1. OVERVIEW

The 7807LT-2 is a dual fiber optic transmitter for RF signals in the extended L-Band frequency range and

below, for frequencies such as over-the-air DTV. It accepts two RF inputs from coaxial cable and provides

two outputs for optical transmission. An RF monitor output is provided for each input, which offers a

convenient means of obtaining peak satellite signal strength, or additional signal distribution. With two

optical transmitters per single-slot card, the 7807LT-2 provides an economical, high density solution.

Individual monitoring and control is provided for each signal path. Gain may be adjusted manually or

managed automatically via AGC. With SmartMON™, incoming RF signal strength, LNB current, and other

data are relayed over the fiber output for monitoring through SNMP/VistaLINK®at the fiber receiver

(requires SmartMON™ capable companion fiber receiver). LNB power with selectable 13/18V DC and 22

kHz tone is also provided on each RF input.

Features:

•Extended frequency response for extended L-Band, off-air DTV and other signals

•Protocol independent design - transports all modulation formats

•LNB power with selectable 13/18V DC, per input

•LNB current limit & short circuit protection

•LNB current monitoring for advance warning of LNB failure

•22kHz tone on/off for LNB local oscillator control, per input

•RF monitoring output ports for signal peaking and signal distribution

•Manual gain and AGC modes for tuning optimal CNR performance

•Multiple versions of the 7807LT-2 are available to address single-mode/multi-mode fiber, single/dual

fiber and CWDM/DWDM applications.

•The 7807LT13/15-2-W is a dual channel card that features and on-board fiber coupler, requiring only

a single fiber for the link (companion receiver is the 7807LR-2-W)

•Dual fiber transmitters on a single-slot card provides the industry’s highest density solution

•SmartMON™ capability provides remote status monitoring via SNMP without a separate data

connection

•VistaLINK® capability is available for monitoring and control when modules are used in a 3RU

7800FR frame and a 7700FC VistaLINK® frame controller is installed in slot 1 of the frame

•Form-C dry contact GPO alarm contacts for monitoring

•Fiber link provides electrical isolation between antenna and facility, mitigating ground loop and

lightning issues

•Compatible with all 2406LR, 7706LR, 7708LR and 7807LR-2 series receivers

7700/7800 MultiFrame Manual

7807LT-2 Dual Wideband RF Fiber Transmitter

Page - 2 Revision 1.2

Optical

Transmitter

Monitoring/Control

Local

Control

Fiber

Output 1

RF In/LNB

Power 1

Monitor

Out 1

Tap

Amp

VistaLINK

Interface

LED Indicators

Dot Matrix Display

Toggle Switch/

pushbutton

Optical

Transmitter

Fiber

Output 2

RF In/LNB

Power 2

Monitor

Out 2

Tap

Amp

LNB Power

Supply

Current Monitor

22 kHz Tone

LNB Power

Supply

Current Monitor

22 kHz Tone

(7807LT-2 “Non -W” version)

Coupler

(7807LT13/15-W version Only)

Fiber

Output

Figure 1-1: 7807LT-2 Block Diagram

7700/7800 MultiFrame Manual

7807LT-2 Dual Wideband RF Fiber Transmitter

Revision 1.2 Page - 3

2. INSTALLATION

The 7807LT-2 comes with a companion rear plate appropriate for a 1RU, 3RU or standalone enclosure as

specified at the time of order. SC/UPC, SC/APC, ST/UPC, FC/UPC or FC/APC optical connectors are

available and the type specified at the time of order will be installed. For information on mounting the rear

plate and inserting the module into the frame, see the 7700FR/7800FR manual for detailed instructions.

7807LT13/15-W

7807LT-2

Figure 2-1: 7807LT-2/7807LT13/15-W Module

7700/7800 MultiFrame Manual

7807LT-2 Dual Wideband RF Fiber Transmitter

Page - 4 Revision 1.2

2.1. 7807LT-2 CONNECTIONS

FIBER OUTPUTS: SC/UPC, SC/APC, FC/UPC, FC/APC or ST/UPC female connectors with the optical

outputs from the 7807LT-2. These connectors should be connected to the FIBER

IN connectors of an appropriate Evertz companion receiver model at the destination

end with suitable fiber optic cables. The 7807LT-2 may transmit 1310nm, 1550nm

or CWDM wavelengths as indicated by the part number on the card ejector. The

standard connector type is UPC. This connector type is compatible with standard

PC connectors, but for optimal return loss performance, Evertz recommends the

use of UPC fiber terminations throughout the system. The optional APC connectors

provide further enhanced return loss performance, and when specified, should be

used throughout the system.

RF IN: Input connectors for RF signals. These connectors can also provide LNB power

and 22 kHz tone back to the LNB.

RF OUT: Output connector provides buffered copy of the incoming RF signal for monitoring

purposes (signal peaking, etc.) or coaxial distribution. Although not essential, if this

connector is to remain unused, it is recommended that it be terminated with an

appropriate 75 Ohm or 50 Ohm load.

GPO’s: The 3 pin terminal strip is used for the General Purpose Outputs (GPO). Pin1 and

Pin2 refer to GPO1 and GPO2 respectively, whose behavior (NC/NO) can be

selected by a jumper. (Refer to section 5.1 for Jumper Positions). Signal on GPO

Common (C) is to be provided by the user. A minor alarm between Common and

GPO1 is triggered in a state of RF outside of threshold and major alarm between

Common and GPO2 is triggered in a state of Laser failure and/or LNB short. Each

GPO output is a set of normally open and normally closed relay contacts as shown

in Figure 2-2.

NO GPO Contact

GPO Common

from

internal

circuit

NC GPO Contact

Figure 2-2: GPO Configuration



When connecting cables to the GPO terminal block, a ferrite core should be placed

around the cable in order to reduce the electromagnetic interference to limits

acceptable for Class A digital devices. The ferrite impedance should be greater

than 70 ohms at 25MHz and greater than 135 ohms at 100MHz.

Autres manuels pour 7700 MultiFrame

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels evertz Émetteur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7707VT-8-OC48 Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 2408RGBT/DVIT Manuel utilisateur

evertz

evertz 2408LT Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7707VAT13-HD Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7707CVT-8 Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7707MTA-HD Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7707VAT Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 2407RGBT/DVIT Manuel utilisateur

evertz

evertz 7707VT-8-HS Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7706LT Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 2405LTA Manuel utilisateur

Manuels Émetteur populaires d'autres marques

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manuel du propriétaire

Honeywell

Honeywell 5816WMBR Manuel utilisateur

Kamstrup

Kamstrup READy MTU Mode d'emploi

Omega

Omega ZW Series Manuel utilisateur

ABB

ABB Field 264H Mode d’emploi

Alinco

Alinco DJ-V17T Manuel utilisateur

Dejero

Dejero EnGo 3x Manuel utilisateur

Rosemount

Rosemount 4600 Manuel utilisateur

Speaka Professional

Speaka Professional 2342740 Manuel utilisateur

trubomat

trubomat GAB 1000 Manuel utilisateur

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manuel utilisateur

Rondish

Rondish UT-11 Manuel utilisateur

MG 10JRE Manuel utilisateur

Burkert

Burkert 8177 Manuel utilisateur

Firetide

Firetide HotPort 3203 Manuel

Tele Radio

Tele Radio T9-02 Manuel utilisateur

Rotronic

Rotronic HygroFlex HF3 Series Manuel utilisateur

Jamara

Jamara FCX6 Pro Tel Manuel utilisateur

evertz 7700 MultiFrame Manuel utilisateur

Manuels Émetteur populaires d'autres marques
