Extron electronics DMP Plus Series Manuel utilisateur

DMP Plus Series / C V Models

DMP Plus Series / C V AT Models

Patton POTS Configuration Guide

REVISION: 1.0.0

DATE: OCTOBER 16, 2020

Revision Date:

10/16/2020

Page 2 of 28

DMP Plus Series C V / C V AT – Patton POTS

Revision Log

Date

Version

Notes

Oct 16, 2020 1.0.0 Initial Release

Revision Date:

10/16/2020

Page 3 of 28

DMP Plus Series C V / C V AT – Patton POTS

Table of Contents

1.0 Introduction ......................................................................................................................... 5

1.1 Overview of setup ............................................................................................................ 5

1.1.1 Features supported................................................................................................... 5

1.1.2 Features not supported ............................................................................................ 5

1.1.3 DMP Plus Setup......................................................................................................... 5

1.1.4 Patton POTS interface............................................................................................... 6

1.1.5 Wiring........................................................................................................................ 6

2.0 Configuring Patton POTS interface for DMP Plus Series C V (AT) VoIP ............................... 7

2.1 Ordering Information ....................................................................................................... 7

2.1.1 Patton SN4112/JO/EUI - VoIP Gateway 2 FXO Ports ................................................ 7

2.1.2 Firmware used during testing: R6.11 2019-07-02 ................................................... 7

2.2 Setting IP address on Patton............................................................................................ 7

2.2.1 Setting the IP address via DataViewer...................................................................... 7

2.3 Upload configuration into Patton POTS interface ........................................................... 9

2.3.1 Login to Webpage ..................................................................................................... 9

2.3.2 Patton Firmware/Software ....................................................................................... 9

2.4 Upload configuration File............................................................................................... 11

2.4.1 To restart / reload, select Reload in the lower left ................................................ 12

2.4.2 If any changes are made, they will need to be saved to the startup-config .......... 12

2.5 Adjust auto hang-up / Call disconnection...................................................................... 13

2.5.1 Adjust auto hang-up and Call disconnection if necessary ...................................... 13

3.0 Configuring DMP Plus Series C V (AT) VoIP Lines .............................................................. 14

3.1 Network Interface Configuration ................................................................................... 14

3.2 Transport Configuration................................................................................................. 16

3.3 Line Registration............................................................................................................. 17

3.4 Codecs ............................................................................................................................ 18

3.5 Dialing............................................................................................................................. 19

3.6 System Overview............................................................................................................ 20

3.7 Troubleshooting ............................................................................................................. 20

Revision Date:

10/16/2020

Page 4 of 28

DMP Plus Series C V / C V AT – Patton POTS

Appendix A: Configuration Files – Attached to PDF ..................................................................... 21

Appendix B: How to manually set the IP address of the Patton SN4112................................... 22

Appendix C: How to import configuration into DMP Plus............................................................ 23

Appendix D: Patton RS-232 Cable wiring detail............................................................................ 24

Appendix E: Copy of DMP Plus VoIP Configuration ...................................................................... 25

Appendix F: Copy of Patton configuration.................................................................................... 26

Revision Date:

10/16/2020

Page 5 of 28

DMP Plus Series C V / C V AT – Patton POTS

1.0 Introduction

This document provides essential instructions for configuring the VoIP lines of DMP Plus Series,

C V and C V AT models, with the Patton SN 4110 Series FXO.

DMP Plus Relates to the following products:

•DMP 128 Plus C V / C V AT

•DMP 128 FlexPlus C V AT

•DMP 64 Plus C V / C V AT

1.1 Overview of setup

VoIP Line 1 in the DMP Plus will be directly connected to the LAN interface of the Patton POTS

interface. This does not need to be connected to a network. The DMP Plus will not register to a

call server or Patton POTS interface.

The DMP Plus and Patton POTS interface need to be located on the same subnet / VLAN

Features supported

•POTS interface will support a single POTS line on FXO Port 0/0

•Hold is supported

1.1.1 Features not supported

•3-Way calling is not supported

•Hook Flash is not supported

•VoIP Dialer in DSP Configurator Software will not work since the line does not

1.1.2 DMP Plus setup

•Firmware: 1.06.0000 or Higher

•Line 1: Ext 1001

•LAN2 IP address: 192.168.1.254 / 255.255.255.0

•LAN2 port of the DMP Plus

Figure 1 DMP 64 Plus C V AT – Rear

Figure 2 DMP 128 Plus C V AT - Rear

LAN

Revision Date:

10/16/2020

Page 6 of 28

DMP Plus Series C V / C V AT – Patton POTS

1.1.3 Patton POTS interface

•LAN port

•IP Address: 192.168.1.253 / 255.255.255.0

•Firmware: R6.11 2019-07-02

1.1.4 Wiring

•Using a CAT5/6 network cable

oDirectly connect LAN 2 of DMP Plus to

oPatton 10/100 ENET port / ETH 0/0 port

Figure 3 DMP 64 C V AT Plus Figure 4 Patton SN4112/JO/EUI

•Connect the analog Telephone POTS line to the Voice Port FXO 0/0

oPort 1

Figure 5 Patton SN4112/JO/EUI – Rear Panel Figure 6 Analog Phone Line – POTS

Revision Date:

10/16/2020

Page 7 of 28

DMP Plus Series C V / C V AT – Patton POTS

2.0 Configuring Patton POTS interface for DMP Plus Series C V (AT) VoIP

This section will guide you through the setup of the Patton POTS interface.

2.1 Ordering Information

The Patton Smart Node VoIP Gateway has multiple different models.

Note: When purchasing the Patton POTS interface, make sure to purchase the model

with FXO ports. Units with FXS ports will not work.

2.1.1 Patton SN4112/JO/EUI - VoIP Gateway 2 FXO Ports

oProduct page:

https://www.patton.com/voip-gateway/sn4110/

2.1.2 Firmware used during testing: R6.11 2019-07-02

•SN4110_H323_SIP_R6.11_2019-07-02

•Firmware can be downloaded at patton.com

ohttps://www.patton.com/support/upgrades/index.asp?um=S

martNode%20411x

2.2 Setting IP address on Patton

The Patton SmartNode default configuration has Interface Ethernet 0 (ETH0) set to

DHCP from the factory. The attached configuration (Patton_Config.cfg) needs to be

uploaded via the internal webpage on the Patton SN4112/JO/EUI VoIP Gateway.

2.2.1 Setting the IP address via DataViewer

Utilizing the included console cable that comes with the Patton POTS interface:

•Connect the RJ-45 to Port labeled “Console” on the front of the Patton

•Connect the RS-232 DB-9 to your computer

Revision Date:

10/16/2020

Page 8 of 28

DMP Plus Series C V / C V AT – Patton POTS

•Using Extron DataViewer connect to the Patton POTS interface via RS-232

oDownload the attached file “DataViewer Set Patton IP address.txt” from the PDF

Refer to Appendix A to download the files from the PDF

oOpen Extron DataViewer

oClick Connect from the toolbar

File -> Connect (ALT+E)

oSelect the RS-232 Tab

Setup the port:

•Com Port (select COM port on your computer)

•Baud Rate: 9600

•Parity Bit: None

•Data Bit: 8

•Stop Bit: 1

•Handshake: None

oPress OK/Enter until you see “login:”

•Once connected to the Patton and you see login:

•In DataViewer select “Run Script from the menu bar

oTools -> Send Script File ( ALT + F )

oSelect DataViewer Set Patton IP address.txt and Click Open

Refer to Appendix A to download the files from the PDF

•The Script will set the IP address to

o192.168.1.253 / 255.255.255.0

Revision Date:

10/16/2020

Page 9 of 28

DMP Plus Series C V / C V AT – Patton POTS

2.3 Upload configuration into Patton POTS interface

After the IP address has been setup on the Patton POTS interface, the attached

configuration file must be uploaded via the webpage interface.

2.3.1 Login to Webpage

•Connect to the internal Webpage via the IP address of the unit set in

the previous step

ohttp://192.168.1.253

othe factory defaults for logging in:

login: administrator

Password: (leave the password empty )

2.3.2 Patton Firmware/Software

•This configuration guide was developed using firmware R6.11

oif firmware is up to date skip to 2.3.3 Upload configuration File

•The Software/Firmware information is displayed on the main page

when you log in:

•If the software/Firmware needs to be updated:

•First download the Software from patton.com:

ohttps://www.patton.com/support/upgrades/index.asp?um=SmartNode%20411x

•Connect to the webpage on the Patton POTS interface

ohttp://192.168.1.253

othe factory defaults for logging in:

login: administrator

Password: (leave the password empty )

•From the Patton webpage Select Import/Export, Upper Left corner

Revision Date:

10/16/2020

Page 10 of 28

DMP Plus Series C V / C V AT – Patton POTS

•Select Import Firmware

•Follow the instructions below

oShutdown VoIP Gateways

oFirmware upload

oOnce the VoIP Gateways are shut down the Download firmware dialog will appear

oSelect “Choose file” and select the downloaded ZIP file.

oSelect Import

oFirmware will download and be programmed into the Patton POTS interface.

oOnce the firmware update is complete, the box will need to be Reload/Restarted before the

update will take effect.
