Feig Electronic ID ISC.MU02.02 Manuel utilisateur

INSTALLATION

final –public (B)

2018-09-19 –M91002-5e-ID-B.docx

ID ISC.MU02.02

UHF Reader Module

Identification

Installation

ID ISC.MU02.02

FEIG ELECTRONIC GmbH

Page 2 of 22

M91002-5e-ID-B.docx

Note

FEIG ELECTRONIC GmbH

Lange Strasse 4

D-35781 Weilburg

Tel.: +49 6471 3109-0

http://www.feig.de

With the edition of this document, all previous editions become void. Indications made in this manual may be

changed without previous notice.

Copying of this document, and giving it to others and the use or communication of the contents thereof are

forbidden without express authority. Offenders are liable to the payment of damages. All rights are reserved

in the event of the grant of a patent or the registration of a utility model or design.

Composition of the information in this document has been done to the best of our knowledge. FEIG

ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this

manual and may not be held liable for damages ensuing from incorrect or incomplete information. Since,

despite all our efforts, errors may not be completely avoided, we are always grateful for your useful tips.

The instructions given in this manual are based on advantageous boundary conditions. FEIG ELECTRONIC

GmbH does not give any guarantee promise for perfect function in cross environments and does not give

any guaranty for the functionality of the complete system which incorporates the subject of this document.

FEIG ELECTRONIC call explicit attention that devices which are subject of this document are not designed

with components and testing methods for a level of reliability suitable for use in or in connection with surgical

implants or as critical components in any life support systems whose failure to perform can reasonably be

expected to cause significant injury to a human. To avoid damage, injury, or death, the user or application

designer must take reasonably prudent steps to protect against system failures.

FEIG ELECTRONIC GmbH assumes no responsibility for the use of any information contained in this docu-

ment and makes no representation that they free of patent infringement. FEIG ELECTRONIC GmbH does

not convey any license under its patent rights nor the rights of others.

Identification

Installation

ID ISC.MU02.02

FEIG ELECTRONIC GmbH

Page 3 of 22

M91002-5e-ID-B.docx

General information's regarding this document

The sign "" indicates extensions or changes of this manual compared with the former issue.

If bits within one byte are filled with "-", these bit spaces are reserved for future extensions or

for internal testing- and manufacturing-functions. These bit spaces must not be changed, as this

may cause faulty operation of the reader.

The following figure formats are used:

0...9: for decimal figures

0x00...0xFF: for hexadecimal figures,

b0...1 for binary figures.

The hexadecimal value in brackets "[ ]" marks a control byte (command).

Identification

Installation

ID ISC.MU02.02

FEIG ELECTRONIC GmbH

Page 4 of 22

M91002-5e-ID-B.docx

Contents

1. Safety Instructions / Warning - Read before start-up ! 6

2. Performance Characteristics of the ID ISC.MU02.02 Reader Module 7

2.1. Performance Characteristics............................................................................................ 7

2.2. Available module types.....................................................................................................7

2.3. Optional available.............................................................................................................. 8

3. Installation and wiring 9

3.1. Dimensions........................................................................................................................9

3.2. Wiring –Connector X2.................................................................................................... 10

3.2.1. Supply voltage ...........................................................................................................11

3.2.2. RS232 interface.........................................................................................................11

3.2.3. Data/Clock interface...................................................................................................12

3.2.4. Shut Down.................................................................................................................13

3.3. USB interface................................................................................................................... 14

3.4. Antenna ports.................................................................................................................. 15

3.5. Display elements.............................................................................................................16

3.6. Installation notes.............................................................................................................17

3.6.1. Metallic surroundings.................................................................................................17

3.6.2. EMC effects on cables...............................................................................................17

4. Technical Data 18

5. Radio Approvals 20

5.1. Europe (CE)...................................................................................................................... 20

5.2. USA (FCC) and Canada (IC)............................................................................................ 21

5.2.1. USA (FCC) and Canada (IC) warning notices............................................................ 21

5.2.2. Label Information.......................................................................................................22

5.2.3. Installation with FCC / IC Approval............................................................................. 22

Identification

Installation

ID ISC.MU02.02

FEIG ELECTRONIC GmbH

Page 5 of 22

M91002-5e-ID-B.docx

5.2.4. USA (FCC) and Canada (IC) approved antennas ......................................................22

Identification

Installation

ID ISC.MU02.02

FEIG ELECTRONIC GmbH

Page 6 of 22

M91002-5e-ID-B.docx

Safety Instructions / Warning - Read before start-up !

The device may only be used for the intended purpose designed by for the manufacturer.

The operation manual should be conveniently kept available at all times for each user.

Unauthorized changes and the use of spare parts and additional devices which have not been

sold or recommended by the manufacturer may cause fire, electric shocks or injuries. Such

unauthorized measures shall exclude any liability by the manufacturer.

The liability-prescriptions of the manufacturer in the issue valid at the time of purchase are valid

for the device. The manufacturer shall not be held legally responsible for inaccuracies, errors,

or omissions in the manual or automatically set parameters for a device or for an incorrect

application of a device.

Repairs may only be executed by the manufacturer.

Installation, operation, and maintenance procedures should only be carried out by qualified

personnel.

Use of the device and its installation must be in accordance with national legal requirements

and local electrical codes .

When working on devices the valid safety regulations must be observed.

Special advice for carriers of cardiac pacemakers:

Although this device doesn't exceed the valid limits for electromagnetic fields you should keep

a minimum distance of 25 cm between the device and your cardiac pacemaker and not stay in

an immediate proximity of the device respective the antenna for some time.

Identification

Installation

ID ISC.MU02.02

FEIG ELECTRONIC GmbH

Page 7 of 22

M91002-5e-ID-B.docx

Performance Characteristics of the ID ISC.MU02.02 Reader Module

2.1.

Performance Characteristics

The ID ISC.MU02.02 Reader Module is designed for reading and writing passive transponders, so-

called “Smart Labels”, with an operating frequency of 860 MHz to 960 MHz. It is suitable for any

application in which short and middle read ranges and small reader dimensions are required.

The module has 2 integrated antenna outputs for connecting 2 different 50 Ω antennas.

2.2.

Available module types

The following module types are currently available:

Table 1: Available reader types

Module type

Description

ID ISC.MU02.02-AD

Reader Module with RS232 and data/clock interface, external supply voltage of 5 V DC

ID ISC.MU02.02-CU

Reader Module with RS232-LVTTL and USB interface, external supply voltage of 5 V

DC or directly over USB

Identification

Installation

ID ISC.MU02.02

FEIG ELECTRONIC GmbH

Page 8 of 22

M91002-5e-ID-B.docx

2.3.

Optional available

The following components are optional available for the ID ISC.MU02.02.

Table 2: Accessories

Accessories

Order number

For COM-Port connection:

ID CAB.A-A Cable for Adaption of RS232 and Data/Clock

2259.000.00

ID CAB.RS-A Cable for RS232 and Power supply

1690.000.00

RS232-LVTTL/TTL Serial Data Converter

1962.000.00

ID Net.5V Power Supply

1689.000.00

For USB-Port connection:

ID CAB.USB-B Cable for USB

3541.000.00

Antennas and accessories:

ID ISC.ANT.U75/50-EU UHF antenna module 865 –868 MHz

3544.000.00

ID ISC.ANT.U75/50-FCC UHF antenna module 902 –928 MHz

3543.000.00

ID ISC.ANT.C05-A UHF antenna cable U.FL-U.FL 500 mm

3540.000.00

ID ISC.ANT.C02-U.FL/SMA adapter cable U.FL-SMA 200 mm

3621.000.00

Identification

Installation

ID ISC.MU02.02

FEIG ELECTRONIC GmbH

Page 9 of 22

M91002-5e-ID-B.docx

Installation and wiring

3.1.

Dimensions

Figure 1 shows the dimensions of the ID ISC.MU02.02 Reader Module in mm.

Figure 1: Dimensions of the ID ISC.MU02.02 Reader Module in mm

Identification

Installation

ID ISC.MU02.02

FEIG ELECTRONIC GmbH

Page 10 of 22

M91002-5e-ID-B.docx

3.2.

Wiring –Connector X2

Figure 2 and Table 1 show the pin assignments for Terminal X2. The pin connector is designed for

flat cable connection using an IDC multipoint socket connector with 2.54 mm pin spacing.

Figure 2: Pin assignments for Terminal X2

Table 3: Pin assignments for Terminal X2

Function

Description

DAT

Data line for the data/clock interface

CLK

Clock line for the data/clock interface

TxD

RS232-TTL –Transmit Data

GND **

Ground

RxD

RS232-TTL –Receive Data

SHDN

Shut Down

CLS

CLS line for the data/clock interface

VCC *

+ 5 V DC

GND **

Ground

---

no function (use ONLY open!)

* Use only regulated DC power supplies !

** GND-Pins 4 and 9 are to be connected directly to each other

on the Reader Module
