Fellowes PC 100 Manuel utilisateur

Operating Instructions

PC100

Model: PC 100

Equipment Parts

1. Waste Paper Cover

2. Punching Area

3. Punching Handle

4. Margin Guide

Using the Punching

Machine

Punching Holes

1. Use the margin guide on the left-most side of the

punching area to align the sheets.

2. Slide all sheets to the back of the punching area.

NOTE: a maximum of 5 sheets can be punched at

a time.

3. Lower the punching handle to punch holes in the

paper.

4. Return handle to its original position and remove

sheets from punching area.

5. Repeat until all sheets and covers have been

punched.

Binding the Document

Use the table below to select the appropriate plastic

coil according to the number of sheets to be bound:

No. of Sheets Coil Size

30 6 mil

45 7 mil

70 10 mil

85 13 mil

1. Align holes. Place document to be bound on

desktop. Starting at the first hole on either end,

twist binding coil until it has passed through every

hole. (Figure A) 2. Close loop by bending end of

coil down towards binding on each end of the

document. (Figure B). Your document is now

bound.

Emptying Paper Cuttings

To remove, simply raise the waste paper cover located

on either side of the machine. Pick up machine and

tip it toward the same side as the raised cover. To be

sure all paper clippings have been removed from the

machine, gently shake the machine. To prevent

clogging and jamming, be sure to empty paper

clippings frequently.

PC100

Figure A Figure B

Specifications

Maximum punching length 11 inches (279mm)

Maximum punching capacity (at a time) 5 sheets

Number of holes punched 43, 4:1 pitch

Dimensions (L x W x H) 15-5/8" x 6-7/8” x 3-1/2” (396 x 175 x 89mm)

Weight 8.6 lbs. (3.9kg)

Warranty 1 year

Limited Warranty

Fellowes Manufacturing Company warrants all PC Model Binding Machines to be free from defects in material

and workmanship for a period of one year from the date of purchase by the original consumer. The exception to

this are the punching dies which are subject to wear. If any part is found to be defective during the warrant

period, your sole and exclusive remedy will be repair or replacement, at Fellowes’ option and expense, of the

defective part.

This warranty does not apply in cases of abuse, mishandling or unauthorized repair. ANY IMPLIED WARRANTY,

INCLUDING THAT OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED IN

DURATION TO THE APPROPRIATE WARRANTY PERIOD SET FORTH ABOVE. In no event shall Fellowes be liable for

any consequential or incidental damages attributable to this product. This warranty gives you specific legal rights.

You may have other legal rights which vary from state to state. To obtain service under this warranty on

machines purchased in the USA, return the machine prepaid to the address below. Please allow two weeks for

processing.

Return with machine:

• Copy of original sales receipt.

• A card stating your name, address, daytime telephone number, machine model and serial number, plus a brief

description of the problem.

For specific instructions on obtaining service under this warranty on machines purchased outside the USA, contact

the appropriate location listed below.

Warrantor: Fellowes Manufacturing Company

U.S. 1-800-955-0959

Australia + 6139-330-3211 (inside Melbourne)

1-800-331-177 (outside Melbourne)

Benelux + 31-3473-77988

Canada 1-800-665-4339

France + 334-789-12279

Germany + 4951-31-49770

Japan + 81-3-5496-2401

U.K. + 44-1302-885331

Australia Benelux Canada France Germany Italy Japan Poland United Kingdom

Tullamarine, Vic Vianen, NL Markham, Ont. Rennes, I-V Garbsen, Han. Camerano, AN Tokyo Warsaw Doncaster, S. Yorks.

1789 Norwood Avenue, Itasca, Illinois 60143-1095 630-893-1600 Customer Service 1-800-945-4545 http://www.fellowes.com
