Epson EB-Z10005U Manuel utilisateur

Specications

Contents

f Product Overview ………………………………………………………………… 3

f Dimensions …………………………………………………………………… 10

f Dimensions with Ceiling Mount ……………………………………………… 11

f Interface ……………………………………………………………………… 14

f Remote Control Operating Range (Wireless) ………………………………… 15

f Screen Size and Projection Distance ………………………………………… 15

f Lens Compatibility Table ……………………………………………………… 29

f Supported Resolutions ………………………………………………………… 29

f Available Lens Shift Adjustment Range ……………………………………… 32

f Available Keystone Correction Range ………………………………………… 33

f Installation Angle ……………………………………………………………… 33

f Installation Environment ……………………………………………………… 34

f Serial Connection ……………………………………………………………… 35

f Monitoring and Control ……………………………………………………… 36

f Cautions ……………………………………………………………………… 48

f Disclaimer ……………………………………………………………………… 48

f Product Overview

This product has high luminance and high luminous ux, optimal for projecting in a large space such as a

lecture hall or a large conference room. These projectors allow for exible installation with features such as

portrait projection, and come with a variety of adjustment features such as Geometric Correction and Edge

Blending.

EB-Z10005U/EB-Z10000U/EB-Z9875U/EB-Z9870U/EB-Z9750U

Product Specications

Product name

EB-Z10005U

EB-Z10000U

EB-Z9875U

EB-Z9870U EB-Z9750U

Projection system RGB liquid crystal shutter

Brightness*1*2

2 standard lamps

(Power Consumption: Normal/ECO)

10000 lm/6600 lm

8700 lm/6600 lm 7500 lm/6600 lm

1 standard lamp

(Power Consumption: Normal/ECO)

5000 lm/3300 lm 4350 lm/3300 lm

3750 lm/3300 lm

2 lamps for portrait use 7500 lm

1 lamp for portrait use 3750 lm

Contrast ratio*2 15000:1 (Auto Iris: Normal/High Speed)

Supported RGB signal resolutions WUXGA*3, UXGA, WSXGA+, SXGA+, SXGA, WXGA++, WXGA+, WXGA, XGA,

SVGA, VGA, MAC13”, MAC16”, MAC19”, MAC21”

Supported video signals

Video: NTSC/PAL/SECAM

Component: SDTV (480i/480p), SDTV (576i/576p), HDTV (720p), HDTV

(1080i/1080p*4)

Supported digital signals

WUXGA*3, UXGA, WSXGA+, SXGA+, SXGA, WXGA++, WXGA+, WXGA, XGA,

SVGA, VGA, SDTV (480i/480p), SDTV (576i/576p), HDTV (720p), HDTV

(1080i/1080p)

Pixel Number (Width × Height × Number of

LCDs) 1920 x 1200 x 3

LCD panel size (diagonal) 1.03" Wide

Color reproducibility Approximately 1,070 million colors

Scanning

frequency

Analog Horizontal: 15 to 92 (KHz) Vertical: 50 to 85 (Hz)

HDMI Horizontal: 15 to 75 (KHz) Vertical: 24, 30, 50, and 60 (Hz)

SDI

Horizontal: 15 to 67.5 (KHz) Vertical: 50 and 60 (Hz)

Projection lens Varies depending on the lens

Zoom System Optics/Automatic

Zoom ratio Varies depending on the lens

Focus System Automatic

Lens Shift*5 Range Vertical 60%, horizontal 18% (except for Rear projection wide lens)

System Automatic

Dimensions (W × H × D) mm 534 × 197 × 741 (not including raised section)

Mass (with Standard zoom lens) Approx. 26 kg Approx. 25 kg

Lamp Output (W)/

Classication

Standard lamp 380W UHE x2 (ELPLP81 (1 pack), ELPLP82 (2 packs))

Lamp for portrait use 304W UHE x2 (ELPLP83 (1 pack), ELPLP84 (2 packs))

Product name

EB-Z10005U

EB-Z10000U

EB-Z9875U

EB-Z9870U EB-Z9750U

Lamp replacement

cycle

Standard lamp

(Power Consumption:

Normal/ECO)

Approx. 1900 hours/

Approx. 3900 hours

Approx. 2400 hours/

Approx. 3900 hours

Approx. 2900 hours/

Approx. 3900 hours

Lamp for portrait use Approx. 900 hours

Operating temperature*6 0 to +50°C No condensation (Altitude 0 to 1,499 m)

0 to +45°C No condensation (Altitude 1,500 to 3,048 m)

Power supply

AC 100 - 240V ± 10%,

50/60Hz,

11.2 - 4.9 A

AC 100 - 240V ± 10%,

50/60Hz,

10.0 - 4.4 A

AC 100 - 240V ± 10%,

50/60Hz,

8.5 - 3.8 A

Power

consumption

100 - 120 V

Area

Operating (2

lamps, Power

Consumption:

Normal/ECO)

1120 W (Normal)

821 W (ECO)

995 W (Normal),

821 W (ECO)

844 W (Normal),

748 W (ECO)

Standing by 2.7 W (Communication On), 0.26 W (Communication O ) (for 100 V)

220 - 240 V

Area

Operating (2

lamps, Power

Consumption:

Normal/ECO)

1060 W (Normal)

788 W (ECO)

948 W (Normal),

788 W (ECO)

809 W (Normal),

721 W (ECO)

Standing by 2.9 W (Communication On), 0.37 W (Communication O ) (for 220 V)

Noise level*2

(Power Consumption: Normal/ECO) 40 dB/35 dB 38 dB/35 dB 37 dB/35 dB

Dissipation BTU

(max.)

100 - 120 V Area 3808 BTU/h 3383 BTU/h 2870 BTU/h

220 - 240 V Area 3604 BTU/h 3223 BTU/h 2751 BTU/h

Air ow (max.) 165.9 CFM

Image input ports

Mini D-Sub15-pin x1, 5BNC x1, HDMI x1, Mini

DIN 4-pin x1, Composite video (1 BNC) x1, DVI-D

24 pin x1, HDBaseT x1, SDI (1BNC) x1

Mini D-Sub15-pin x1,

5BNC x1, HDMI x1,

Mini DIN 4-pin x1,

Composite video (1

BNC) x1, DVI-D 24 pin

x1, HDBaseT x1

Image output port Mini D-Sub15-pin x1

Network

RJ45 (100BASE-TX/10BASE-T) x1

USB connector (A type) x1 (for wireless LAN unit*7 corresponding to

IEEE802.11b/g/n)

Control ports RJ45 x1, Mini D-Sub9-pin x1 (RS-232C), stereo mini x1 (for wired remote

control), HDBaseT x1

Function

Others

Geometric Correction function, Edge Blending, Portrait Projection*8,

2 lamps type, Lamp Relay, Schedule, Shutter, Split Screen, Frame

Interpolation, Password Protection, Memory function, Direct Power On,

Direct Shutdown, Network Projection function

Products supplied

Power cord (3 m), Computer cable (1.8 m), Remote control (with 2 AA size

batteries), Cable clamp for power cord, Cable clamp for HDMI cable, User

manuals

*1 The specications are when a standard zoom lens ELPLS04 is attached.

*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.

*3 Only VESA CVT-RB (Reduced Blanking) signals are supported.

*4 Only for input signals from the Computer input port.

*5 The lens cannot be shifted to the maximum in all four directions. The Rear projection wide lens ELPLR04 does not support

lens shift.

*6 At an altitude of 0 to 1,499 m, the operating temperature is 0 to +50˚C when Power Consumption is set to ECO or Temp

Interlock, and 0 to +45˚C when it is set to Normal.

At an altitude of 1,500 to 3,048 m, the operating temperature is 0 to +45˚C when Power Consumption is set to ECO or

Temp Interlock, and 0 to +40˚C when it is set to Normal.

*7 The wireless LAN unit is an optional accessory.

*8 You need a lamp unit (for portrait, ELPLP83 or ELPLP84) and a frame (ELPMB44).

EB-Z11000W/EB-Z9900W/EB-Z9800W

Product Specications

Product name

EB-Z11000W

EB-Z9900W EB-Z9800W

Projection system RGB liquid crystal shutter

Brightness*1*2

2 standard lamps

(Power Consumption: Normal/

ECO)

11000 lm/7100 lm

9200 lm/7100 lm

8300 lm/7100 lm

1 standard lamp

(Power Consumption: Normal/

ECO)

5500 lm/3550 lm 4600 lm/3550 lm

4150 lm/3550 lm

2 lamps for portrait use 8100 lm

1 lamp for portrait use 4050 lm

Contrast ratio*2 15000:1 (Auto Iris: Normal/High Speed)

Supported RGB signal resolutions UXGA, WSXGA+, SXGA+, SXGA, WXGA++, WXGA+, WXGA, XGA, SVGA, VGA,

MAC13”, MAC16”, MAC19”, MAC21”

Supported video signals

Video: NTSC/PAL/SECAM

Component: SDTV (480i/480p), SDTV (576i/576p), HDTV (720p), HDTV

(1080i/1080p*3)

Supported digital signals

WUXGA*4, UXGA, WSXGA+, SXGA+, SXGA, WXGA++, WXGA+, WXGA, XGA,

SVGA, VGA, SDTV (480i/480p), SDTV (576i/576p), HDTV (720p), HDTV

(1080i/1080p)

Pixel Number (Width × Height × Number of

LCDs) 1280 x 800 x 3

LCD panel size (diagonal) 1.03" Wide

Color reproducibility Approximately 1,070 million colors

Scanning

frequency

Analog Horizontal: 15 to 92 (KHz) Vertical: 50 to 85 (Hz)

HDMI Horizontal: 15 to 75 (KHz) Vertical: 24, 30, 50, and 60 (Hz)

Projection lens Varies depending on the lens

Zoom System Optics/Automatic

Zoom ratio Varies depending on the lens

Focus System Automatic

Lens Shift*5 Range Vertical 60%, horizontal 18% (except for Rear projection wide lens)

System Automatic

Dimensions (W × H × D) mm 534 × 197 × 741 (not including raised section)

Mass (with standard lens) Approx. 26 kg Approx. 25 kg

Lamp Output (W)/

Classication

Standard lamp 380 W UHE x2 (ELPLP81 (1 pack), ELPLP82 (2 packs))

Lamp for portrait use 304 W UHE x2 (ELPLP83 (1 pack), ELPLP84 (2 packs))

Product name

EB-Z11000W

EB-Z9900W EB-Z9800W

Lamp replacement

cycle

Standard lamp

(Power Consumption:

Normal/ECO)

Approx. 1900 hours/

Approx. 3900 hours

Approx. 2400 hours/

Approx. 3900 hours

Approx. 2900 hours/

Approx. 3900 hours

Lamp for portrait use Approx. 900 hours

Operating temperature*6 0 to +50°C No condensation (Altitude 0 to 1,499 m)

0 to +45°C No condensation (Altitude 1,500 to 3,048 m)

Power supply

AC 100 - 240V ± 10%,

50/60Hz,

11.2 - 4.9 A

AC 100 - 240V ± 10%,

50/60Hz,

10.0 - 4.4 A

AC 100 - 240V ± 10%,

50/60Hz,

8.5 - 3.8 A

Power

consumption

100 - 120 V

Area

Operating (2

lamps, Power

Consumption:

Normal/ECO)

1120 W (Normal)

821 W (ECO)

995 W (Normal),

821 W (ECO)

844 W (Normal),

748 W (ECO)

Standing by 2.7 W (Communication On), 0.26 W (Communication O ) (for 100 V)

220 - 240 V

Area

Operating (2

lamps, Power

Consumption:

Normal/ECO)

1060 W (Normal)

788 W (ECO)

948 W (Normal),

788 W (ECO)

809 W (Normal),

721 W (ECO)

Standing by 2.9 W (Communication On), 0.37 W (Communication O ) (for 220 V)

Noise level*2

(Power Consumption: Normal/ECO) 40 dB/35 dB 38 dB/35 dB 37 dB/35 dB

Dissipation BTU

(max.)

100 - 120 V Area 3808 BTU/h 3383 BTU/h 2870 BTU/h

220 - 240 V Area 3604 BTU/h 3223 BTU/h 2751 BTU/h

Air ow (max.) 165.9 CFM

Image input ports Mini D-Sub15-pin x1, 5BNC x1, HDMI x1, Mini DIN 4-pin x1, Composite

video (1 BNC) x1, DVI-D 24 pin x1, HDBaseT x1

Image output port Mini D-Sub15-pin x1

Network

RJ45 (100BASE-TX/10BASE-T) x1

USB connector (A type) x1 (for wireless LAN unit*7 corresponding to

IEEE802.11b/g/n)

Control ports RJ45 x1, Mini D-Sub9-pin x1 (RS-232C), stereo mini x1 (for wired remote

control), HDBaseT x1

Function

Others

Geometric Correction function, Edge Blending, Portrait Projection*8, 2 lamps

type, Lamp Relay, Schedule, Shutter, Split Screen, Password Protection,

Memory function, Direct Power On, Direct Shutdown, Network Projection

function

Products supplied

Power cord (3 m), Computer cable (1.8 m), Remote control (with 2 AA size

batteries), Cable clamp for power cord, Cable clamp for HDMI cable, User

manuals

*1 The specications are when a standard zoom lens ELPLS04 is attached.

*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.

*3 Only for input signals from the Computer input port.

*4 Only VESA CVT-RB (Reduced Blanking) signals are supported.

*5 The lens cannot be shifted to the maximum in all four directions. The Rear projection wide lens ELPLR04 does not support

lens shift.

*6 At an altitude of 0 to 1,499 m, the operating temperature is 0 to +50˚C when Power Consumption is set to ECO or Temp

Interlock, and 0 to +45˚C when it is set to Normal.

At an altitude of 1,500 to 3,048 m, the operating temperature is 0 to +45˚C when Power Consumption is set to ECO or

Temp Interlock, and 0 to +40˚C when it is set to Normal.

*7 The wireless LAN unit is an optional accessory.

*8 You need a lamp unit (for portrait, ELPLP83 or ELPLP84) and a frame (ELPMB44).

EB-Z11005/EB-Z11000/EB-Z9870

Product Specications

Product name EB-Z11005/EB-Z11000 EB-Z9870

Projection system RGB liquid crystal shutter

Brightness*1*2

2 standard lamps

(Power Consumption:

Normal/ECO)

11000 lm/7300 lm 8700 lm/7300 lm

1 standard lamp

(Power Consumption:

Normal/ECO)

5500 lm/3650 lm 4350 lm/3650 lm

2 lamps for portrait use 8500 lm

1 lamp for portrait use 4250 lm

Contrast ratio*2 15000:1 (Auto Iris: Normal/High Speed)

Supported RGB signal resolutions UXGA, SXGA+, SXGA, WXGA++, WXGA+, WXGA, XGA, SVGA, VGA, MAC13”,

MAC16”, MAC19”, MAC21”

Supported video signals

Video: NTSC/PAL/SECAM

Component: SDTV (480i/480p), SDTV (576i/576p), HDTV (720p), HDTV

(1080i/1080p*3)

Supported digital signals WUXGA*4, UXGA, SXGA+, SXGA, WXGA++, WXGA+, WXGA, XGA, SVGA, VGA

SDTV (480i/480p), SDTV (576i/576p), HDTV (720p), HDTV (1080i/1080p)

Pixel Number (Width × Height × Number of

LCDs) 1024 x 768 x 3

LCD panel size (diagonal) 1.06"

Color reproducibility Approximately 1,070 million colors

Scanning

frequency

Analog Horizontal: 15 to 92 (KHz) Vertical: 50 to 85 (Hz)

HDMI Horizontal: 15 to 75 (KHz) Vertical: 24, 30, 50, and 60 (Hz)

Projection lens Varies depending on the lens

Zoom System Optics/Automatic

Zoom ratio Varies depending on the lens

Focus System Automatic

Lens Shift*5 Range Vertical 56%, horizontal 19% (except for Rear projection wide lens)

System Automatic

Dimensions (W × H × D) mm 534 × 197 × 741 (not including raised section)

Mass (with standard lens) Approx. 26 kg Approx. 25 kg

Lamp Output (W)/

Classication

Standard lamp 380 W UHE x2 (ELPLP81 (1 pack), ELPLP82 (2 packs))

Lamp for portrait use 304 W UHE x2 (ELPLP83 (1 pack), ELPLP84 (2 packs))

Product name EB-Z11005/EB-Z11000 EB-Z9870

Lamp replacement

cycle

Standard lamp

(Power Consumption:

Normal/ECO)

Approx. 1900 hours/ Approx. 3900 hours

Lamp for portrait use Approx. 900 hours

Operating temperature*6 0 to +50°C No condensation (Altitude 0 to 1,499 m)

0 to +45°C No condensation (Altitude 1,500 to 3,048 m)

Power supply AC 100 - 240 V ± 10%,

50/60 Hz, 11.2 - 4.9 A

AC 100 - 240 V ± 10%,

50/60 Hz, 8.5 - 3.8 A

Power

consumption

100 - 120 V

Area

Operating (2

lamps, Power

Consumption:

Normal/ECO)

1120 W (Normal), 821 W (ECO) 844 W (Normal), 748 W (ECO)

Standing by 2.7 W (Communication On), 0.26 W (Communication O) (for 100 V)

220 - 240 V

Area

Operating (2

lamps, Power

Consumption:

Normal/ECO)

1060 W (Normal), 788 W (ECO) 809 W (Normal), 721 W (ECO)

Standing by 2.9 W (Communication On), 0.37 W (Communication O) (for 220 V)

Noise level*2

(Power Consumption: Normal/ECO)

40 dB/35 dB 37 dB/35 dB

Dissipation BTU

(max.)

100 - 120 V Area

3808 BTU/h 2870 BTU/h

220 - 240 V Area

3604 BTU/h 2751 BTU/h

Air ow (max.)

165.9 CFM

Image input ports

Mini D-Sub15-pin x1, 5BNC x1, HDMI x1, Mini DIN 4-pin x1, Composite video (1

BNC) x1, DVI-D 24 pin x1, HDBaseT x1

Image output port Mini D-Sub15-pin x1

Network

RJ45 (100BASE-TX/10BASE-T) x1

USB connector (A type) x1 (for wireless LAN unit*7 corresponding to

IEEE802.11b/g/n)

Control ports RJ45 x1, Mini D-Sub9-pin x1 (RS-232C), stereo mini x1 (for wired remote

control), HDBaseT x1

Function

Others

Geometric Correction function, Edge Blending, Portrait Projection*8, 2 lamps

type, Lamp Relay, Schedule, Shutter, Split Screen, Password Protection, Memory

function, Direct Power On, Direct Shutdown, Network Projection function

Products supplied

Power cord (3 m), Computer cable (1.8 m), Remote control (with 2 AA size

batteries), Cable clamp for power cord, Cable clamp for HDMI cable, User

manuals

*1 The specications are when a standard zoom lens ELPLS04 is attached.

*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.

*3 Only for input signals from the Computer input port.

*4 Only VESA CVT-RB (Reduced Blanking) signals are supported.

*5 The lens cannot be shifted to the maximum in all four directions. The Rear projection wide lens ELPLR04 does not support

lens shift. When using a short throw zoom lens ELPLU02, if you move it more than 50%, part of the screen cannot be

displayed correctly.

*6 At an altitude of 0 to 1,499 m, the operating temperature is 0 to +50˚C when Power Consumption is set to ECO or Temp

Interlock, and 0 to +45˚C when it is set to Normal.

At an altitude of 1,500 to 3,048 m, the operating temperature is 0 to +45˚C when Power Consumption is set to ECO or

Temp Interlock, and 0 to +40˚C when it is set to Normal.

*7 The wireless LAN unit is an optional accessory.

*8 You need a lamp unit (for portrait, ELPLP83 or ELPLP84) and a frame (ELPMB44).

Lens Specications

Lens Model

Number Lens Name

Projector Size

when Lens

Installed

D (mm)

Lens Mass F value f (mm) Zoom Rate Optical Power

Comparison

ELPLS04 Standard zoom

lens

741 1,820 g 1.65-2.51 36.00-57.35 1.61 100%

(standard)

ELPLU02

Short throw

zoom lens

793 3,000 g 2.0-2.1 14.8-17.7 1.2 88%

ELPLR04 Rear projection

wide lens

741 1,950 g 1.85 16.15 - 88%

ELPLW04 Wide zoom lens 766 2,860 g 1.8-2.26 27.32-37.04 1.37 95%

ELPLM06 Middle throw

zoom lens

773 2,600 g 1.81-2.4 55.43-83.3 1.5 94%

ELPLM07 Middle throw

zoom lens

777 2,200 g 1.81-2.34 80.59-121.1 1.5 92%

ELPLL07 Long throw

zoom lens

777 2,200 g 1.8-2.45 118.98-165.39 1.39 93%

Set the model number for the lens being used in Extended - Operation - Advanced - Lens Type from the projector's

Conguration menu.

Ceiling Mount Mass

You need a dedicated ceiling mount to suspend the projector from a ceiling. Special expertise is required

to suspend the projector from a ceiling. For safety reasons, do not install the projector yourself. Installation

entails a separate cost.

Mass

Low ceiling mount ELPMB25 13.5 kg

High ceiling mount ELPMB26 14.7 kg

Values are just reference.

f Dimensions

[Units: mm]

466

160.5137.8

60.5

740.5

551.2

236

231.7 23.3

197.2

345.5 135.2

151.1

395

398

M6×15

53.8

534

456 39

170

102.9

60.5

267

39.7 39.7

Autres manuels pour EB-Z10005U

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Epson Projecteur

Epson

Epson PowerLite 600p Manuel utilisateur

Epson

Epson 821p - PowerLite XGA LCD Projector Manuel utilisateur

Epson

Epson PowerLite 503c Manuel utilisateur

Epson

Epson PowerLite TW-100 Manuel d'installation et d'exploitation

Epson

Epson EB-2247U Manuel utilisateur

Epson

Epson PowerLite 5500c Manuel utilisateur

Epson

Epson EB-G6970WU Manuel utilisateur

Epson

Epson EH-TW750 Manuel utilisateur

Epson

Epson 7850p - PowerLite XGA LCD Projector Dimensions

Epson

Epson EMP-73 Manuel utilisateur

Epson

Epson PowerLite Pro G6050W Manuel utilisateur

Epson

Epson 730c - PowerLite Projector Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 7100 Manuel utilisateur

Epson

Epson PowerLite 7300 Manuel utilisateur

Epson

Epson BrightLink 695Wi Manuel utilisateur

Epson

Epson BrightLink 710Ui Manuel utilisateur

Epson

Epson PowerLite 61p Manuel utilisateur

Epson

Epson EB-PU2010B Manuel utilisateur

Epson

Epson Elmo HV-110XG Dimensions

Epson

Epson PowerLite 4100 Manuel du système

Epson

Epson V11H381020 Manuel utilisateur

Epson

Epson AP-60 - Projector Sound Solution Manuel utilisateur

Epson

Epson Pro L25000U Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 7100 Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur

BOXLIGHT

BOXLIGHT CP-322i/CP-634i Manuel utilisateur

JVC

JVC 1108TTH-AO-AO Manuel utilisateur
