ETC ALiEn2 Manuel utilisateur

Step 2 - Setup Security

a) Press instll.

c) Enter the default login of 000-0000.

b) Scroll down to the Security menu.

b) Press selct and scroll down until you

see Operator ID.

d) Press selct and set the desired ID.

e) Change the Installer ID in the same

manner.

Step 3 - Set Date/Time

a) Press instll and scroll to Date/Time.

b) Press selct to enter the menu.

c) Adjust the Date and/or Time.

d) Set the Daylight savings time option to

on if desired.

Step 4 - Controller Setup

a) Press instll and then scroll to Inputs.

b) Enable and congure any required

devices.

c) Press cncl to back out to the menu.

d) Scroll to Outputs to enable additional

valves in the same manner.

e) Enter the Alarms menu to congure the

behaviour when failures occur.

f) Enter Optimize to set the optimization.

Note: Changes to install settings do not

take eect until the next Close cycle.

Step 5 - Start Controller

a) Press clse or opn to reset the controller

to a given state.

b) The controller will set the valves and the

screen will update to show the current

state and remaining time.

install

select

cancel

open

select

install

select

install

Step 1 - Wire Back Panel

a) Plug in Valve Connectors.

b) Connect Field Devices.

- 2 Wire Switches are wired to COM and SIG.

- 3 Wire Sensors are wired to PWR, COM and SIG.

c) Plug in Battery Connection.

d) Connect Solar Panel.

PWR

SIG

COM

Quick Install

Guide

www.ETCorp.ca

Changing Timers/Set Points

a) Press setin.

b) Use the up/down arrow keys to scroll

through each setting.

c) Press selct to edit a given setting.

Note: Most timers are related to each

other and will auto adjust. Values entered

below the min or above the max will be

adjusted automatically.

Note: Timer settings do not take eect

until the next Close cycle.

Adding/Removing Devices

a) Press instl and then scroll to the Inputs

menu.

b) Press selct and then scroll through each

screen.

c) Press selct to edit a given setting.

Note: Additional device screens are

hidden until the device is enabled.

Note: Changes to input settings do not

take eect until the next Close cycle.

Change State Manually

a) From the main screen, press selct.

b) Select yes, and then set the desired state

and time.

c) The controller will enter the desired state

and then resume normal operation once

complete.

Modifying Alarms

a) Press instll and scroll to the Alarms

menu.

b) Scroll to the desired alarm setting and

press selct to modify it.

Note: Fast Trip and Non Arrival alarms are

consecutive occurances.

install

select

settings

install

select

Congure Modbus

a) Press instll and scroll to the Modbus

menu.

b) Press selct to enter the menu.

c) Select the Modbus Port and set it to

enabled.

d) Scroll through each setting, ensuring

that it matches the Modbus master.

Note: To communicate properly, all

communication settings must match the

master’s settings.

install

select

View History

a) Press htry to enter the History menu.

b) Selct the type of history you wish to see.

c) Scroll through each history screen.

Note: All logs in the history menu have

multiple records displayed in reverse

chronological order.

history

select

ET-12000-1018-0000 rev 3

www.ETCorp.ca

Quick Tips
