Ergo Systems 20008D Manuel utilisateur

Model and serial number may be found

at the rear of the 8 Day Feeder base.

Please record both model and serial

number in a safe place for future use.

Where Purchased : ______________________

Date Purchased : Month ________________

: Day __________________

: Year __________________

Model No. : ______________________

Serial # : ______________________

The Owner’s Manual contains

information for all models.

Read and keep this manual for

future reference.

This manual contains important

information on Safety, Assembly,

Operation and Maintenance.

Ergo Systems Inc. Rev# 1.2

MODEL NO.

20008D

8 Day Autopetfeeder

Owner’s Manual

ergo systems inc.

LIMITED WARRANTY

Please read this warranty carefully. Ergo Systems Inc. will warranty this product to be free from manufacturing

defects, including workmanship, when assembled and operated according to operating instructions enclosed with

this product, for a period of ninety (90) days from the date of original purchase. This warranty is non-transferable and

applies solely to the original purchaser and does not extend to subsequent owners of this product. Please register

your product at http://www.autopetfeeder.com.

1. Repair service for a period of ninety (90) days from the date of original purchase at no charge for parts

and labor with proof of purchase.

2. Replacement of defective parts for a period of 12 months from the date of original purchase with proof of

purchase. (Labor not included after Initial ninety (90) days).

3. This warranty does not cover cost incurred in the shipping of the product to and from Ergo Systems

Inc. for service. Shipping to Ergo Systems Inc. must be prepaid and insured by UPS or other parcel

delivery services.

THIS WARRANTY IS VOID IF THE PRODUCT IS:

1. Damaged due to negligence, abuse, misuse, accident, modication, tampering, alteration, faulty installation

and/or acts of God.

2. Used for commercial applications or rentals.

3. Modied or repaired by anyone other than Ergo Systems Inc.

The extent of Ergo Systems Inc. under this limited warranty is the repair or replacement of the product at the sole

discretion of Ergo Systems Inc, In no event shall Ergo Systems Inc.’s. liability exceed the purchase price paid by the

purchaser. Under no circumstances shall Ergo Systems Inc. be liable for any loss, direct, indirect, incidental, foreseen,

unforeseen, special or consequential damage arising out of or in connection with the use of this product. This

warranty is valid only in the United States of America and Canada.

Important : This is an Owner’s Manual for 8 Day Autopetfeeder.

Please do not discard this.

Congratulations on purchasing the “8 DAY

AUTOPETFEEDER”. You will now have more time on

your hands and your pet can be fed on time. Before

you can use this appliance you need to follow same

simple steps to assemble the 8 Day Autopetfeeder.

DO NOT RETURN THE PRODUCT TO

THE STORE

Call 1-888 ERGOSYS (1-888-374-6797)

If there are missing parts. Check all packing for missing

parts prior to discarding the package.

Before you call us, please have the following

Information ready.

1. Details of purchase like Invoice number (found

on the bill or invoice)

2. Name and model number of the product (found

on the manual and on the carton.)

3. Actual problem after following the instructions.

4. List of missing parts.

Reviewing these important safety alert symbols

When you see this Safety Symbol on the following pages, It will alert you to the

possibility of damage to your 8 Day Pet Feeder. If you do not comply with the

corresponding instructions. The hazard may come from something mechanical or

electrical. Read the instructions carefully.

Components

1. Base

2. Bowl Cover

3. Bowl

4. Ice Pack

5. Digital Timer

6. Bowl Cover Handle

7. Cover Lock Screw

List of parts in the 8 day Autopetfeeder Box

Cover Lock Screw

Bowl Cover Handle

Ice Packs (Quantity 4)

Bowl Cover

8 Day Feeder Base

Bowl

Digital Timer

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Step 2

pRemove the three screws to remove the Bowl

Cover Handle. Align the bowl to the cover and

tighten the screws.

Assembly

Cover Lock Screw

Fig-1

The 8-Day Autopetfeeder comes as a pre-assembled unit.

Bowl Cover Alignement

Step 1

pRemove the cover lock screw from the Bowl

cover handle.

Fig-2

Fig-3

Installing batteries in the Timer Module.

Step 1

p Place the feeder bottom side up. You will

nd the battery compartment at the back of

the Timer Module.

Step 2

p Open the battery compartment by pushing

the plastic tab to the left and lift up.

Step 3

p Install 3 new AA batteries in the battery

compartment.

Step 4

p Close and latch the cover.

NOTE:

Always install new batteries. When you replace the

old battery you must do it within 1 minute or you will

loose the programs.

Replacing Timer Module

pIn the event that the timer module has to be

replaced, place the feeder bottom side up. Then

remove the two screws that attach the timer to

the feeder base.

pThen turn the feeder rightside up and lift the

timer out of the base.

pTo install timer follow the above steps in reverse.

Fig-7

Fig-5

Fig-6

THE TIMER WILL MAKE A BEEPING

SOUND WHEN THE BATTERY IS LOW

Fig-4

Screw

The bottom view of the 8 day feeder

This is the Digital Timer unit for 8 Day Autopet Feeder. The timer works on 3 AA batteries. With this

Digital Controller Module you can record your voice which will be played back every meal time.

Records your voice up to 7 seconds.

NOTE:

p Remove bowl cover to program the timer.

p Press RESET button prior to programming the timer. Use 3 AA Batteries. Do not mix old and

new batteries.

1.0 Setting the time mode: 24 hour (military time) or 12 hour AM/PM MODE

TIMER PROGRAMMING

pPress the HOUR and MINUTE button simultaneously

to activate 12 hour or 24 hour program mode. The

display will begin to ash.

INDICATES

HOUR

INDICATES AM/PM

24 HOUR MODE

INDICATES

MINUTES

INDICATES

SECONDS

SPEAKER INDICATOR

BATTERY LEVEL

INDICATOR

FEED ON/OFF

INDICATOR

RESET BUTTON

ON/AUTO/OFF

BUTTON

MINUTE BUTTON

SPEAKER

HOUR BUTTON

INDICATES

RECORD MEMORY

PROGRAM BUTTON

VOICE RECORDING

BUTTON

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-1

1.1 Setting the Current Time

p Press the HOUR and MINUTE button

simultaneously to activate the setting

mode.

pPress the HOUR button to set the HOUR.

p Press the PROGRAM button to switch from the

present mode to the next mode i.e. from 24

hour to AM/PM or AM/PM to 24 hour mode.

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-2

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-3

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-4

1.2 Understanding the Timer

pThe autopetfeeder is capable of feeding your pet up to 8 times per day. You can set the time for the

feeder up to 8 times per day. This will give you control over the amount of food you feed your pet and

also the time your pet is fed. By pressing the PROGRAM button you will enter the programming mode.

The display will now show 1, At this time the feeder will turn ON and after the cover rotates 45 degrees,

the feeder will turn OFF.

pThe pet feeder is capable of feeding both dry and canned food and pet meds.

pPress ON/AUTO/OFF button to go back to clock

mode.

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-6

pPress the MINUTE button to set the MINUTE.

Fig-5

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

NOTE: The seconds setting cannot be altered.

1.3 ON/AUTO/OFF

pPress ON/AUTO/OFF button to toggle

between TEST, AUTO and OFF mode. The

display will show the mode in which the

timer is set.

pIn TEST mode the bowl cover rotates

45 degree and enters the next feed

compartment.

pIn AUTO mode the feeder works as per the

programmed schedule.

Now let us understand the dierent modes of operation in the timer.

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-8

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-7

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-9

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-10

pIn OFF mode the feeder does not work.

1.4 Setting the Program Mode

pPress the PROGRAM button to

enter into program mode. The

display will show 1 whch means

that we are setting the 1st schedule.

pPress the HOUR button till the display shows 7 AM.

1.5 Timer Programming Examples :

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-11

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-12

pLet us set a schedule for 7.10 am.

pPress the MINUTE button till the

display shows 10.

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-13

pPress the PROGRAM button again

and the display will show 2 which

means that we are setting the

second feed time.

RECORD

PROG HOUR MIN ON/AUTO/OFF

RESET

Fig-14
