EverFocus EHD Series Manuel de formation

3”

”

User’s Manual

and

Operation Instructions

Series

Notice

This manual is presented to the users of EHD series by EverFocus

Electronics Corp. With years of engineering researches, EverFocus has

spared no effort to provide the high quality products to the worldwide users.

For the policy of continual product improvement, EverFocus reserves the

right to make changes to the product specifications and documentation

without notice. All the components of the products, including accessories,

components, and outlook, are based on the agreements of each deals to

satisfy all kinds of users. Meanwhile, please be advised that every step of

operation must follow the instruction of this manual to keep EHD series

working under the best condition. Please notice that EverFocus will not be

charged any claims or renewing cases resulted from inappropriate operation.

Table of Contents

Safety Warning ……………………………………. 1

Introduction………………………………………...2

Specification……………………………………….. 3

Installation Instructions……………………………4

Dip Switch Functions……………………………… 8

Simple Instructions for the desiccant pack……… 11

1. Do not install the camera near electric or magnetic fields.

Installed the camera away from TV, radio transmitter, magnet,

electric motor, transformer, audio speakers because the

magnetic fields generate from above devices will distort the

video image.

2. Do not install the camera in the high temperature environment.

Installed the camera away from stoves, or other heat

generating devices as the high temperature could cause

deformation, discoloration or other damages of the camera.

Install the camera at where the temperature range will stay

between -40℃to 50℃.

3.Never face the camera toward the sun.

Never aim the camera at the sun or other extremely bright objects

whether it is in use or not.

4. Cleaning

Do not touch the surface of CCD sensor by hand directly. Use

a soft cloth to remove the dirt from the camera body. Use lens

tissue or a cotton tipped applicator and ethanol to clean the

CCD sensor and the camera lens. When the camera is not in

use, put the cover cap on the lens mount.

5. Heater

Heater elements could be very hot!! Heaters are located inside

the camera housing and will active automatically while the

environment temperature is below 10℃. Do not touch the

heater element while it’s active.

Safety Warning

The most technically advanced EHD series are the newest

vandal-resistant Color Rugged Dome Camera from EverFocus Electronics.

The Color Rugged Dome Camera can withstand a blow from a 10-pound

sledgehammer and has a built-in heater that allows for operation in low

temperatures. It is perfect for all high-profile crime-prone applications such

as building entrances, retail stores, and shopping malls. The extremely EHD

series are unquestionably one of the world's toughest cameras and is your

best choice for vandal resistance.

Main Features :

??Excellent high resolution 520TVL

??Revolutionary integrated 10-bit Digital Signal Processor (DSP)

delivers excellent picture quality and performance.

??Low lightsensitivity of 0.5lux/F=1.2is achieved by using the

advanced 1/3” interline transfer color CCD.

??The electronic shutter and AGC allow the camera to be used in

environment with varying light levels.

??DC12V or AC24V switches automatically power supply; Line Lock

for AC24V.

??S/N Ratio reaches 48 dB or more.

??Vari-focal lens available.

??Compact size: 130(W)mm x 98.9(H)mm x 130(D)mm

??Polycarbonate shell withstand the impact of 10 pounds

sledgehammer, smoke color or clear as option.

??Aluminum die-casting base, smoke color or clear as option

??Unique security screw locked

??Operating temperature –40 ~ 50℃.

??Heater triggered when temperature less than 10℃.

Introduction

Model 350HQ

Pickup device: 1/3” interline transfer color CCD

Picture element: NTSC :768(H) × 494(V)

PAL: 752(H)×582(V)

Horizontal

resolution: 520 TV lines

Sensitivity: 0.5lux /F=1.2,

S/N ratio: >48dB(AGC off)

Weatherproof

Ratings: IP66

Electronic shutter: Up to 1/100,000

IRIS Control: Auto

Auto white balance YES

Auto gain control on/off switch

Back light comp on/off switch

Line Lock on/off switch for 24VAC

Flickerless on/off switch

Gamma correctio >0.45

Video output: 1.0Vp-p,75ohm

Power source: 12VDC+/-10%, 24VAC+/-10%

Power

Consumption: 5W Max. (15W when heater active; thermostatically

controlled)

Sync.mode: Internal Sync. /Line lock (Only AC24V)

Dimension: 130(W)mm x 98.9(H)mm x 130(D)mm

Heater auto

activated

temperature:

10℃, Heater optional

Operating

temperature: -40℃to 50℃, 20~80%

Weight: 1.7kg

Specification

1. Loosen the 4 fix screws on the housing cover by using the attached

wrench (Figure 1). Carefully uncap the housing cover as the direction

shown below (Figure 2), please pay attention not to damage the lens.

To remove the housing cover, push the hinges to the bottom of the

bracket, the hinges can be easily removed from the bracket.

2. Remove the camera.

To remove the camera, first unplug the wire connection on the back of

the camera. Then loosen the 2 locking screws on the camera base,

push the camera base to the right (toward heater direction, as shown

in Figure 3), remove the camera from the mounting base. Reinstall

the camera and the cable while the base mounting is completed.

Installation Instructions

Locking Screws

Vari-Focal Lens

Heater

Figure 1 Figure 2

Figure 3

3. Mounting the base.

Attach the base to the wall or ceiling, fix the base by the 4 setscrews

attached in the accessory pack. The dome is weighted 1.7kg, please

make sure if the mounting is strengthened enough to support it, if not,

please reinforce the mounting according to the environment.

Note: The diameter of the screw hole isψ4.7mm.

Caution: To prevent moisture leaking into the housing, apply an

appropriate gasket or sealant around the conduit connection.

Conduit plug setscrew

Side conduit entry

Back conduit entry

Mounting Setscrew

The camera comes with a conduit plug

pre-installed in the PF 1/2 conduit entry

on the side. The screw can be removed

and installed in the back conduit entry.

Loosen the conduit plug setscrew (as

shown in Figure 5) before removing the

conduit plug.

Side conduit entry (PF1/2)

Conduit plug

Back conduit entry (PF1/2)

Figure 4

Figure 5

4. Re-assemble Camera

1. If mounting COLOR RUGGED DOME CAMERA on the wall,

please to aim the “Wall” in line with the triangle “?” marked

on the lead frame. (factory default)

2. If mounting COLOR RUGGED DOME CAMERA on the

ceiling, please to aim the “Ceiling” in line with the triangle

“?” marked on the lead frame.

Figure 6-2

Figure 6-1

“Wall”

“Ceiling”

5. Wire Connection

Connect the power supply cable (AC24V/DC12V), video output and

alarm output to the proper connectors shown as Figure 7.

The V. Phase adjustment screw is located on the termination board.

The vertical phase may require adjustment to synchronize the vertical

phase of the camera with other camera in the system when it is to be

used in the line-lock sync mode. Make the adjustment when the

vertical phase of the camera does not match with other cameras.

Termination Board

Video

Alarm COM

Micro Switch for Alarm trigger

GND

Alarm NO Alarm NC

Power In(+)

V. Phase Adjustment VR

Figure 7

Power In (-)
