ETC F-Drive W1 Series Manuel utilisateur

F-Drive Series W1

Installation Manual

Part Number: 7148M2110 Rev: A

Released: 2020-06

To view a list of ETCtrademarks and patents, go to etcconnect.com/ip. All other trademarks, both marked

and not marked, are the property of their respective owners.

ETC intends this document, whether printed or electronic, to be provided in its entirety.

Table of Contents

Table of Contents 3

Introduction 1

Document Conventions 1

Help from ETC Technical Services 2

Safety 3

IMPORTANTSAFEGUARDS 3

Chapter 1 Overview 4

Features 4

W1 Models 5

Emergency System Overview 6

W1 Emergency Functionality 6

Before You Begin Installation 8

Installation Requirements 8

Power Disconnect Device 8

Chapter 2 W1 Installation 9

Prepare to Install the W1 9

Parts and Tools 9

Mounting Straps 10

Electrical and Wiring Specifications 11

Install the W1 12

Wall-Mount the W1 Driver 12

Connect the Power Input 13

DMXIn and Thru Connections 15

Terminate DMXIn and DMXThru 17

Terminate Outputs 17

Chapter 3 W1 Emergency Driver Installation 20

Wire a W1 Emergency Driver 20

Connect the Sense Input 22

Connect the Maintained Input 22

Configure the W1 CC Emergency Driver Test Button for

Low-Voltage Loads 23

Complete the Installation 23

Chapter 4 Power Up and Control 24

Power Up Procedure 24

Identify 24

DMX System Control 24

Navis Luminaire DMXPersonalities 24

Edit and Save Configuration Files 25

RDM Parameters 25

Update Firmware 27

W1 Driver Firmware 27

Maintenance 28

Emergency Operation and Test 28

Troubleshooting 29

Test Button 29

LEDIndicators 29

Appendix A Compliance 30

FCC-Part 15 Class A 30

DMX 30

4 W1 Installation Manual

Introduction 1

Introduction

Congratulations on your purchase of the ETC F-Drive Series W1. The F-Drive Series W1 Driver

LEDpower control solutionprovides a centralized approach for controlling LEDluminaires. It is a

wall-mount driver that provides power and data for up to four circuits in standard and

emergency installations. By maintaining remote, easy access to the driver, LED-based systems

can be easily installed and serviced, while ensuring critical components are readily accessible to

support staff.

Document Conventions

This document uses the following conventions to draw your attention to important information.

Note:

Notes are helpful hints and information that is supplemental to the main text.

CAUTION:

A Caution statement indicates situations where there may be

undefined or unwanted consequences of an action, potential for data loss or

an equipment problem.

WARNING: A Warning statement indicates situations where damage may

occur, people may be harmed, or there are serious or dangerous

consequences of an action

WARNING: RISK OF ELECTRIC SHOCK! This warning statement indicates

situations where there is a risk of electric shock.

All ETC documents are available for free download from our website: etcconnect.com.

Please email comments about this manual to: TechComm@etcconnect.com.

2 W1 Installation Manual

Help from ETC Technical Services

If you are having difficulties and your problem is not addressed by this document, try the ETC

support website at support.etcconnect.com or the main ETC website at etcconnect.com. If none

of these resources are sufficient, contact ETC Technical Services directly at one of the offices

identified below. Emergency service is available from all ETC offices outside of normal business

hours.

When calling for help, take these steps first:

•

Prepare a detailed description of the problem

•

Go near the equipment for troubleshooting

•

Find your notification number if you have called in previously

Americas United Kingdom

ETC, Inc. ETC Ltd

Technical Services Department Technical Services Department

3031 Pleasant View Road 26-28 Victoria Industrial Estate

Middleton, WI 53562 Victoria Road,

800-775-4382 (USA, toll-free) London W3 6UU England

+1-608 831-4116 +44 (0)20 8896 1000

service@etcconnect.com techservltd@etcconnect.com

Asia Germany

ETCAsia ETC GmbH

Technical Services Department Technical Services Department

Room 1801, 18/F Ohmstrasse 3

Tower 1, Phase 1 Enterprise Square 83607 Holzkirchen, Germany

9 Sheung Yuet Road +49 (80 24) 47 00-0

Kowloon Bay, Kowloon, Hong Kong techserv-germany@etcconnect.com

+852 2799 1220

techserv-asia@etcconnect.com

France

ETC France

Zone Urbaparc -

Bâtiment E

6 Boulevard de la Libération

Saint-Denis, 93200

+33 1 4243 3535

techservltd@etcconnect.com

Introduction 3

Safety

The F-Drive Series W1 is intended for professional use only. Read the entire manual before

using this equipment.

IMPORTANTSAFEGUARDS

When using electrical equipment, basic safety precautions should always be followed

including the following:

•

READ AND FOLLOW ALL SAFETY

INSTRUCTIONS.

•

Do not use outdoors.

•

Do not let power supply cords touch hot surfaces.

•

Do not mount near gas or electric heaters.

•

Equipment should be mounted in locations and at heights where it will not

readily be subjected to tampering by unauthorized personnel.

•

The use of accessory equipment not recommended by the manufacturer may

cause an unsafe condition.

•

Do not use this equipment for other than intended use.

•

To reduce the risk of fire and overheating, make sure all connections are tight.

•

Turn off electrical power before modifying the lighting system in any way.

SAVE THESE INSTRUCTIONS

4 W1 Installation Manual

Chapter 1

Overview

F-Drive W1 and W1E Drivers

Features

•

Compatible with a wide range of control systems

•

DMX/RDM control input with per-circuit patching

•

W1E models are UL 924 listed for emergency lighting control

Overview 5

W1 Models

Variant Load Type Output Type

Max.

Power

per

Circuit

Max.

Power

per Card

Output

Connectors

W1 Fade to Warm

Driver

FDW1FTWD (-CE) up to four total

ETCArcSystem Navis 100

Fade to Warm luminaires

constant current,

maximum

450mA per

channel

50 W 150 W

RJ45 and 4

two-pin

terminal

blocks

W1 Fade to Warm

Emergency Driver

FDW1EFTWD (-CE)

W1 CC Driver

FDW1CCD (-CE)

•

up to four total ETC

ArcSystem Navis 100 White

luminaires

•

up to four total

ETCArcSystem Pro One-

Cell White luminaires

Pro One-Cell

Pro One-Cell Small

Pro One-Cell Micro

•

200–700 mA fixtures

manufactured by others

constant current,

adjustable from

200–700mA,

default output

600mA (see

Configure the W1

CC Driver on

page19

)

50W 150W

RJ45 and 4

two-pin

terminal

blocksW1 CC Emergency

Driver

FDW1ECCD (-CE)

W1 CV Driver

Constant Voltage

FDW1CVD (-CE)

24VDC fixtures 24VDC 50W 150W

4 two-pin

terminal

blocks

W1 CV Emergency

Driver Constant

Voltage

FDW1ECVD (-CE)

Note:

Use ONEtype of output connector. For example, use the RJ45 receptacle OR

the two-pin terminal blocks on a W1 Fade to Warm Driver or a W1 CC Driver.

Note:

F-Drive W1 Drivers do not support ArcSystem Navis 100 RGBW luminaires or

ArcSystem Pro One-Cell High Output luminaires.

CAUTION:

Setting the F-Drive W1 CC Driver to output more current than

the manufacturer recommends for the loads may reduce the lifetime or cause

damage to the load. See Configure the W1 CC Driver on page19.

6 W1 Installation Manual

Emergency System Overview

The W1 Emergency Driver is a UL924 listed variant of the W1 Driver.

Install the W1 Emergency Driver in a location that is accessible by qualified personnel for testing

of the emergency operation.

Note:

Installation must follow all national and local codes for electrical equipment.

Note:

Normal and emergency wiring cannot be contained in the same conduit

according to NEC 700.10(B).

W1 Emergency Functionality

The W1 Emergency Driver requires two circuit connections. These inputs have the following

functions:

1. "Sense" input. The "Sense" input accepts 40-300 VACor VDC. There are two options for

"sense" input:

•

A normal mains supply circuit to sense failure of the normal supply.

•

Alternatively, this can be the 48 VDCpanic output from an F-Drive R12 Driver to sense

failure of the power to the F-Drive R12.

Connect this circuit to the "Sense" input terminal.

2. "Maintained"input:a circuit with a changeover relay that switches to a battery-backed

supply that provides power to the fixture when the normal mains supply fails. Connect this

circuit to the "Maintained" input terminal.

"Sense" detects when power is lost and forces the fixture to a full-on state, powered by the

emergency supply through the maintained input. Control of the fixture will not be available until

the sense input has been restored.

Sense Input from Normal Mains Supply

CAUTION:

If you are using a normal mains supply for the "Sense" input, do

not mix 120 Vand 277 V between the sense and emergency feeds. "Sense"

(normal) and "Maintained" (normal/emergency) must have the same phase.

The diagram below shows the recommended installation.

F-Drive W1E

Driver

Maintained

Changeover Relay

Battery

Backed

Supply

Normal

Mains

Supply Sense
