Speciﬁcations — ISS 506 Series

Extron ISS 506 Series Seamless Switchers • Specications

Video input

Number/signal type..................... 4 RGBHV, RGBS, RGsB, component video (interlaced or progressive),

S-video, composite video

1 component video (interlaced), S-video, composite video

1 S-video, composite video, or optional digital component video (SDI or

HDSDI)

Connectors ..................................... 4 x 5 female BNC

1 x 3 female BNC, 1 female 4-pin mini DIN

1 optional BNC for SDI/HDSDI

Nominal level ................................ 1 Vp-p for Y of component video and S-video, and for composite video

0.7 Vp-p for RGB and for R-Y and B-Y of component video

0.3 Vp-p for C of S-video

Minimum/maximum levels........ Analog: 0.0 V to 2.0 Vp-p with no offset at unity gain

Impedance...................................... 75 ohms

Horizontal frequency.................... Autoscan 15 kHz to 100 kHz

Vertical frequency.......................... Autoscan 50 Hz to 120 Hz

Resolution range ........................... Autoscan 640x480 to 1600x1200

Return loss...................................... -30 dB @ 5 MHz

DC offset (max. allowable)........... 0.5 V

Video processing

Encoder (for scan converted output)

10 bit digital

Digital sampling (for program and preview outputs)

24 bit, 8 bits per color; 162 MHz standard

Colors (for program and preview outputs)

16.78 million

Horizontal ﬁltering (for scan converted output)

3 levels

Vertical ﬁltering (for scan converted output)

3 levels

Encoder ﬁltering (for scan converted output)

3 levels

Video output

Number/signal type..................... 2 scaled RGBHV, RGBS, RGsB, HD YUV component video program outputs

1 scaled RGBHV, RGBS, RGsB, HD YUV component video preview output

1 optional DVI, HDSDI (SMPTE 292 M), or scan converted output (interlaced

component video, S-video, composite video)

Connectors ..................................... (2) 15-pin HD (1 for preview output, 1 for program output)

5 BNC female (for program output)

Nominal level ................................ 1 Vp-p for Y of component video and S-video, and for composite video

0.7 Vp-p for RGB and for R-Y and B-Y of component video

0.3 Vp-p for C of S-video

Minimum/maximum levels........ 0.0 V to 0.7 Vp-p (RGB)

0.0 V to 1.0 Vp-p (component video, G of RGsB)

Impedance...................................... 75 ohms

Scaled resolution ........................... 640x4801,2,3,4,5,6, 800x6001,2,3,4,5,6, 852x4801,2,3,4,5, 1024x7681,2,3,4,

1024x8521,2,3,4,1024x10241,2,3, 1280x7681,2,3,4, 1280x10241,2,3, 1360x7651,2,3,

1365x7681,2,3, 1365x10241,2, 1366x7681,2,3, 1400x10501,2, 1600x12001,2,

1864x10501,2, HDTV 480p2,10, 576p1,5, 720p1,2,8,9,10, 1080p1,2,7,8,9,10, and 1080i1,2,10

1= at 50 Hz ; 2= at 60 Hz; 3= at 72 Hz ; 4= 96 Hz; 5= 100 Hz; 6= 120 Hz; 7= 24

Hz; 8 = 25 Hz; 9= 30 Hz; 10 = 59.94 Hz;

Return loss...................................... -30 dB @ 5 MHz

DC offset......................................... ±25 mV with input at 0 offset (except for RGsB and component video)

Switching type............................... Seamless switching (cut or dissolve)

Speciﬁcations — ISS 506 Series, cont’d

Extron ISS 506 Series Seamless Switchers • Specications

Sync

Input type....................................... Autodetect RGBHV, RGBS, RGsB

Output type.................................... RGBHV, RGBS, RGsB

Tri-level on Y, R-Y, B-Y channels of component video or bi-level on Y channel

of component video (selectable)

Standards........................................ NTSC 3.58, NTSC 4.43, PAL, SECAM

Optional SDI/HDSDI input: SMPTE 259M-C, SMPTE 292M

Input level ...................................... 0.0 V to 5.0 Vp-p

0.0 V to 0.6 Vp-p for component video with tri-level sync

Output level ................................... TTL: 5.0 V p-p, unterminated

Input impedance ........................... 510 ohms

Output impedance ........................ 75 ohms

Max. input voltage........................ 5.0 Vp-p

Polarity............................................ Positive or negative (selectable)

Audio

Gain................................................. Unbalanced output: -6 dB; balanced output: 0 dB

Frequency response ...................... 20 Hz to 20 kHz, ±0.05 dB

THD + Noise.................................. 0.05% @ 1 kHz at +4 dBu and 0 dB gain

S/N.................................................. >83 dB (typical) at maximum output (unweighted)

Crosstalk......................................... <-80 dB @ 1 kHz, fully loaded

Stereo channel separation ............ >90 dB @ 1 kHz

CMRR.............................................. >75 dB @ 1 kHz

Audio input

Number/signal type..................... 6 stereo, balanced/unbalanced

Connectors ..................................... (6) 3.5 mm captive screw connectors, 5 pole

Impedance...................................... >10k ohms unbalanced/balanced, DC coupled

Nominal level ................................ +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)

Maximum level.............................. +19.5 dBu, (balanced or unbalanced) at 1% THD+N

Input gain adjustment .................. –18 dB to +24 dB

Audio delay compensation (automatic)

20 ms when scaling RGB computer video or HDTV component video

75 ms when scaling NTSC component video, S-video, or composite video

90 ms when scaling PAL component video, S-video, or composite video

N 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈2 dBu

Audio output

Number/signal type..................... 3 stereo, balanced/unbalanced (2 program, 1 preview)

Connectors ..................................... (3) 3.5 mm captive screw connector, 5 pole

Impedance...................................... 50 ohms unbalanced, 100 ohms balanced

Gain error ....................................... ±0.5 dB channel to channel

Maximum level (Hi-Z) ................. >+21 dBu, balanced or unbalanced at 1% THD+N

Maximum level (600 ohm)........... >+15 dBm, balanced or unbalanced at 1% THD+N

Control/remote — switcher

Serial control ports........................ 1 RS-232/RS-422: 1 rear panel 9-pin female D connector

1 RS-232: 1 front panel 2.5 mm mini stereo jack

Baud rate and protocol................. 9600 (default), 19200, 38400, 115200 baud; 8 data bits; 1 stop bit; no parity

Extron ISS 506 Series Seamless Switchers • Specications

Serial control pin conﬁgurations

9-pin female D connector. RS-232: 2 = TX, 3 = RX, 5 = GND

RS-422: 2 = TX-, 3 = RX-, 5 = GND, 7 = RX+, 8 = Tx+

Mini stereo jack.................. RS-232: tip = TX, ring = RX, sleeve = GND

Ethernet control port..................... 1 RJ-45 female connector

Ethernet data rate.......................... 10/100Base-T, half/full duplex with autodetect

Ethernet protocol........................... ARP, DHCP, ICMP (ping), TCP/IP, UDP/IP, Telnet, HTTP, SMTP

Ethernet default settings .............. Link speed and duplex level = autodetected

IP address = 192.168.254.254

Subnet mask = 255.255.0.0

Gateway = 0.0.0.0

DHCP = off

Web server...................................... Up to 200 simultaneous sessions

16 MB nonvolatile user memory

Program control............................. Extron's control/conﬁguration program for Windows®

Extron's Simple Instruction Set (SIS™)

Microsoft® Internet Explorer®ver. 6 or higher, Netscape®Navigator®, Telnet

General

Power .............................................. 100 VAC to 240 VAC, 50/60 Hz, 45 watts, internal

Temperature/humidity................ Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Mounting

Rack mount ........................ Yes, with included brackets

Enclosure type ............................... Metal

Enclosure dimensions................... 3.5" H x 17.5" W x 12.0" D (2U high, full rack wide)

8.9 cm H x 44.4 cm W x 30.5 cm D

(Depth excludes connectors and knobs. Width excludes rack ears.)

Product weight .............................. 8.5 lbs (3.9 kg)

Shipping weight ............................ 18 lbs (9 kg)

DIM weight

USA/Canada ..................... 15 lbs (7 kg)

International....................... 18 lbs (8 kg)

Vibration......................................... ISTA 1A in carton (International Safe Transit Association)

Regulatory compliance

Safety................................... CE, CUL, UL

EMI/EMC .......................... CE, C-tick, FCC Class A, ICES, VCCI

MTBF............................................... 30,000 hours

Warranty......................................... 3 years parts and labor

N All nominal levels are at ±10%.

N Speciﬁcations are subject to change without notice.

7.6-100708-D5
