Fanvil I10 Guide d'installation et d'utilisation

Version: 1.0

Release Date: 4th,Nov,2021

How to Check the IP address

of i10 and i10S series?

Catalog

How to Check the IP address of i10 and i10S series?...................................................................1

1. Introduction...........................................................................................................................3

1.1. Overview ......................................................................................................................3

1.2. Applicable Model.........................................................................................................3

1.3. Before You Start...........................................................................................................3

1.4. Connection Diagram.....................................................................................................3

2. Operation Guide ...................................................................................................................4

2.1. Check IP Address via DSS key ....................................................................................4

2.2. Check IP Address via IPScanner..................................................................................4

Fanvil Technology Co. Ltd

Addr:10/F Block A, Dualshine Global Science Innovation Center, Honglang North 2nd Road, Bao'an District, Shenzhen, China

Tel: +86-755-2640-2199 Email: [email protected] [email protected] Official Web:www.fanvil.com

1. Introduction

1.1. Overview

When we need to make one P2P call, or when we need to load the management website of the

device to check or change settings, we need to know its IP address. This document introduces how

to check the IP address of i10 and i10S series.

1.2. Applicable Model

i10, i10V, i10D, i10S, i10SV and i10SD.

1.3. Before You Start

Step1.

Prepare PoE switch, network cable, one i10 or i10S series of device, computer.

Step2.

Refer to the connection diagram, connect the device to the network switch..

Step3.

Connect the computer to the same switch as the device with network cable.

1.4. Connection Diagram

Fanvil Technology Co. Ltd

Addr:10/F Block A, Dualshine Global Science Innovation Center, Honglang North 2nd Road, Bao'an District, Shenzhen, China

Tel: +86-755-2640-2199 Email: [email protected] [email protected] Official Web:www.fanvil.com

2. Operation Guide

There are two ways to check the IP address of i10 and i10S series, via DSS key and via IP Scanner

tool. Please check the following steps for detail.

2.1. Check IP Address via DSS key

Step1.

Refer to the above connection diagram, connect i10 or i10S series to PoE switch.

Step2.

After the device finishes booting and gets into standby mode:

Long press the DSS key for 3 seconds, the warning tone will ring out and last for 5 seconds. Press

the DSS key once during the 5 seconds, the device will broadcast IP address after the warning tone

stops.

2.2. Check IP Address via IPScanner

Step1.

Download IPScanner tool from Fanvil website:

https://www.fanvil.com.cn/Uploads/Marketing/Tool/IPScanner_v1.2.1.zip

Install this tool for your computer.

Step2.

Refer to the connection diagram, connect the computer and the device to the same PoE switch

with Network cable.

Step3.

Open IPScanner tool, find the record which has the same MAC address as your device, and you can

find its IP address too.
