EX83304 Series Hardened Managed Ethernet Switch

EX83304

06/13/2019

Installation Guide

W70G-EX83304Q1

1 Unpacking

Unpack the items. Your package should include:

One EX83304 Series hardened managed switch

One console cable

If items are missing or damaged, notify your

EtherWAN representative. If possible, save the

carton and packing material. The full product

manual can be downloaded from:

https://www.etherwan.com

2 What Else You Need

Shielded twisted pair cables and

corresponding shielded RJ45 connectors

Appropriate SFP cable for SFP ports

Personal computer with a DB9 straight cable

(if switch is to be managed through console

port)

3 Select a Location

Installations: DIN-Rail mount, wall (in an

enclosure or industrial panel)

Identify a power source within 6 feet (1.8

meters).

Choose a dry area with ambient

temperature between -40 and 75ºC (-40 and

167ºF).

Be sure there is adequate airflow.

4 Connect to the Data Ports

Depending on the model, your switch can have

the following ports:

12 or 8 10/100BASE-TX ports

2 or 4 Gigabit SFP slots

10/100BASE-TX Ports

These ports come in 10/100Base-TX interfaces.

They can connect to devices such as an IP

surveillance camera or a Voice Over Internet

Protocol (VoIP) phone.

1 Gbps SFP Ports

Your switch model has four 1 Gbps SFP slots. SFP

transceivers can be installed directly into ports

13 –16. Ensure that the same type of transceiver

is used at both ends of the link and that the

correct type of fiber cable is used.

5 Apply Power

The switch has two pairs of power inputs:

A 12-48 VDC terminal block

The power dissipation under full load is as

follows:

12V/1.44A 24V/0.67A 48V/0.33A

Redundant power supply is supported. However,

only one power input is required to operate the

switch.

Note: Use qualified power supply by SELV or

double insulation of UL60950 or UL61010-1 or

UL61010-2-201 standards.

Terminal Block

The switch provides two power inputs on a 12-

48VDC terminal block. Only one power input is

required to operate the switch. The terminal

block has 5 terminal posts.

EX83304 Series Hardened Managed Ethernet Switch

EX83304

06/13/2019

Installation Guide

hernet Switch

W70G-EX83304Q1

Description

Power 1



12-48VDC



Power Ground

Power 2



12-48VDC



Power Ground

Earth Terminal

Relay Output Rating

2A @ 30VDC

Relay Output Alarm

The relay output can be connected to an alarm

signaling device. Current is 2A at 30VDC.

Power-Up Sequence

When the switch is powered up:

All Link/ACT LEDs blink momentarily.

The Power 1, 2 LEDs light up and stay lit.

LEDs for every port connected to a device

will flash, as the switch conducts a brief

Power On Self-Test (POST).

6 Console Configuration

Connect to the switch console by

connecting the DB9 cable to the console

port of the switch and to the serial port of

the computer running a terminal emulation

application (such as HyperTerminal or

Putty).

Configuration settings of the terminal-

emulation program: Baud rate: 115,200bps,

Data bits: 8, Parity: none, Stop bit: 1, Flow

control: none.

The default login name is “root,” no

password.

7 Web Configuration

Log in to the switch by launching a web

browser and entering 192.168.1.10 in the

address bar.

Enter the default login ID: root (no

password) and click “Login.” The system

information screen will display.

8 Other information

DIN-Rail Assembly Startup, and Dismantling

Assembly: Place the Switch on the DIN rail

from above using the slot. Push the front of

the Switch toward the mounting surface

until it audibly snaps into place.

Startup: Connect the supply voltage to

start up the Switch via the terminal block.

Dismantling: Pull out the lower edge and

then remove the Switch from the DIN rail.

Power wiring information:

Use cable type - AWG (American Wire Gauge) 18-

24 and corresponding pin type cable terminals.

Using torque value 1.7 lb-in, do not use excessive

force when fixing wiring.

The rating of the power wire used must be

at least 105°C.

Label clean up:

Indoor use and pollution degree II, it must

be wiped with a dry cloth for clean up the

labelling.

If the equipment is used in a manner not

specified by the manufacturer, the

protection provided by the equipment may

be impaired.

The Ethernet switch shall be mounted in the

Industrial Control Panel and ambient

temperature should not exceed 75 °C.

Manufacturer information:

ETHERWAN SYSTEMS, INC.

4F-7, No. 79, Sec. 1, Xintai 5th Road, Xizhi

District, New Taipei City 221, Taiwan

Altitude up to 2000 m

Indoor use only

Humidity range (Operational): 5% to 95%,

non-condensation
