Extron • System 8/10 PLUS • User’s Manual • P/N 68-399-01 Rev. G

Barco Installation Configuration and Connections

SYSTEM 8/10 Plus

PROJECTOR COMMUNICATIONS KIT

ATTENTION!

PLEASE READ THIS DOCUMENT FOR IMPORTANT

INSTALLATION INSTRUCTIONS

THIS KIT HAS BEEN SHIPPED WITHTHE FOLLOWING COMPONENTS:

Kit Type: BARCO

Included Communications Adapter(s):

Quantity Part Number Description

1 26-309-01 Barco RCDVS Adapter

THE TABLE BELOW LISTS THE POSSIBLE CONFIGURATION(S) AND CORRESPONDING

COMMUNICATIONS ADAPTER(S) FOR YOUR PROJECTOR MANUFACTURER’S VARIOUS

MODELS. PLEASE NOTE THAT YOUR SWITCHER HAS BEEN CONFIGURED AS INDI-

CATED BY THE “✔”IN THE “Config as” COLUMN. IF YOUR PROJECTOR MODEL DIF-

FERS FROM THIS CONFIGURATION, YOU MUST RECONFIGURE YOUR SWITCHER

WITH THE CORRECT SETTINGS.

PLEASE REFER TO THE FOLLOWING PAGES FOR COMPLETE CONFIGURATION AND

SIGNAL CONNECTION INSTRUCTIONS.

THIS SWITCHER HAS BEEN CONFIGURED FOR: BARCOCRT

Config Model Rotary Switches Cable SW15 Settings Comm

as RS1 RS2 RS3 RS4 J2/J3 1 2 3 45678910Adapter

RC5 PPM

Barco LCD 5-Wire A 2 0 2 2 J2 ↑↓↑↓↑↓↓ ↑↑↓26-309-01

Barco LCD A 2 0 2 2 J2 ↑↓↑↓↑↓↓ ↓↑↓26-309-01

Barco 5000 9 1 0 2 2 J2 ↑↓↑↓↑↓↓ ↓↑↓26-309-01

✔Barco CRT 8 0 0 2 2 J2 ↑↓↑↓↑↓↓ ↓↑↓26-309-01

Barco 6300/6400 C 4 0 2 2 J2 ↑↓↑↓↑↓↓ ↑↑↓26-309-01

(cable saver mode)

Page1

Extron • System 8/10 PLUS • User’s Manual • P/N 68-399-01 Rev. G

Barco Installation Configuration and Connections

Installation of System 8/10 Plus and Barco LCD with 5-Wire Input

____________

Important note: If S-Video sources are used, five wires must be run to the

projector’s 5-Wire input.

Note: All sources are routed through the RGBHV port of the switcher, and

the switcher is configured in Cable Saver mode. There is no need to run

separate S-Video or Composite video cables to Barco projectors with a 5-

Wire input module. See manual for further information on Cable Saver

modeoperation.

Step 1: Verify switcher configuration switches are set as shown on the

following pages.

Step 2: Verify that the 5-Wire card is in location 2 of the projector (see

diagram)

Step 3: Connect input sources to switcher as shown on the following

pages. Verify that the input configuration switches are set to

match the input type.

Step 4: Connect RGBHV output of the switcher to the 5-Wire input as

shown on the following pages.

Step 5: Connect CC cable and Comm adapter as shown.

Step 6: Power on the projector.

Step 7: Go into the Adjust menu of the projector.

Step 8: Select INSTALLATION from the Adjustment Mode menu.

Step 9: Select 800 PERIPHERAL.

Step 10: Press Enter to toggle out of Standard into 5-wire. 5-wire

configuration requires SW15 DIP switch 8 to be in the up position.

Step 11: Infrared (RC5 or PPM) determines RS1 rotary position. If infrared

is set to RC5, configure RS1 to RC5 setting. If infrared is set to

PPM, configure RS1 to PPM setting.

____________

Important note: The switcher’s RS1 setting must match the projector’s infrared

setting (RC5 or PPM).

Step 12: Exit out of all menus.

Step 13: Switch to each switcher channel with an active input source.

Step 14: For each source input, enter the FILE SERVICE menu and go to

LOAD to configure the projector memory for the source input.

Page2

Extron • System 8/10 PLUS • User’s Manual • P/N 68-399-01 Rev. G

Barco Installation Configuration and Connections

Page3

_ RS5 is for

RGB

switching

delay. See

page 3-4 for

information.

Barco LCD Projector Configuration with 5-Wire Input

Verify that the System 8/10 PLUS is already configured for the Barco LCD

projector. The general setup is explained on page 3-4 and the switch settings for

the projector are repeated below.

1. Use a small screwdriver to remove the access cover from the System 8/10 PLUS

front panel. See bottom of page 3-3. The label on the back of the access cover

may also have the configuration information.

__________ Before changing anything, remove the AC power cord to the System 8/10 PLUS to

set the main power OFF; also turn the projector power OFF.

2. Set the switches as shown below:

Config Model RotarySwitches Cable SW15Settings Comm

as RS1 RS2 RS3 RS4 J2/J3 1 2 3 4 5 6 7 8 9 10 Adapter

RC5 PPM

Barco LCD 5-Wire A 2 0 2 2 J2 ↑↓↑↓↑↓ ↓↑↑↓ 26-309-01

3. Locate the switcher’s Address DIP switches on the rear panel, lower right. Unless

this is part of a host/peripheral system, set #3 and #5 to the up position and the

others down. See picture to the left.

Use the illustration on the next page as a guide to the following steps.

4. Connectthe CommAdapter’s 9-pinmale connector to the9-pin female “Comm

Port” connector on the rear panel of the projector.

5. ConnecttheCC-50'(or CC-100') cablefromthe9-pin male connectoroftheComm

Adapterto the 15-pinHD “Projector Control” port located on the rear panel of the

System 8/10 PLUS. (If you wish to make your own communications cable, see

page3-2.)

______ Secure the screws on all D connectors.

6. Connect the BNC cables from the System 8/10 PLUS outputs to the Barco LCD

projectorinputsaccordingtotheapplicationrequirements.

7. Apply Main Power to the System 8/10 PLUS by connecting the power cord. The

Main Power LED should light. Apply power to the projector.

8. ReturnSystem8/10PLUS and projector tonormaloperation.

Configured For:

RS-232

3456789101 2

SW15 DIP Switch

RS5 RS2

RS2

RS1

RS3

RS4

RS1

RS3 RS4

Extron • System 8/10 PLUS • User’s Manual • P/N 68-399-01 Rev. G

Barco Installation Configuration and Connections

Page4

Barco LCD 5-Wire Projector Connections

Use the illustration below when connecting the System 8/10 PLUS to a Barco

LCD projector. Refer to Barco documentation to continue the installation.

_______ Location 2 for 5-Wire input

________

If the installation includes looping (

host/peripheral

) switchers, see Chapter 5.

If Video Loop Back is part of the installation, see pages 2-10 and 2-11.

9-Pin Female

Br Com

Adapter

26-309-01

RGBHV 5 BNC 15-Pin

Male

Five wires must be used if S-Video

signals are being switched

System 8/10 Plus Input Connection

The four examples which follow illustrate proper user device connections to the

System 8/10 Plus input connectors.

EXAMPLE 1: Connecting to a Composite Video Device - Video Camera

VIDEO CAMERA

COMPOSITE VIDEO

Extron • System 8/10 PLUS • User’s Manual • P/N 68-399-01 Rev. G

Barco Installation Configuration and Connections

EXAMPLE 2: Connecting to an S-Video Device - VCR

EXAMPLE 3: Connecting to any YUV Device* - DVD Player

* To ensure proper decoding and line drive, a CVC 200 interface (shown below) is used to facilitate the installation.

EXAMPLE 4: Connecting to an RGBHV Device* - Computer

*Using an RGB 109 Plus as an interface

VCR

YVU

DVD Player

CVC 200

COMPUTER

RGB 109 PLUS

Page5

Extron • System 8/10 PLUS • User’s Manual • P/N 68-399-01 Rev. G

Barco Installation Configuration and Connections

Page6

InstallationofSystem8/10PlusandBarco6300/6400

____________

Important note: If S-Video sources are used, five wires must be run to the

projector’s 5-Wire input.

Note: All sources are routed through the RGBHV port of the switcher, and

the switcher is configured in Cable Saver mode. There is no need to run

separate S-Video or Composite video cables to Barco projectors with a 5-

Wire input module. See manual for further information on Cable Saver

modeoperation.

Step 1: Verify switcher configuration switches are set as shown on the

following pages.

Step 2: Connect input sources to switcher as shown on the following

pages. Verify that the input configuration switches are set to

match the input type.

Step 3: Connect RGBHV output of the switcher to the 5-Wire input as

shown on the following pages.

Step 4: Connect CC cable and Comm adapter as shown.

Step 5: Power on the projector.

Step 6: Go into the Adjust menu of the projector.

Step 7: Select INSTALLATION from the Adjustment Mode menu.

Step 8: Select 800 PERIPHERAL.

Step 9: Press Enter to toggle out of Standard into 5-wire.

Step 10: Infrared (RC5 or PPM) determines RS1 rotary position. If infrared

is set to RC5, configure RS1 to “C” setting. If infrared is set to

PPM, configure RS1 to “4” setting.

____________

Important note: The switcher’s RS1 setting must match the projector’s infrared

setting (RC5 or PPM).

Step 11: Exit out of all menus.

Step 12: Switch to each switcher channel with an active input source.

Step 13: For each source input, enter the FILE SERVICE menu and go to

LOAD to configure the projector memory for the source input.

Extron • System 8/10 PLUS • User’s Manual • P/N 68-399-01 Rev. G

Barco Installation Configuration and Connections

Page7

_ RS5 is for

RGB

switching

delay. See

page 3-4 for

information.

Barco6300/6400ProjectorConfiguration(cablesavermode)

Verify that the System 8/10 PLUS is already configured for the Barco 6300/6400

projector. The general setup is explained on page 3-4 and the switch settings for

theprojectorarerepeatedbelow.

1. Use a small screwdriver to remove the access cover from the System 8/10 PLUS

front panel. See bottom of page 3-3. The label on the back of the access cover

may also have the configuration information.

__________ Before changing anything, remove the AC power cord to the System 8/10 PLUS to

set the main power OFF; also turn the projector power OFF.

2. Set the switches as shown below. Note: RS1 may be RC5 or PPM.

Config Model RotarySwitches Cable SW15Settings Comm

as RS1 RS2 RS3 RS4 J2/J3 1 2 3 4 5 6 7 8 9 10 Adapter

RC5 PPM

Barco 6300/6400 C 4 0 2 2 J2 ↑↓↑↓↑↓ ↓↑↑↓ 26-309-01

3. Locate the switcher’s Address DIP switches on the rear panel, lower right. Unless

this is part of a host/peripheral system, set #3 and #5 to the up position and the

others down. See picture to the left.

Use the illustration on the next page as a guide to the following steps.

4. Connectthe Comm Adapter’s 9-pinmale connector to the 9-pin female “Comm

Port” connector on the rear panel of the projector.

5. ConnecttheCC-50'(or CC-100') cablefromthe9-pin male connectoroftheComm

Adapterto the 15-pinHD “Projector Control” port located on the rear panel of the

System 8/10 PLUS. (If you wish to make your own communications cable, see

page3-2.)

______ Secure the screws on all D connectors.

6. Connect the BNC cables from the System 8/10 PLUS outputs to the Barco

projectorinputsaccordingtotheapplicationrequirements.

7. Apply Main Power to the System 8/10 PLUS by connecting the power cord. The

Main Power LED should light. Apply power to the projector.

8. ReturnSystem8/10PLUS and projector tonormaloperation.

Configured For:

RS-232

34567891012

SW15 DIP Switch

RS5 RS2

RS2

RS1

RS3

RS4

RS1

RS3 RS4

Extron • System 8/10 PLUS • User’s Manual • P/N 68-399-01 Rev. G

Barco Installation Configuration and Connections

Page8

Barco 6300/6400 Projector Connections

Use the example illustration below (Barco 6400) when connecting the System 8/

10 PLUS to a Barco 6300/6400 projector. Refer to Barco documentation to continue

the installation.

_______ Location2 for 5-Wireinput

________

If the installation includes looping (

host/peripheral

) switchers, see Chapter 5.

If Video Loop Back is part of the installation, see pages 2-10 and 2-11.

System 8/10 Plus Input Connection

The four examples which follow illustrate proper user device connections to the

System 8/10 Plus input connectors.

EXAMPLE 1: Connecting to a Composite Video Device - Video Camera

9-Pin Female

Br Com

Adapter

26-309-01

RGBHV 5 BNC 15-Pin

Male

Five wires must be used if

S-video signals are being switched

MANUAL

REMOTE

R Audio

Video/Y

L Audio

H/HV

AC POWER INPUT

(90 - 260 VAC)

50/60 Hz

LRL

Audio

Level

VIDEO CAMERA

COMPOSITE VIDEO

Extron • System 8/10 PLUS • User’s Manual • P/N 68-399-01 Rev. G

Barco Installation Configuration and Connections

Page9

EXAMPLE 2: Connecting to an S-video Device - VCR

EXAMPLE 3: Connecting to any YUV Device* - DVD Player

* To ensure proper decoding and line drive, a CVC 200 interface (shown below) is used to facilitate the installation.

EXAMPLE 4: Connecting to an RGBHV Device* - Computer

*Using an RGB 109 Plus as an interface

MANUAL

REMOTE

R Audio

Video/Y

L Audio

H/HV

AC POWER INPUT

(90 - 260 VAC)

50/60 Hz

LRL

Audio

Level

COMPUTER

RGB 109 PLUS

YVU

DVD Player

CVC 200

VCR

Extron • System 8/10 PLUS • User’s Manual • P/N 68-399-01 Rev. G

Barco Installation Configuration and Connections

Page10

_ RS5 is for

RGB

switching

delay. See

page 3-4 for

information.

Barco LCD Projector Configuration

Verify that the System 8/10 PLUS is already configured for the Barco LCD

projector. The general setup is explained on page 3-4 and the switch settings for

the projector are repeated below.

1. Use a small screwdriver to remove the access cover from the System 8/10 PLUS

front panel. See bottom of page 3-3. The label on the back of the access cover

also has the configuration information.

__________ Before changing anything, remove the AC power cord to the System 8/10 PLUS

to set the main power OFF; also turn the projector power OFF.

2. Set the switches as shown below:

____________ Be sure that SW15 (below) is set to Cable Saver mode (DIP switch #8 On), as

shown below.

Config Model Rotary Switches Cable SW15 Settings Comm

as RS1 RS2 RS3 RS4 J2/J3 1 2 3 4 5 6 7 8 9 10 Adapter

RC5 PPM

Barco LCD A 2 0 2 2 J2 ↑↓↑↓↑↓ ↓↓↑↓ 26-309-01

3. Use a grease pencil (or other rub-off marker) to mark the space on the label next

to “Barco”.

4. Locate the switcher’s Address DIP switches on the rear panel, lower right. Unless

this is part of a host/peripheral system, set #3 and #5 to the up position and the

others down. See picture to the left.

Use the illustration on the next page as a guide to the following steps.

5. Connect the Comm Adapter’s 9-pin male connector to the 9-pin female “Comm

Port” connector on the rear panel of the projector.

6. Connect the CC-50' (or CC-100') cable from the 9-pin male connector of the

Comm Adapter to the 15-pin HD “Projector Control” port located on the rear

panel of the System 8/10 PLUS. (If you wish to make your own communications

cable, see page 3-2.)

______ Secure the screws on all D connectors.

7. Connect the BNC cables from the System 8/10 PLUS outputs to the Barco LCD

projector inputs according to the application requirements.

8. Apply Main Power to the System 8/10 PLUS by connecting the power cord. The

Main Power LED should light. Apply power to the projector.

9. Return System 8/10 PLUS and projector to normal operation.

Configured For:

RS-232

34567891012

SW15 DIP Switch

RS5 RS2

RS2

RS1

RS3

RS4

RS1

RS3 RS4

Autres manuels pour System 8 Plus

Ce manuel convient aux modèles suivants

Autres manuels Extron electronics Changer

Extron electronics

Extron electronics SW6 VGA A Manuel utilisateur

Extron electronics

Extron electronics SW2 VGA Ars Manuel utilisateur

Extron electronics

Extron electronics VersaTools MSW 4V SDI Manuel utilisateur

Extron electronics

Extron electronics ISM 1WB Manuel utilisateur

Extron electronics

Extron electronics System 4LD xi Manuel utilisateur

Extron electronics

Extron electronics DXP HD 4K Series Manuel utilisateur

Extron electronics

Extron electronics MPS 601 Manuel utilisateur

Extron electronics

Extron electronics SW6 AV MX AS Manuel utilisateur

Extron electronics

Extron electronics 650 UT Manuel utilisateur

Extron electronics

Extron electronics System 10 Plus Manuel utilisateur

Extron electronics

Extron electronics MediaLink Controllers MLC 104 Series Manuel utilisateur

Extron electronics

Extron electronics System 5 IP Series Manuel utilisateur

Extron electronics

Extron electronics TeamWork 601 Manuel utilisateur

Extron electronics

Extron electronics ISS 608 Manuel utilisateur

Extron electronics

Extron electronics FOX3 Matrix Series Manuel utilisateur

Extron electronics

Extron electronics Matrix 12800 Series Manuel utilisateur

Extron electronics

Extron electronics SW6 AV MX AS Manuel utilisateur

Extron electronics

Extron electronics System 8/10 Plus Manuel utilisateur

Extron electronics

Extron electronics System 5cr Manuel utilisateur

Extron electronics

Extron electronics USB HUB4 Series Manuel utilisateur

Extron electronics

Extron electronics SW6 VGA Ars Manuel utilisateur

Extron electronics

Extron electronics DTP T USW 333 Manuel utilisateur

Extron electronics

Extron electronics SW 4 AR MX HV Manuel utilisateur

Extron electronics

Extron electronics System 4LQ xi Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
