Epson ELP-3300 - Data/Video Projector Manuel utilisateur

EPSON®

Owner’s Manual

or transmitted in any form or by any means, electronic, mechanical, photocopying, recording,

or otherwise, without the prior written permission of Seiko Epson Corporation. No patent

liability is assumed with respect to the use of the information contained herein. Neither is any

liability assumed for damages resulting from the use of the information contained herein.

Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this

product or third parties for damages, losses, costs, or expenses incurred by purchaser or third

parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications,

repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with

Seiko Epson Corporation’s operating and maintenance instructions.

Seiko Epson Corporation shall not be liable against any damages or problems arising from the

use of any options or any consumable products other than those designated as Original EPSON

Products or EPSON Approved Products by Seiko Epson Corporation.

EPSON is a registered trademark of Seiko Epson Corporation.

EPSON Connection is a service mark of Epson America, Inc.

General Notice: Other product names used herein are for identification purposes only and may

be trademarks of their respective owners. EPSON disclaims any and all rights in those marks.

The Energy Star emblem does not represent EPA endorsement of any product or service.

Torrance, California, USA 2/96

iii

FCC Compliance Statement

For United States Users

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment.

WARNING

The connection of a non-shielded equipment interface cable to this equipment will invalidate the FCC Certification of this

device and may cause interference levels which exceed the limits established by the FCC for this equipment. It is the

responsibility of the user to obtain and use a shielded equipment interface cable with this device. If this equipment has

more than one interface connector, do not leave cables connected to unused interfaces. Changes or modifications not

expressly approved by the manufacturer could void the user’s authority to operate the equipment.

DOC (for Canadian Users)

This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment regulations.

Cet appareil numérique de la Classe A respecte toutes les exigences du Réglement sur le materiel brouilleur du Canada.

AppleWarranty Disclaimer

Apple Computer, Inc. (“Apple”) makes no warranties, express or implied, including without limitation the implied

warranties of merchantability and fitness for a particular purpose, regarding the Apple software. Apple does not warrant,

guarantee or make any representations regarding the use or the results of the use of the Apple software in terms of its

correctness, accuracy, reliability, currentness or otherwise.The entire risk as to the results and performance of the Apple

software is assumed by you. The exclusion of implied warranties is not permitted by some states. The above exclusion may

not apply to you.

In no event will Apple, its directors, officers, employees or agents be liable to you for any consequential, incidental or

indirect damages (including damages for loss of business profits, business interruption, loss of business information, and

the like) arising out of the use or inability to use the Apple software even ifApple has been advised of the possibility of

such damages. Because some states do not allow the exclusion or limitation of liability for consequential or incidental

damages, the above limitations may not apply to you. Apple’s liability to you for actual damages from any cause

whatsoever, and regardless of the form of the action (whether in contract, tort (including negligence), product liability or

otherwise), will be limited to $50.

Energy Star Compliance

EPSON is an Energy Star Partner and this projector complies with the Energy Star program's

guidelines for energy efficiency.

iii

Important Information About Your ELP-3300

Please read the following important information about your ELP-3300 projector.

Important Safety Information

WARNING: Never look into the projector lens when the lamp is turned on;

the bright light can damage your eyes. Never let children look into the lens

when it is on.

WARNING: Never open any cover on the projector, except the lamp, fuse, and

filter covers. Dangerous electrical voltages inside the projector can severely

injure you. Except as specifically explained in this Owner’s Manual, do not

attempt to service this product yourself. Refer all servicing to qualified

service personnel.

Caution: When you replace the lamp, never touch the new bulb with your

bare hands; the invisible residue left by the oil on your hands may shorten

the bulb life. Use a cloth or glove to handle the new bulb.

Remote Control Information

The ELP-3300 allows you to operate it by remote control via infrared (IR)

receivers located at the front and back of the projector. The projector may not

respond to remote control commands under the following conditions:

• The ambient light is too bright

• Certain types of fluorescent lighting are used

• A strong light source shines into either IR receiver

• Other equipment that emits infrared energy, such as a radiant room heater, is

in the room.

These conditions commonly cause problems for most infrared-controlled

equipment. Try the following solutions:

• The remote control unit’s batteries may be low on power; replace them.

• Dim the ambient lighting and/or turn off any fluorescent lights.

• Close any window coverings and/or move the projector out of direct sunlight.

• Turn off other equipment that emits infrared energy.

If the remote control still does not work properly, cover the unused IR receiver

on the projector with light-blocking material, such as masking tape. Remember

you can always control your computer-based presentation directly from the

computer, even in an environment containing one of the conditions listed above.

README File Information

The diskettes that came with your projector include README files that contain

additional important information about the projector. Be sure to read these files.

Contents

Introduction

Getting the Most Out of Your Projector x

Optional Accessories xii

About This Manual xiii

Safety Instructions xiv

Where to Get Help xvi

Electronic support services xvii

Energy Star Compliance xviii

1 Installation 1

Unpacking the Projector 2

Additional components 3

Setting Up the Projector 4

Connecting to a Computer 6

Connecting to a PC desktop computer 7

Contents

Connecting to a PC laptop computer 8

Connecting to a desktop Macintosh 9

Connecting to a PowerBook 10

Connecting to a Video Source 11

Connecting to an Audio Source 13

Connecting to an External Speaker or PA System 14

Setting Up Serial Communication 15

Connecting the serial cable 15

Installing the software 16

Connecting the Remote Control with the Lead Wire 17

2 Using the Projector 19

Turning the Equipment On and Off 20

Focusing and Positioning the Screen Image 21

Controlling the Projector 23

Adjusting the settings from ELP Link 26

Monitoring the Projector 27

Using Rear Projection 28

3 Using the Menus 29

Accessing the Menus 30

Changing menu settings 31

Accessing ELP Link menus 32

Restoring the default settings 33

Menu Settings 33

Contents

vii

Computer menu 34

Video menu 36

Display menu 37

Audio menu 39

Options menu 40

Custom menu 41

4 Remote Control of the Computer 43

ELP Remote Programmer Templates 44

Starting the ELP Remote Programmer 45

Assigning a Macro to a Programmable Button 48

Using record mode 49

Using manual mode 51

Activating a Template 51

ELP Remote Programmer Menus 52

5 Maintenance 53

Cleaning the Lens 54

Cleaning the Projector Case 54

Cleaning the Air Filter 54

Cleaning the Trackball 56

Replacing the Lamp 58

Resetting the lamp timer 61

Replacing the Fuse 62

viii

Contents

6 Troubleshooting 65

Problems with the Projector 66

Problems with the Image or Sound 69

Problems with the Remote Control 72

A Technical Specifications 75

General 75

Optical 76

Projector Lamp 76

Mechanical 76

Electrical 77

Environmental 77

Supported Monitor Displays 78

Pin Assignments 79

Glossary 81

Index 85

Introduction

The compact, lightweight EPSON®ELP-3300 Projector allows you to project

computer images and video onto a large screen for full-color presentations. The

projector can connect simultaneously to two image sources; one can be your PC

or Apple®Macintosh®computer and the other can be a video source, such as a

VCR, camcorder, digital camera, or laser disk player. Audio can be supplied with

one or both image sources.

Images are displayed in up to 16 million colors at a resolution of 640 x480

pixels. The projector’s 300-lumen bulb produces bright images that can be easily

seen in rooms light enough to take notes. You can play audio on the projector’s

internal speakers or route it to an external speaker for amplification. You control

the projector through a hand-held remote control, which allows you to switch

between image sources and make adjustments to the projected image.

The projector supports any computer capable of VGA output, including IBM®-

compatible PCs and laptops and Apple Macintosh computers, including the

PowerBookTM and Power Macintosh.TM The video source can be NTSC, PAL,

and SECAM in composite video or S-Video format.
