Extech Instruments DT200 Manuel utilisateur

User Guide

Laser Distance Meter

Extech DT200

DT200

DT200-EU-EN-V2.0 4/12

Introduction

Congratulations on your purchase of the Extech Model DT200 Laser Distance Meter. This meter

measures Distance up to 35m (115’) and calculates Area and Volume. In addition, the DT200

includes a laser pointer for accurate targeting. This meter is shipped fully tested and calibrated

and, with proper use, will provide years of reliable service.

Safety Instructions

This meter has been designed for safe use, but must be operated with caution.

WARNING: Do not directly view or direct the laser pointer at an eye. Low power visible lasers

do not normally present a hazard, but may present some potential for hazard if viewed directly

for extended periods of time.

Laser classification (Class 2)

The DT200 produces a visible Class 2 laser beam from the top of

the instrument. Do not stare into the laser beam or direct the beam

toward anyone’s eyes. Eye protection is normally an automatic

response (‘blink reflex’, for example).

Warning: Do not look directly into the laser beam using optical

aids such as binoculars or telescopes. This can create a hazard.

Permitted Uses

Measure Distances

Compute Area and Volume

Measure Angles

Prohibited Uses

Exceeding the specified measurement limits

Compromising or deactivating the safety systems built into the meter

Removal of hazard or explanatory labels affixed to the meter

Modifying or converting the instrument

Using third party accessories

Operation on scaffolding or ladders without proper safety precautions

Measuring near machines that are operating or near parts of machine installations that are

unprotected

Aiming the meter into the sunlight

Outdoor measurements or measurements on roads, near construction sites, etc. without

adequate safeguards

DT200-EU-EN-V2.0 4/12

Meter Description

Front Panel

1. Laser Pointer

2. Laser Test Beam

3. LCD display area

4. Keypad (described below)

5. Battery compartment on rear of instrument

Display

1. Laser Status icon appears when laser is active

2. Reference level (Top)

3. Reference Level (Bottom)

4. Area, Volume, and Indirect Measurement icons

5. Single Distance Measurement mode

6. Battery status icon

7. Reading Memory Location Number

8. Error icon

9. Continuous MIN-MAX measurement mode

10. Display Line 1

11. Display Line 2

12. Display Line 3 (Summary Display Line)

Keypad

Power ON / Measurement Button

CLEAR / Power OFF Button

Measurement Reference Button

Backlight / Unit Button

MAX-MIN Continuous Measurement Button

Indirect Measurement Button

Memory Button

Add/Subtract Buttons

Area-Volume Button

DT200

DT200-EU-EN-V2.0 4/12

Operating Instructions

Measurement Considerations

1. For best results, choose a target that is flat, hard and smooth

2. Use a section of cardboard or similar material if the target size needs to be increased

3. Replace the battery if the battery icon appears on the display

4. The meter will not measure through glass, liquid, or Styrofoam

5. Inaccurate measurements may result from any of the following:

Low battery

Measured distance exceeding specified range

Irregular shaped objects near the target

Preparation for Measurements

1. Press the MEAS button to switch the meter ON. The unit automatically switches OFF after

three (3) minutes of inactivity.

2. Press and hold the UNIT button to change the unit of measure (ft = feet, in = inches, m =

meters, and ‘ “ (feet and inches).

3. Use the reference button to select the Top or Bottom distance reference.

In the Top mode (2), the displayed reading will represent the distance from the top of the

meter to the target.

In the Bottom mode (1), the displayed reading will represent the distance from the bottom of

the meter to the target.

Single Distance Measurement

1. Momentarily press the MEAS button to switch the meter ON; Dashes (- - -) will appear on the

display and the Laser pointer will switch ON.

2. Aim the meter and momentarily press the MEAS button again to take and display a reading.

3. The reading will remain on the display for 60 seconds.

DT200-EU-EN-V2.0 4/12

MAX-MIN Continuous Measurement Mode

This mode of operation is useful for determining the shortest and longest distances from a given

point.

1. Press the MEAS button to switch the meter ON.

2. Press and Hold the MAX/MIN button for 3 seconds to begin a continuous measurement

session.

3. The meter will beep with each new measurement update (approx. every one half second).

4. The MIN reading will be indicated on the top display line and will update each time a lower

reading (lower than the currently displayed reading) is encountered.

5. The MAX reading will be indicated on the middle display line and will update each time a

higher reading is encountered.

6. The actual reading will be indicated on the bottom display line.

7. To exit this mode of operation, momentarily press the MEAS button.

8. Note that the meter exits to the normal mode of operation after approx. 100 measurements in

continuous mode.

Adding / Subtracting Measurements

A series of measurements can be taken and the sum or difference can be displayed.

1. Press the MEAS button to switch the meter ON.

2. Press the MEAS button to take the first measurement.

3. Press the + button or the - button (+ or – will appear in the display flashing).

4. Press the MEAS button again to take another measurement.

5. The two individual measurements will be shown on display lines 1 and 2.

6. The sum or difference will be indicated on display line 3.

7. Repeat the above steps as desired.

Area Calculation

The DT200 allows the user to compute the area of a room.

1. Press the MEAS button to turn the meter ON; wait several seconds and the Laser pointer will

switch ON.

2. Press the button firmly once.

3. A parallelogram will appear with its length side flashing

indicating that a Length measurement is to be taken.

4. Aim the meter and press MEAS to take the room length measurement.

5. Press the MEAS again to switch the Laser Pointer back ON.

6. The parallelogram will now appear with its Width side flashing

indicating that a Width measurement is to be taken.

7. Press MEAS to take the room width measurement.

8. Lines 1, 2, and 3 will now show the Length, Width, and Area (in ft2or m2) respectively.

Note that the laser pointer will switch off automatically if too much time is taken between the steps

above. If this occurs, simply press the MEAS button to switch the Laser pointer back ON and then

continue following the steps.

DT200-EU-EN-V2.0 4/12

Volume Calculation

The DT200 allows the user to compute room Volume.

1. Press the MEAS button to switch the meter ON. Wait several seconds and the Laser pointer

will automatically switch ON.

2. Press the button firmly twice (allow a second or so between presses).

3. A cube shape will appear with its Length side flashing indicating that a Length

measurement is to be taken.

4. Press MEAS to take the room Length measurement.

5. The cube’s Width side will now be flashing indicating that a Width measurement is to be

taken.

6. Press MEAS to switch the Laser pointer ON again.

7. Press MEAS again to take the room Width measurement.

8. The cube’s Height side will now be flashing indicating that a Height measurement is to be

taken.

9. Press MEAS to switch the Laser pointer ON again.

10. Press MEAS to take the room Height measurement.

11. Lines 1, 2, and 3 will now show the Length, Width, and Area (in ft3 or m3) respectively. Note that

the individual Height measurement is NOT displayed.

Indirect Measurements (Using Two Measurements)

The DT200 can measure the vertical height from Point 1 to Point 2 with the operator taking the

measurement from Point X. This is accomplished using two measurements.

1. Press the MEAS button to switch the meter ON.

2. Press the button once. Wait several seconds and the Laser pointer will automatically

switch ON.

3. A right triangle shape will appear with its diagonal line flashing.

4. From exactly Point X, aim the instrument at Point 1 and press MEAS. One reading is now

complete and the bottom line of the right triangle will begin flashing.

5. From Point X, align the meter as horizontal as possible and aim for Point 2 and then press

MEAS. The laser pointer will switch ON.

6. Press MEAS again to take the second measurement.

7. The second measurement is now complete.The lower display line indicates the vertical

distance from Point 1 to Point 2.

DT200-EU-EN-V2.0 4/12

Indirect Measurements (Using Three Measurements)

The DT200 can measure height in two segments by taking three measurements. The operator

stands at Point X. The first measurement is Point X to 1, the second measurement is a horizontal

line from Point X to 2, and the third measurement is from Point X to 3.

1. Press the MEAS button to switch the meter ON. Wait several seconds and the Laser pointer

will switch ON.

2. Press the button two times.

3. The triangle icon will appear with its bottom diagonal line flashing.

4. From Point X aim the instrument at Point 1 and press MEAS. One reading is now complete

and the middle line of the triangle will begin flashing.

5. Press MEAS again to turn on the laser pointer to prepare for the next measurement.

6. From Point X, aim the instrument horizontally at a Point 2 and press MEAS. The second

reading is now complete and the top diagonal line of the triangle will begin flashing.

7. Press MEAS to turn on the laser pointer and prepare for the third measurement.

8. From Point X, aim the instrument at Point 3 and press MEAS. The third measurement is now

complete.

9. The distance from Point 1 to Point 3 will now be indicated on the bottom display line.

DT200-EU-EN-V2.0 4/12

Storing and Recalling Readings

The DT200 stores up to twenty (10) readings in memory for later recall.

1. Take a reading as previously described.

2. With the reading displayed, press the button.

3. The reading will be stored in location 1.

4. Take another reading press the store button. This new reading will be stored in location 1 and

the previous reading from location 1 will be moved to location 2.

5. When all twenty locations have been filled the meter begins overwriting the existing readings.

6. The memory location number is indicated on the upper left hand area of the display (1 to 20).

7. Use the + and – bottons to scroll through the the stored readings.

8. To clear all readings, enter the memory mode using the Memory button and then press

and hold the CLR and the Memory buttons until the displayed memory location reading value

switches to zeros.

DT200-EU-EN-V2.0 4/12

Maintenance

WARNING: Do not operate the meter until the battery compartment cover is in place and fastened

securely.

This instrument is designed to provide years of dependable service, if the following care instructions

are performed:

1. Keep the meter dry and free from dust.

2. Use and store the meter in nominal temperature conditions. Temperature extremes can

shorten the life of the electronic parts and distort or melt plastic parts.

3. Handle the meter carefully and avoid shock and vibration. Dropping the meter may

damage the electronic parts or the case.

4. Keep the meter clean. Wipe the case occasionally with a damp cloth. DO NOT use chemicals,

cleaning solvents, or detergents.

5. Use only fresh batteries of the correct type. Remove old or weak batteries so they do not

leak and damage the unit.

6. If the meter is to be stored for long periods, the batteries should be stored separately to

prevent damage to the unit.

Battery Installation/Replacement

When the low battery symbol appears on the display or when the display does not switch ON,

replace the two (2) ‘AAA’ batteries.

1. Switch the instrument off before replacing the batteries.

2. Remove the rear battery compartment cover by sliding the grooved latch on the meter bottom

toward the rear of the meter.

3. Replace the two (2) ‘AAA’ batteries observing polarity.

4. Replace the battery compartment cover.

You, as the end user, are legally bound (Battery ordinance) to return all used batteries

and accumulators; disposal in the household garbage is prohibited!

You can hand over your used batteries / accumulators at collection points in your

community or wherever batteries / accumulators are sold!

Disposal: Follow the valid legal stipulations in respect of the disposal of the device at the

end of its lifecycle

Display Error Codes

204 – Calculation Error (Retry the procedure)

208 – Received signal too weak (Use target plate)

209 – Received signal too strong (Target too reflective, use target plate)

252 – High Temperature (Cool down the instrument)

253 – Low Temperature (Warm up the instrument)

255 – Hardware error (Return the instrument for service)

Wrench icon – Hardware error (Return the instrument for service)

DT200-EU-EN-V2.0 4/12

Specifications

General Specifications

Laser diode Class 2 red laser (wavelength: 635nm)

Battery Two (2) ‘AAA’ alkaline batteries

Dust/Splash Proof IP 54

Operating conditions 32 to 104°F (0 to 40°C)

Storage conditions 14 to 140°F (-10 to 60°C)

Dimensions 4.5 x 1.9 x 1.1” (115 x 48 x 28mm)

Weight 5.3 oz. (150g)

Recommended use For indoor use only

Range Specifications

Distance Range 0.1 to 35m (4” to 115’)

Resolution 0.001 inches, feet, or meters

Accuracy ±2mm (± 0.08”)

Displayed Calculation Ranges

Length 99’ 11” (99.99m)

Area 999.99 sq. ft. (999.99m2)

Volume 999.99 cu. ft. (999.99m3)

www.extech.com

Table des matières

Autres manuels Extech Instruments Instrument de mesure

Extech Instruments

Extech Instruments AN510 Manuel utilisateur

Extech Instruments

Extech Instruments CO80 Manuel utilisateur

Extech Instruments

Extech Instruments CO10 Manuel utilisateur

Extech Instruments

Extech Instruments 475055 Manuel utilisateur

Extech Instruments

Extech Instruments SDL470-NISTL Manuel utilisateur

Extech Instruments

Extech Instruments 407355 Manuel utilisateur

Extech Instruments

Extech Instruments RH401 Manuel utilisateur

Extech Instruments

Extech Instruments 407790 Manuel utilisateur

Extech Instruments

Extech Instruments AN200 Manuel utilisateur

Extech Instruments

Extech Instruments EX820 Manuel utilisateur

Extech Instruments

Extech Instruments HD750 Manuel utilisateur

Extech Instruments

Extech Instruments AN320 Manuel utilisateur

Extech Instruments

Extech Instruments MO25 Manuel utilisateur

Extech Instruments

Extech Instruments ExStik PH100 Manuel utilisateur

Extech Instruments

Extech Instruments TM100-NIST Manuel utilisateur

Extech Instruments

Extech Instruments HD300-NISTL Manuel utilisateur

Extech Instruments

Extech Instruments 700 Series Manuel utilisateur

Extech Instruments

Extech Instruments HD450 Manuel utilisateur

Extech Instruments

Extech Instruments 461895 Manuel utilisateur

Extech Instruments

Extech Instruments 382152 Manuel utilisateur

Extech Instruments

Extech Instruments EA30 Manuel utilisateur

Extech Instruments

Extech Instruments MS400 Manuel utilisateur

Extech Instruments

Extech Instruments 380803 Manuel utilisateur

Extech Instruments

Extech Instruments CG104 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
