig. 9
(A)(B)
(C)
(D)
6
ERMB
Festo ERMB 2018-12a English
10
SCheck whether additional proximity switches are necessary. The scanning kit
can be used for this purpose in accordance with the section on Accessories
(ècatalogue specifications, www.festo.com/catalogue).
Turning the switching ring (E)
SScrew the switching ring with a pin into
the hole (A) as far as is desired (90° latch
ing). The drive shaft 2must be used here
as a counter hold.
Turning the holding ring (F)
Note
If the holding ring is loosened, the drive
shaft may be drawn out of the ERMB due
to excessive axial forces.
SAvoid axial forces when the holding ring
is loose.
SUnscrew:
– The 4 fastening screws out of the holding ring (F).
– Screw the holding ring into the desired position (note permitted swivel
angle).
– Screw the 4 fastening screws into the holding ring again.
The permitted swivel angle and tightening torques are as follows:
ERMB-... 20 25 32
Permitted swivel angle [°] 180 90/180/270 90/180/270
Tightening torque [Nm] 2.9 2.9 5.9
Fig. 11
Fitting electric components
Note
If used in safety-relevant applications additional measures are necessary. In
Europe, for example, the EU machine guideline standards must be observed.
Without additional measures in accordance with legally specified minimum
requirements, the product is not suitable as a safety relevant component in
control systems.
Fig. 10
2
(E)
(F)
(A)
Table des matières
Autres manuels Festo Unité de contrôle
Festo
Festo CPX-AP-A-12DI4DO-M12-5P Manuel utilisateur
Festo
Festo MS6-SV Series Manuel utilisateur
Festo
Festo CPX-AP-A-16DI-D-M12-5P Manuel utilisateur
Festo
Festo SPC200-MMI-DIAG Manuel de la liste des pièces
Festo
Festo CP-FB8-E Manuel de la liste des pièces
Festo
Festo MSE6-C2M Manuel de la liste des pièces
Festo
Festo SPC200-COM-PDP Manuel utilisateur
Festo
Festo CMGA Series Manuel utilisateur
Festo
Festo ZSB-1/8 Manuel utilisateur
Festo
Festo VZXA-***-M Series Manuel utilisateur
Festo
Festo CP-FB11-E Manuel de la liste des pièces
Festo
Festo VZQA-C-M22C-6-GG-V2V4E-1 Manuel utilisateur
Festo
Festo LFR-D Series Manuel utilisateur
Festo
Festo VZBA-...-63-T-22-...-V4V4T series Manuel utilisateur
Festo
Festo CMGA-E1-CO Manuel utilisateur
Festo
Festo MS6-SV Series Manuel utilisateur
Festo
Festo CTEU-DN Manuel de la liste des pièces
Festo
Festo VABF-S4-1-V2B1 series Manuel utilisateur
Festo
Festo CPX-FVDA-P Instructions d'utilisation et d'installation
Festo
Festo VZXA M Series Manuel de la liste des pièces
Manuels Unité de contrôle populaires d'autres marques
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur
JS Automation
JS Automation MPC3034A Manuel utilisateur
JAUDT
JAUDT SW GII 6406 Series Guide rapide
Spektrum
Spektrum Air Module System Manuel utilisateur
BOC Edwards
BOC Edwards Q Series Manuel utilisateur
KHADAS
KHADAS BT Magic Manuel utilisateur
