Introduction

Congratulations on your purchase of the Extech Conductivity / pH meter. For best

results, please read the entire manual before use.

The EC600 meter measures Conductivity, pH, and temperature parameters.

Conductivity measurements also yield TDS (total dissolved solids), Salinity, and

Resistivity readings.

The built-in microprocessor provides automatic calibration, automatic temperature

compensation, data storage, and self-diagnostics. The meter can recognize up to 13

types of pH standard buffer solutions and 8 types of Conductivity standards.

The meter’s digital filter improves measurement speed and accuracy.

Two special modes (for distilled water and distilled water mixed with ammonia) are

provided.

The meter offers a backlit LCD display and is dust-proof and water-proof, meeting the

IP57 rating

This meter is shipped fully tested and calibrated and, with proper use, will provide years

of reliable service.

Supplied Equipment List

•EC6000 Meter

•Conductivity and pH Electrodes

•Standard pH buffer solutions (4.00pH, 7.00pH, and 10.01pH) / 50ml

•Standard Conductivity solution (1413µS/cm) / 50ml

•Screwdriver (for removing battery compartment)

•Batteries (2 x ’AA’ 1.5V)

•User’s Guide

•Carrying Case

www.burntec.comwww.burntec.com

EC600 V2.0 4/10

Meter Description

1. LCD Display (detailed in section below)

2. Rubber protective jacket (remove to access the rear battery compartment)

3. Keypad (detailed in section below)

4. Electrode connection jack

5. Electrode plug

6. Electrode cable

Display Description

1. Measurement type icon

2. Measured reading

3. 888 (Stored data serial number), M+ (measurement to be stored icon), RM (reading to

be recalled icon)

4. Units of measure

5. Temperature reading

6. Stable measurement icon

7. Calibration icons

8. Low battery icon

www.burntec.comwww.burntec.com

EC600 V2.0 4/10

Keypad Description

The meter has five (5) front panel function keys:

ON/OFF Power Key

Calibration Key:

a) When taking a measurement, press this key to enter the calibration mode

b) When in the programming mode, press this key to change the displayed

number or the ON/OFF state

Function Key

a) In pH measuring mode, one short press switches between pH and mV

measuring modes. One long press (>2s) enters the parameter setting mode.

Subsequent presses will scroll through the available parameters.

b) In other measuring modes, press and hold to enter the parameter setting

modes. The meter will scroll through the available parameters

Backlight and ENTER Key

a) In the measurement mode, momentary presses toggle the backlight on and off

b) When in the programming or calibration mode, press to ENTER data

c) When in the pH mode, press and hold to change the resolution in the range of

0.01 to 0.1pH

d) When in the Conductivity mode, press and hold to scroll through the TDS,

Salinity, Resistivity, and Conductivity modes

MEMORY STORE and RECALL Key

a) In the measurement mode, momentary presses store the displayed readings.

Press and hold for at least 2 seconds to recall a saved reading

b) In programming mode, press to change the displayed number or ON/OFF state

Store, Recall, and Clear Datalogger Memory

STORE Readings

The meter can store up to 100 pH, 100 mV, and 100 Conductivity readings for a total of

300 data points. To store a reading, wait until the reading stabilizes (the smiling face icon

appears when the reading stabilizes). Press the M+/RM key momentarily to store a

reading. The M+ icon appears and the data point serial number increments.

RECALL Readings

In the measurement mode, press the M+/RM key to recall the most recently stored

reading. RM and the data point serial number for the displayed reading will appear on the

LCD. The measurement information will appear on the lower right hand side of the LCD.

Use the CAL or M+/RM buttons to scroll the remaining stored readings. Press the ENTER

key to return to the normal measurement mode.

CLEAR Readings

From the RECALL mode, press and hold the ENTER key for at least five (5) seconds. The

LCD display will show ‘CLR’ indicating that all of the stored readings have been erased.

www.burntec.comwww.burntec.com

EC600 V2.0 4/10

The unit will automatically return to the normal measurement mode after approximately 2

seconds.

www.burntec.comwww.burntec.com

EC600 V2.0 4/10

pH Measurement Mode

Preparation for Measurement

1. Turn the meter ON using the power key

2. Connect the pH electrode to the meter and the pH mode will automaticaly be selected.

3. Unscrew the protective cap on the probe jack located on the bottom of the meter (store

the protective cap in the carrying case for later use)

4. Carefully connect the pH probe to the meter’s probe jack. The probe can only be

inserted in one orientation. Once it is firmly connected, screw the probe collar onto the

meter to secure the probe

3-Point Calibration (7.00pH, 4.00pH and 10.01pH)

1. Press the CAL key to enter the Calibration mode. The meter’s display will show a

blinking ‘C1’

2. Rinse the probe in distilled water, allow it to air dry, and submerge it into a pH 7.00

buffer solution. Stir the solution briefly and allow it to stay in the buffer solution until a

stable reading is reached

3. Press CAL again and the display will show a blinking ‘7.00’

4. This portion of the calibration procedure is complete when the display stops blinking

and shows the ‘C2’ icon. The unit will automatically switch to the second point of the

calibration

5. Rinse the probe in distilled water again, allow it to dry, and submerge it into a pH 4.00

buffer solution. Stir the solution briefly and allow it to stay in the buffer solution until a

stable reading is reached

6. Press CAL again and the display will show a blinking ‘4.00’

7. This portion of the calibration procedure is complete when the display stops blinking

and shows the ‘C3’ icon. The unit will automatically switch to the third point of the

calibration

8. Rinse the probe in distilled water again, allow it to dry, and submerge it into a pH 10.01

buffer solution. Stir the solution briefly and allow it to stay in the buffer solution until a

stable reading is reached

9. Press CAL again and the display will show a blinking ‘10.01’

10. After the display stabilizes the 3-point calibration icon will appear

1-Point and 2-Point Calibration

Note that the user can calibrate one or two points only, if the expected measurement is

known.

For example, if the expeced pH is 4pH, it is acceptable to perform only a 1-Point

Calibration (4pH). If the expected measurement is between 4.00pH and 7.00pH, the user

can perform a 2-Point Calibration (4.00 and 7.00pH), and so on.

For a 4pH calibration, only the circled Lwill appear on the LCD. For a 7.00pH, only the

circled Mwill appear on the LCD. For a 10.01pH Calibration, only the circled Hwill appear

(Low, Medium, and High).

Note: Use the ENTER key to exit the Calibration mode and return to the normal

measurement mode when performing 1 or 2 point calibrations.

For all other applications, a 3-Point Calibration is recommended. Always perform a 3-Point

Calibration on new probes and probes that have been in use for long periods. This

maximizes measurement slope linearity.

www.burntec.comwww.burntec.com

EC600 V2.0 4/10

Testing the pH of a Sample

1. Perform the pH Calibratoin as described above

2. Rinse and dry the pH Probe and submerge it in a sample liquid

3. Stir the solution briefly with the probe and allow it to stand until the display stabilizes

4. Note that the closer the temperature of the sample solution to the calibration solution,

the more accurate readings

Programming pH Parameters

The Table below shows the available programming menu items P1 ~ P7. Each parameter

is explained in detail in the subsequent sections.

Parameters Code Selections

P1 pH buffer solution series selection USA (Europe & U.S.A)

NIS (NIST)

CH (China)

P2 Distilled water pH temperature

compensation setting (see notes

below this Table)

OFF / ON

P3 Distilled water with Ammonia pH

temperature compensation setting

(see Notes below this Table)

OFF / ON

P4 Temperature unit setting ℃/ ℉

P5 Back light display time setting 0-1-3-6min

P6 Auto power off setting 0-10-20min

P7 Restore to default factory settings OFF / ON

Notes on P2 and P3 Parameters: Measurements of distilled water and distilled water

mixed with ammonia affect the temperature compensation and the slope linearity of the pH

probe. Such measurements are sometimes used in the electrical power and petrochemical

industries. Set these parameters to ON only if necessary, otherwise leave these

parameters in the OFF state.

www.burntec.comwww.burntec.com

EC600 V2.0 4/10

Parameter P1 (pH Buffer Solution Setting)

1. From the pH measurement mode, press and hold MODE for at least 2 seconds and

then release, the ‘P1’ icon appears on the LCD

2. Use the CAL or the M+/RM keys to toggle through the three (3) selections: USA (for

use in the USA or Europe, NIS (for NIST calibration purposes), and CH (for use in

China)

3. Momentarily press MODE to move to the next parameter (P2), or press ENTER to

return to the normal measurement mode

Parameter P2 (Distilled Water Temperature Compensation Setting)

1. From the P2 menu, use the CAL or the M+/RM keys to turn this feature ON or OFF

2. Momentarily press MODE to move to the next parameter (P3), or press ENTER to

return to the normal measurement mode

Parameter P3 (Distilled Water with Ammonia Temperature Compensation Setting)

1. From the P3 menu, use the CAL or the M+/RM keys to turn this feature ON or OFF

2. Momentarily press MODE to move to the next parameter (P4) or press ENTER to

return to the normal measurement mode

Parameter P4 (Temperature Measurement Units Setting)

1. From the P4 menu, use the CAL or the M+/RM keys to turn this feature ON or OFF

2. Momentarily press MODE to move to the next parameter (P5) or press ENTER to

return to the normal measurement mode

Parameter P5 (Display Backlight Setting)

1. From the P5 menu, use the CAL or the M+/RM keys to select 0, 1, 3, or 6 minute

default backlighting time

2. Momentarily press MODE to move to the next parameter (P6) or press ENTER to

return to the normal measurement mode

Parameter P6 (Automatic Power OFF Setting)

1. From the P6 menu, use the CAL or the M+/RM keys to select a 0, 10, or 20 minute

Auto Power OFF time

2. Momentarily press MODE to move to the next parameter (P7) or press ENTER to

return to the normal measurement mode

Parameter P7 (Restore Factory Default Settings)

1. From the P7 menu, use the CAL or the M+/RM keys to select ON (reset the factory

default settings) or OFF (cancel edit)

2. Momentarily press MODE to move to the first parameter (P1) or press ENTER to return

to the normal measurement mode

www.burntec.comwww.burntec.com

EC600 V2.0 4/10

pH Measurement, Calibration, and Electrode Considerations

•Error messages ERR-1: Electrode zero potential error and ERR-2: Electrode slope

error; For either error, check the following:

1. Air bubbles in the electrode bulb. Shake rigorously to remove air bubbles

2. Accuracy of the pH buffers used in calibration. Replace buffers if necessary

3. Set meter to its factory default state in Parameter P7 (previous section of manual)

•Calibration intervals depend on the sample, the electrode performance, and the

required accuracy. For high accuracy measurements (≤±0.02pH), the meter should be

calibrated immediately before taking a measurement. For general accuracy (≥±0.1pH),

the meter can be calibrated and used for approximately one week before the next

calibration.

•The meter must be recalibrated in the following situations:

1. New probe, or probe that is unused for a long period of time

2. After measuring acids (pH<2) or alkaline solutions (pH>12)

3. After measuring a solution that contains fluoride or a concentrated organic solution

4. If the solution’s temperature differs widely from the calibration solution temperature

•The soaking solution contained in the supplied protective bottle is used to maintain

activation in the glass bulb and junction. Loosen the capsule, remove the electrode and

rinse in distilled water before taking a measurement. Insert the electrode and tighten

the capsule after measurements to prevent the solution from leaking. If the soak

solution is turbid or moldy, replace the solution.

•To prepare a soak solution: Use 25g pure KCL dissolved with purified water and diluted

to 100mL. The electrode should not be soaked in a purified water protein solution or an

acid fluoride solution for long periods of time. In addition, do not soak the electrode in

organic silicon lipids.

•For calibration accuracy, the pH of the standard buffer solution must be reliable. The

buffer solution should be refreshed often, especially after heavy use.

•For best accuracy, always keep the meter clean and dry, especially the meter’s

electrode and electrode jack. Clean with medical cotton and alcohol if necessary.

•The sensitive glass bulb at the front of the combination electrode should not come in

contact with hard surfaces. Scratches or cracks on the electrode will cause inaccurate

readings. Before and after each measurement, the electrode should be washed with

distilled water and air dried. Do not clean the glass bulb with a tissue for it will affect the

stability of the electrode potential and increase the response time. The electrode

should be thoroughly cleaned if a sample sticks to the electrode. Use a solvent if the

solution does not appear clean after washing.

•Electrodes that have been used over a long period of time, used in a strong solution

that has damaged the sensitive bulb, or used with a substance resulting in a jam at the

junction will be become passivated; the sensitivity will decrease, its response will slow,

and the readings will be inaccurate. Replace the electrode as soon as possible in these

cases.

•For abnormal readings, try calibrating again; if the problem persists replace the

Electrode. The user can also try resetting the meter to factory default conditions per

Parameter P7 (detailed in an earlier section). Electrode life can be shortened by heavy

use, extreme conditions, and improper maintenance.

www.burntec.comwww.burntec.com

EC600 V2.0 4/10

mV Measurement Mode

1. Turn the meter ON using the power key

2. Momentarily press MODE to switch to the mV mode, if necessary

3. Connect the probe to the meter

4. Immerse the electrode in the sample solution, slowly stir the solution with the

electrode and then allow it to rest in the solution

5. When the smile face icon appears on the LCD, the reading has stabilized

mV Programming Parameters

Prompt Parameters Code Settings

P1 Back light display time

0 -1-3-6 min

P2 Auto power off time

0 -10-20 min

Parameter P1 (Display Backlight Setting)

1. Press MODE to access the P1 Parameter

2. Use the CAL or the M+/RM keys to select 0, 1, 3, or 6 minute default backlighting

time

3. Momentarily press MODE to move to the next parameter (P2) or press ENTER to

return to the normal measurement mode

Parameter P2 (Automatic Power OFF Setting)

1. From the P2 menu, use the CAL or the M+/RM keys to select a 0, 10, or 20 minute

Auto Power OFF time

2. Momentarily press MODE to move back to Parameter P1, or press ENTER to

return to the normal measurement mode

www.burntec.comwww.burntec.com

Table des matières

Autres manuels Extech Instruments Instrument de mesure

Extech Instruments

Extech Instruments AN100-NIST Manuel utilisateur

Extech Instruments

Extech Instruments RH600 Manuel utilisateur

Extech Instruments

Extech Instruments SDL800-NIST Manuel utilisateur

Extech Instruments

Extech Instruments MZ13604 Manuel utilisateur

Extech Instruments

Extech Instruments Oyster 341350A-P Manuel utilisateur

Extech Instruments

Extech Instruments LT250W Manuel utilisateur

Extech Instruments

Extech Instruments HT30 Manuel utilisateur

Extech Instruments

Extech Instruments 480846 Manuel utilisateur

Extech Instruments

Extech Instruments CO250 Manuel utilisateur

Extech Instruments

Extech Instruments 475040-SD Manuel utilisateur

Extech Instruments

Extech Instruments MS400 Manuel utilisateur

Extech Instruments

Extech Instruments 407355 Manuel utilisateur

Extech Instruments

Extech Instruments VB450 Manuel utilisateur

Extech Instruments

Extech Instruments TKG250 Manuel utilisateur

Extech Instruments

Extech Instruments 461893 Manuel utilisateur

Extech Instruments

Extech Instruments 461895 Manuel utilisateur

Extech Instruments

Extech Instruments 407113 Manuel utilisateur

Extech Instruments

Extech Instruments SDL730 Manuel utilisateur

Extech Instruments

Extech Instruments 407510 Manuel utilisateur

Extech Instruments

Extech Instruments 407445 Manuel utilisateur

Extech Instruments

Extech Instruments SDL400 Manuel utilisateur

Extech Instruments

Extech Instruments SDL300-NIST Manuel utilisateur

Extech Instruments

Extech Instruments SDL600-NIST Manuel utilisateur

Extech Instruments

Extech Instruments 380941 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
