Extech Instruments 407768 Manuel utilisateur

User's Manual

Digital Sound Level Meter

Model 407768

407768 Version 2.0 06/06

Introduction

Congratulations on your purchase of the Extech 407768 Sound Level Meter. This Auto

Range Sound Level Meter meets ANSI and IEC Type II accuracy standards. Professional

features include programmable Frequency Weighting and Time Response, Min/Max

Memory, Max Hold, Analog output, and RS-232 PC Interface. Careful use of this meter will

provide years of reliable service.

Specifications

Display 5 Digit LCD with overload, low battery and multifunction

indication

Frequency bandwidth 31.5 Hz to 8 KHz

Microphone 0.5” Electret Condensor Microphone

Output terminals Optically isolated RS-232 port and AC output

Measurement ranges Auto Range: 30 to 130dB

Manual Ranges: 30 to 80dB, 50 to 100dB, 80 to 130dB

Frequency weighting ‘A’ and ‘C’ (Programmable)

Applicable standards ANSI / IEC Type 2

Resolution 0.1dB

Maximum/Minimum record Highest and lowest readings are stored for later recall

Data Hold Displayed reading is held when HOLD key is pressed

Max Hold Highest reading displayed only

Response time Fast: 125ms / Slow:1s (Programmable)

AC Analog output 0.5VAC rms full scale (600Ωoutput impedance)

Power 9V Battery; Consumption: 6mADC approx.

Operating temperature 32 to 122oF (0 to 50oC)

Operating humidity Less than 80% RH

Dimensions / Weight 10.6 x 2.7 x 1.1" / 0.63 lbs. (268 x 68 x 29mm / 285g)

Meter Description

1. Microphone

2. LCD Display

3. Power, Hold, and Min/Max buttons

4. Max, Weighting, Response Time, & Range buttons

5. AC output jack

6. Calibration potentiometer

7. RS-232 PC interface jack

8. Battery compartment, tilt stand,

and tripod mount on rear

407768 Version 2.0 06/06

Sound Level Meter Operation

Meter Power

1. The meter is powered by a 9V battery. The battery compartment is located on the rear

of the meter and the compartment cover is secured by one Phillips screw. When the

battery icon appears on the top left corner of the meter's display, replace the battery.

2. Press the POWER button to turn the meter on. Note that the Meter is equipped with an

Auto Power Off feature that shuts the meter off after 10 minutes. To defeat Auto Power

Off, put the meter in Record mode by pressing the REC MAX/MIN button.

3. Press the POWER button to turn the meter off.

Default Configuration

1. The meter's default configuration is as follows: Auto Range, 'A' Frequency Weighting,

and 'FAST' Response Time

2. The lower portion of the LCD will reflect the meter's configuration, i.e., 'A', 'Fast', 'Auto'.

Measurement Considerations

1. Use a windscreen (not included) to cover the microphone in windy conditions.

2. Calibrate the meter often, especially if the meter has been idle for a long period of time.

3. Do not store/operate the meter in areas of high temperature or humidity.

4. Keep the meter and the microphone dry.

5. Avoid severe vibration when using the meter.

6. Remove the battery when the meter will be stored for long periods of time.

Frequency Weighting

Change the Frequency Weighting by pressing the 'A/C' button. The 'A' or 'C' icon will

display on the lower left-hand area of the LCD.

Note: With ‘A’ weighting selected, the meter responds like the human ear (boosting and

cutting the noise amplitude over the frequency spectrum - see Appendix). ‘A’ weighting is

used for environmental measurements, OSHA regulatory testing, law enforcement, and

workplace design. Select ‘C’ weighting for flat response measurements (no boost or cut).

‘C’ weighting is suitable for the sound level analysis of machines, engines, etc. Most OSHA

related testing is performed using 'A' Weighting and SLOW Response Time settings.

Response Time

Change the Response Time by pressing the 'FAST/SLOW' button. The 'FAST' or 'SLOW'

icon will display on the lower left-hand area of the LCD.

Note: Select FAST to capture noise peaks and noises that occur very quickly. In FAST

mode, the meter responds in 200ms. Select the SLOW Mode (meter responds in 500ms)

to monitor a sound source that has a reasonably consistent noise level or to average

quickly changing levels. Selection of Fast or Slow is determined by the application and any

directives or standards related to that application.

Auto/Manual Range

Press the RANGE button to scroll through the following ranges: Auto, 30-80dB, 50-100dB,

and 80-130dB. The display will reflect the range for each button press.

Calibration

The Sound Level meter should be calibrated before each use; an external sound level

meter calibrator is required. Set the meter to the Manual range (50-100dB), FAST

response and ‘A’ weighting before starting.

1. Place the external calibrator over the Sound Level Meter's microphone and turn the

Calibrator on.

407768 Version 2.0 06/06

2. The meter should read close to, or exactly, the calibrator's dB output level. Typical

Calibrator output levels are 94dB and 114dB.

3. If the meter is within ± 0.2 dB of the calibrator’s output, no adjustment is necessary.

4. Adjust the calibration pot in the output/calibration compartment if necessary to bring the

meter display in line with the calibrator output signal.

Taking Measurements

1. Hold the meter in hand, place it on a desktop (using the rear tilt stand), or mount it on a

tripod using the tripod mount on the rear of the meter.

2. Point the microphone toward the source of noise/sound to be measured.

3. Read the measurement, in dB units, on the LCD display.

Data Hold

1. Press the HOLD button to freeze the displayed reading. The LCD will display the icon

HOLD when Data Hold is engaged.

2. Press the HOLD button to de-activate this feature. The HOLD icon will extinguish.

3. Note that Data Hold is not available while the meter is in the Max/Min Record mode.

Max Hold

1. Press the MAX HOLD button to activate this feature. The LCD will display PH when

Max Hold is engaged.

2. The meter will now display only the highest reading. Each time a higher reading is

encountered the display will update.

3. Press the MAX HOLD button again to de-activate this feature. The PH icon will

extinguish.

4. Note that Max Hold is not available while the meter is in the Max/Min Record mode.

Max/Min Data Recording

The Max/Min feature stores the maximum reading and minimum reading while the user

takes measurements. The Max and the Min readings can later be recalled.

1. Press the REC MAX/MIN button to activate this feature. The LCD will display the icon

REC and the meter will begin monitoring the highest (Max) and lowest (Min) readings.

2. After measurements are made, press the REC button again to view the Max reading.

The MAX icon will appear on the LCD along with the highest reading.

3. Press the REC to view the minimum (MIN) reading. The 'MIN' display icon will appear

on the LCD along with the lowest reading.

4. To exit this mode, press and hold the REC button until the REC indicator

extinguishes.

5. To clear a Max or Min reading, press the HOLD key while viewing either the MAX or

MIN value. Note that exiting the Record mode also clears the MAX and MIN values.

Analog Output

The AC analog output transmits 0.5V AC rms full scale. The output impedance is

600Ω maximum. The mono 3.5mm mini-jack is located in the output/calibration

compartment on the right side of the instrument. Use a phono plug (3.5mm mono) to

connect to the output jack.

407768 Version 2.0 06/06

PC Interface

The optically isolated RS-232 PC Interface port is located in the output/calibration

compartment situated on the lower right side of the meter. The supplied Data Acquisition

Software package includes WindowsTM 95 / 98 / NT / 2000 / XP compatible software and a

meter-to-PC interface cable. Instructions for use can be found on the included software

CD.

Important Note on the Automatic Power OFF feature

The 407768 Sound Level Meter has an AUTO POWER OFF feature that turns the meter

off after approximately 10 minutes. This feature must be disabled before starting a

datalogging session to avoid having the meter automatically shut off in the middle of a

session. Disable it by pressing the REC MAX/MIN button to activate the Record mode.

While the meter is in the Record mode, the AUTO POWER OFF feature is disabled.

407768 Version 2.0 06/06



Support Hotline (781) 890-7440

Tech support: Ext. 200; Email: [email protected]

Repair/Returns: Ext. 210; Email: [email protected]

Website: www.extech.com

Battery Replacement

The 9V battery that powers the Sound Level Meter is housed in the rear battery

compartment. When the battery icon appears on the top left corner of the meter's LCD, it is

time to replace the battery.

1. Open the battery compartment by first removing the Phillips screw and then sliding the

compartment cover down and off.

2. Replace the 9V battery, slide the cover on, and replace the screw.

Calibration and Repair Services

Extech offers complete repair and calibration services for all of the products we sell.

For periodic calibration, NIST certification or repair of any Extech product, call customer

service for details on services available. Extech recommends that calibration be performed

on an annual basis to insure calibration integrity.

Warranty

EXTECH INSTRUMENTS CORPORATION warrants this instrument to be free of defects in parts and

workmanship for one year from date of shipment (a six month limited warranty applies on sensors and

cables). If it should become necessary to return the instrument for service during or beyond the warranty

period, contact the Customer Service Department at (781) 890-7440 ext. 210 for authorization or visit our

website at www.extech.com (click on ‘Contact Extech’ and go to Service Department to request an RA

number). A Return Authorization (RA) number must be issuedbefore any product is returned to Extech. The

sender is responsible for shipping charges, freight, insurance and proper packaging to prevent damage in

transit. This warranty does not apply to defects resulting from action of the user such as misuse, improper

wiring, operation outside of specification, improper maintenance or repair, or unauthorized modification.

Extech specifically disclaims any implied warranties or merchantability or fitness for a specific purpose and

will not be liable for any direct, indirect, incidental or consequential damages. Extech's total liability is limited

to repair or replacement of the product. The warranty set forth above is inclusive and no other warranty,

whether written or oral, is expressed or implied.

Appendix

Typical 'A' Weighted dB le vels

Frequency Weighting Graph

Frequency Weighting

-45

-40

-35

-30

-25

-20

-15

-10

-5

10 100100010000

Frequency (Hz)

dB (relative)

'A' Weighting

'C' Weighting

140

120

100

130

110

50 HP Siren (100')

Jet take-off (200')

Riveting machine

Subway (20')

Pneumatic drill (50')

Vacuum cleaner (10')

Large s tore

Small office

Residential area

(night)

Whisper (5')

Threshold of hearing

Chain saw

Boiler room

Freight train (100')

Speech (1')

Large Office

Residence

Sound studio

more infor for Extech 407768

Phone: 01235 838 555

Email: cs@airconcern.co.uk

Web. www.airconcern.co.uk

Air Concern Ltd, Building 173 Curie Avenue Harvell Didcot, Oxfordshire

Table des matières

Autres manuels Extech Instruments Instrument de mesure

Extech Instruments

Extech Instruments TM100 Manuel utilisateur

Extech Instruments

Extech Instruments CT-3060 Manuel utilisateur

Extech Instruments

Extech Instruments 475055 Manuel utilisateur

Extech Instruments

Extech Instruments 407780A Manuel utilisateur

Extech Instruments

Extech Instruments AN250W Manuel utilisateur

Extech Instruments

Extech Instruments 380560 Manuel utilisateur

Extech Instruments

Extech Instruments HD780 Manuel utilisateur

Extech Instruments

Extech Instruments MA145 Manuel utilisateur

Extech Instruments

Extech Instruments 407123 Manuel utilisateur

Extech Instruments

Extech Instruments SL355 Manuel utilisateur

Extech Instruments

Extech Instruments 461825 Manuel utilisateur

Extech Instruments

Extech Instruments HD450-NIST Manuel utilisateur

Extech Instruments

Extech Instruments 380460 Manuel utilisateur

Extech Instruments

Extech Instruments 461920 Manuel utilisateur

Extech Instruments

Extech Instruments MA140 Manuel utilisateur

Extech Instruments

Extech Instruments 407820 Manuel utilisateur

Extech Instruments

Extech Instruments Oyster Series Manuel utilisateur

Extech Instruments

Extech Instruments 407790A Manuel utilisateur

Extech Instruments

Extech Instruments 475055 Manuel utilisateur

Extech Instruments

Extech Instruments EA30 Manuel utilisateur

Extech Instruments

Extech Instruments AN200 Manuel utilisateur

Extech Instruments

Extech Instruments SP505 Manuel utilisateur

Extech Instruments

Extech Instruments PQ3450-2-NIST Manuel utilisateur

Extech Instruments

Extech Instruments MA250 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
