EverFocus EPN4122i Plus: Manuel utilisateur





EPN Series

IP Speed Dome

Quick Installation Guide



ReleaseDate:April,2013



EPNSeries

1. Overview

TheEPNseriesIPSpeedDomecomesintwotypes:Indoor(EPN4122i/4220i)andOutdoor(EPN4122/

4220).



No.ItemNameNo.ItemNameNo. ItemName

1TopHousing2OuterHousing 3CameraMainBody



PackingList

Themainboxcontains3largeboxesandasmallbox.Eachboxcontainstheitemsaslistedbelow.Please

checkthatthereisnomissingiteminthepackagebeforeinstalling.

Box1:Tophousingwithanetworkconnectorandtoolpacket

Toolpacket(Indooronly):Includes6PlasticAnchorsand6Screws.

Box2:Cameramainbodywithatoolpacket

Toolpacket:Includes1pairofGloves,3DesiccantPacksand1PowerTerminalBlock.

Box3:Outerhousing

SmallBox:Poweradapter

SoftwareCD

QuickInstallationGuide

Note:

1. Equipmentconfigurationsandsuppliedaccessoriesvarybycountry.Pleaseconsultyourlocal

EverFocusofficeoragentsformoreinformation.Pleasealsokeeptheshippingcartonforpossible

futureuse.

2. Contacttheshipperifanyitemsappeartohavebeendamagedintheshippingprocess.



2. SystemRequirement

Beforeinstalling,pleasecheckthatyourcomputermeetsthissystemrequirement.

OperatingSystem:MicrosoftWindowsXP/Vista(32‐bit)/7(32‐bit)

MicrosoftInternetExplorer7orabove

 EPNSeries

3. CablesandI/OTerminalBlock

CableDescriptions



NoNameandDescriptionsNoNameandDescriptions

1RS‐485+(Yellow):ConnectstoanRS‐485device.5AudioIn:Connectstoamicrophone.

2RS‐485‐(Orange):ConnectstoanRS‐485device.6AudioOut:Connectstoaspeaker.

324VAC~:Connectstothepoweradapter.7RJ‐45Cable:Connectstothenetwork.

4Test‐OutCable:ConnectstoaDVRormonitor.

Note:Microphoneswithexternalpowersuppliesarerequired.



I/OTerminalBlock

TheI/Oterminalblock,locatedontherearpaneloftheBaseBoard,canbeusedtodevelopapplications

foralarminputandoutput,motiondetection,PTZcontroloravarietyofotherfunctions.

PinAssignment

No.FunctionsNo. Functions

1GND(Ground)7ALM_NC_A(AlarmOutputNormalCloseA)

2ALM_NO_B(AlarmOutputNormalOpenB)8GND(Ground)

3ALM_COM_B(AlarmOutputCommonB)9ALMIN1(AlarmInput1)

4ALM_NC_B(AlarmOutputNormalCloseB)10GND(Ground)

5ALM_NO_A(AlarmOutputNormalOpenA)11ALMIN2(AlarmInput2)

6ALM_COM_A(AlarmOutputCommonA)12GND(Ground)

 EPNSeries

4. OptionalAccessories

EPTZ‐PBOX(Externalpowerconnectionbox)



Cornermountadapter



Polemountadapter



Indoorceilingpendantmountbracket



Outdoorsunshield



Indoorrecessedmountbracket

Wallmountbracket



Indoorconcreteceilingmountadapter



EKB500(RS‐485keyboard)



EKB200(USBcontrollerkeyboard)



5. Installation

ThisinstallationguideprovidesthebasicinstructionsoninstallinganEPNseriesIPcamera.Fordetails,

refertotheEPNSeriesIPSpeedDomeUser’sManualinthesoftwareCD.



Note:Installationshouldbehandledbyaqualifiedserviceagentandcompliedwithalllocalregulations.



ReplacingtheDesiccantBags/InsertingaMicroSDCard

Beforeinstalling,insertamicroSDcardintothemainbodyandreplacethedesiccantbagsinsidethetop

housing.Itishighlyrecommendedtoreplacethedesiccantbagseverytimewhenyouopenthecamera.



 EPNSeries

Toreplacethedesiccantbags:

1. OntheTopHousing,slightlypresstheblackplasticsocketbackwardandliftupthebaseboard.



2. Removethedesiccantbagsfromthetophousing.

3. Stickthesupplied3newdesiccantbagsinsidethetophousing. Placebackthebaseboard.



Note:EnsureNottoplacethedesiccantbagsunderthepositionofthefan.



ToinsertamicroSDcard:

1. Unscrewthefourscrewsonthecameramainbodytoremovetheblackhousing.



2. InsertthemicroSDcardtothecardslot.Screwbacktheblackhousing.



 EPNSeries

InstallingOutdoorModels(EPN4122/4220)

Twomountingtypesareavailablefortheoutdoormodels:WallMountandCeilingMount.



WallMount

1. Drill4screw‐depthholesforthebracketbaseplateandthendrillathrough‐wallholeforthecamera

cables.Youcanoptionallydrillasecondthrough‐wallholetoseparatecablefeeding(seeStep4).

2. Attachthewaterproofsiliconpadtothebracketbaseplateforwaterproofing.

3. Feedthecamera’scablesthroughtheconduitinthewallmountbracket.



4. Connectthecamera’scablestotherelateddevices.Feedthecablesoftherelateddevices,suchasthe

speaker,throughthewallandthenthroughtheholesofthebracketbaseplate.



5. Screwthebracketbasetothewallusingthe4screws.

6. Screwthewallmountbrackettothebracketbaseusingthe4longscrews.

7. Putonthesuppliedgloves.Lineuptheredtriangles andthenpushthemainbodyupwardtothe

tophousing.Pushthemainbodyupwardintothetophousinguntiltheorangecatchesonbothsides

clickintoposition.

 

Note:Toreleasethemainbody,pressthetwoorangereleasebuttonsonbothsides.



8. Screwthehousingcovertothetophousingslowlybytwistingitclockwise.

Waterproof

siliconpad

Bracketbaseplate

 EPNSeries

CeilingMount

ItisrequiredtousetheoptionalIndoorRecessedMountBracketandSurfaceRingtoattachthecamerato

theceiling.

1. Cutaholeontheceilingusingthesuppliedtemplate.

2. Slightlyturnthesurfaceringandremoveitfromthebracket.



3. Placeandthenscrewthecamera’stophousingonthetopdiskofthebracketusingthe3shortscrews.



4. Useacableorothermechanismtohangthebracketontheceiling.Screwthe3rotationclipsofthe

bracketontheceilingusingascrewdriver.



5. Putonthesuppliedglovesandthenpushthemainbodyupwardtothetophousing.SeeStep7inWall

Mount.

6. Screwthehousingcovertothetophousingslowlybytwistingitclockwise.

7. Slidethesurfaceringtothefillisteronthebracket.

Note:Whenyouturnonthepower,thecamerawillenterself‐inspectionmodeandrunaself‐testing

program.Oncethisiscomplete,youwillbeabletooperateitviaanyIPnetwork.



 EPNSeries

6. NetworkConnections

Youcanuseoneofthemethodsbelowtoconnectthecameratothenetwork.



RouterorLANconnection

ThisisthemostcommonconnectioninwhichtheIPcameraisconnectedtoarouterandallowsmultiple

usersonandoffsitetoseetheIPcameraonaLAN/WAN(Internet).ThecameramustbeassignedanIP

addressthatiscompatiblewithitsLAN.Bysettingupportforwardingontherouter,youcanviewcameras

fromoutsideoftheLANviatheInternet.ToremotelyaccesstheWebinterfaceoftheIPcamera,please

referto7.3.2DDNSintheUser’sManual.Tosetupportforwarding,pleaseconsultthemanualofthe

router.











Straight‐throughLANpatchcable

Right:Pinoutofastraight‐throughcable.

 EPNSeries

DirectHigh‐SpeedConnection

InaDirectHigh‐SpeedConnection,thecameraconnectsdirectlytoamodemwithouttheneedforarouter.

YouneedtosetthestaticordynamicWANIPaddressassignedbyyourISP(InternetServiceProvider)inthe

camera’sconfigurationwebpages.Toaccessthecamera,justtype“http://xxx”,wherexxxistheIPaddress

givenbyyourISP.IfyouhaveadynamicIPaddress,thisconnectionmayrequirethatyouuseDDNSfora

reliableconnection.Pleasereferto7.3.2DDNSintheUser’sManual.



One‐to‐oneConnection(DirectlyfromPCtoIPCamera)

Youcanconnectdirectlywithoutusingaswitch,routerormodem.However,onlythePCconnectedtothe

camerawillbeabletoviewtheIPcamera.YouwillalsohavetomanuallyassignacompatibleIPaddressto

boththecomputerandtheIPcamera.UnlessthePChasanothernetworkconnection,theIPcamerawill

betheonlynetworkdevicevisibletothePC.Seethediagrambelow:



Pinoutofstraightpatchcable      

4.AssignIPAddress



Right:Pinoutofacrossed‐overcable.

 

EPNSeries

7. CheckingtheDynamicIPAddress

YoucanlookuptheIPaddressandaccesstheWebinterfaceofthecamerausingtheIPUtility(IPU)

software,whichisincludedinthesoftwareCD.

1. InstallandthenstarttheIPUprogram .Thefollowingdialogboxappears.



2. IPUwillautomaticallysearchthecamerasconnectedintheLAN.Thedefaultnetworkvaluesofthe

cameraswillbedisplayed.Bydefault,thenetworkprotocolofthecameraisDHCP.

3. Toconfigurethenetworksettings,selectacameraandthenclickLogin/MultiLogintologin.



4. TypetheuserIDandpassword.ClickOK.

Note:

1. ThedefaultuserIDisuser1andthedefaultpasswordis11111111.

2. IfyouselectmorethanonecamerathathasthesameuserID/password,youwillbeabletolog

inseveralcamerasatonce.


