Extron electronics SVS 100 Manuel utilisateur

1-2 SVS 100 • Specifications

Specifications — SVS 100 Seamless Video Switcher

Video

Gain ............................................... Unity

Differential phase error .............. 1.5º, 0 to 10 MHz

Differential gain error ................. 1.5%, 0 to 10 MHz

Video input and loopthrough

Number/signal type ................... S-video: 2 inputs, 2 loop-throughs

NTSC/PAL composite video: 4 inputs, 4 loop-throughs

Connectors .................................... 4 4-pin mini-DIN female....... S-video

8 BNC female .......................... composite video

Minimum/maximum levels ...... 0V to 2.0V p-p

Impedance .................................... 75 ohms

Vertical frequency ....................... 50 Hz to 60 Hz

Video processing

Encoder ......................................... 10 bit digital

Video output

Number/signal type ................... 1 S-video

2 composite video

Connectors .................................... 1 4-pin mini-DIN female....... S-video

2 BNC female ......................... composite video

Minimum/maximum levels ...... 0V to 1.0V p-p

Impedance .................................... 75 ohms

Sync

Standards ...................................... NTSC 3.58, PAL

Audio

Gain ............................................... Unbalanced 0dB, balanced +6dB

Frequency response..................... 20 Hz to 20 kHz, ±0.05dB

THD + Noise ................................ 0.03% @ 1 kHz, 0.3% @ 20 kHz at rated maximum output drive

(+19.5dBu input, +21dBu output, balanced/unbalanced)

S/N ................................................ >90dB, output +21dBu, balanced

Crosstalk ....................................... <-80dB @ 1 kHz

Stereo channel separation .......... >80dB @ 1 kHz

CMRR ............................................ >75dB @ 20 Hz to 20 kHz

Audio input

Number/signal type ................... 4 stereo, balanced/unbalanced

Connectors .................................... 4 3.5 mm captive screw connectors, 5-pole

Impedance .................................... 50 kohms unbalanced, 25 kohms balanced, DC coupled

Maximum input level ................. +19.5dBu (balanced/unbalanced) at stated %THD+N

Input gain adjustment................. -15dB to +9dB, adjustable per input via RS-232 or front panel

Audio output

Number/signal type ................... 1 stereo, balanced/unbalanced

Connectors .................................... 1 3.5 mm captive screw connector, 5-pole

Impedance .................................... 50 ohms unbalanced, 100 ohms balanced

Gain error...................................... ±0.1dB channel to channel

Maximum level (Hi-Z) ................ >+21dBu, balanced at stated %THD+N

Maximum level (600 ohm) ......... >+15dBu, balanced at stated %THD+N

0dBu = 0.775 volts (RMS).

1-3SVS 100 • Specifications

Control/remote — video processor

Serial control port ........................ RS-232/RS-422, 9-pin female D connector

Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity

Serial control pin configurations .... 2 = TX, 3 = RX, 5 = GND

Program control ........................... Extron’s control program for Windows

Extron’s Simple Instruction Set™ – SIS™

General

Power............................................. 100VAC to 240VAC, 50/60 Hz, 40 watts, internal

Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing

Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing

Rack mount ................................... Yes, and furniture/wall mountable with included brackets

Enclosure type .............................. Metal

Enclosure dimensions ................. 1.75" H x 17.5" W x 9.5" D (1U high, full rack width)

4.4 cm H x 44.4 cm W x 24.1 cm D

(Depth excludes connectors and knobs.)

Product weight ............................. 5.4 lbs (2.3 kg)

Shipping weight ........................... 9 lbs (4.1 kg)

Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)

Listings .......................................... UL, CUL

Compliances ................................. CE, FCC Class A

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

Specifications are subject to change without notice.

(7.31-110701-D1)
