Installation Guide

Using the Product Safely

Safety Instructions

For your safety, read all the instructionsin this guide before using this product. Incorrect handling that ignores

instructions in this guide could damage this product or could result in personal injury or property damage.

Keep this installation guide at hand for future reference.

Read the User'sGuide and SafetyInstructions for your projector and follow the instructions in these documents.

Safety indications

The documentation and this product use graphical symbols to show how to use this product safely.

The indications and their meaning are as follows. Make sure you understand them properly before reading

the guide.

Symbol Explanation

Warning This symbol indicates information that, if ignored, could possibly result in personal injury or

even death due to incorrect handling.

Caution This symbol indicates information that, if ignored, could possibly result in personal injury or

physical damage due to incorrect handling.

Explanation of Symbols

Symbols Explanation

Symbol indicating an action that must not be done

Symbol indicating an action that should be done

Symbol indicating related or useful information

Safety Precautions for Installation

Warning

The setting plate is exclusively for mounting the projector on a wall. If anything other than

a projector is mounted, the weight may result in damage.

If this product falls, it could cause death or personal injury.

The installation work (wall mounting) should be performed by specialists who have tech-

nical knowledge and ability. Incomplete or incorrect installation could cause the product

to fall and cause personal injury or property damage.

Follow the instructions in this guide when installing this product.

If the instructions are not followed, this product may fall, resulting in personal injury or an accident.

Using the Product Safely

Warning

Handle the power cord carefully.

Incorrect handling may cause fire or electric shock. Observe the following precautions when han-

dling:

•

Do not handle the power plug with wet hands.

•

Do not use a power cord that is damaged or modified.

•

Do not pull the power cord with too much force when routing the cable through the setting plate.

Do not install the setting plate in a place where it might be subjected to vibration or shock.

This could cause damage to the projector or mounting surface. If this product falls, it could cause

death or personal injury.

Install the setting plate so that it can sufficiently support the mass of the projector and

setting plate, and resist any horizontal vibration. Use M10 nuts and bolts.

Nuts and bolts smaller than M10 could cause the setting plate to fall. Epson acceptsno responsibility

for any damage or injury caused by lack of wall strength or inadequate installation.

The installation work should be performed by at least two qualified service personnel. If

you need to loosen any screws during installation, be careful not to drop this product.

If this product falls, it could cause death or personal injury.

When mounting this product on a wall, the wall requires enough strength to hold the

projector, the setting plate, and the Touch Unit.

This product should be installed on a concrete wall. The maximum combined weight of the pro-

jector, setting plate, and Touch Unit is approximately 14.5 kg (not including cables). Ensure the

strength of the wall before mounting this product on the wall. If the wall is not strong enough,

reinforce the wall before installation.

Inspect the setting plate on a regular basis to ensure there are no broken parts or loose

screws.

If any parts are damaged, stop using the setting plate immediately. If this product falls, it could

cause death or personal injury.

Do not disassemble or remodel this product.

There are numerous high-voltage sections inside the product that could cause a fire, electric shock,

or an accident.

Do not hang on this product or hang a heavy object on this product.

If this product falls, it could cause death or personal injury.

Do not use adhesives, lubricants, or oils to install or adjust the setting plate.

If you use adhesives to prevent the screws from loosening or things such as lubricants or oils on

the slide plate fixing part of the projector, the case may crack and cause the projector to fall,

resulting in personal injury or property damage.

Tighten all screws firmly after adjustment.

Otherwise, the product may fall and cause personal injury or property damage.

Never loosen the bolts and nuts after installation.

Confirm that the screws have not become loose on a regular basis. If you find any loose screws,

tighten them firmly. Otherwise, the product may falland cause personal injury or property damage.

Route the cables so that they do not interfere with the nuts and bolts.

Incorrect handling of the cables may cause fire or electric shock.

Using the Product Safely

Warning

When turning on the projector, do not look into the projection window.

This could cause damage to eyesight due to the powerful light emitted. Take particular care when

there are children present. When turning on the projector at a distance using the remote control,

make sure there is no one looking into the projection window.

When using the projector, do not place any objects or put your hand near the projection

window.

This area is dangerous as it reaches a high temperature due to the concentrated projection light.

Do not cover the projector's air intake vent or air exhaust vent. If either of the vents are

covered, the internal temperature could rise and cause a fire.

Avoid locations subject to high temperatures, such as close to heaters, and leave a gap of at least

20 cm between the wall and the air exhaust vent.

Do not use the projector in a location subject to combustible or explosive gas.

The projector may catch fire because of the high temperature of the lamp inside the projector.

If any abnormalities occur with this product, immediately disconnect the cables from the

product, and then contact your local dealer or the nearest Epson service call center.

Continuing to use the product in an abnormal condition could cause a fire, electric shock, or visual

impairment.

Caution

Do not install this product in a location where the operating temperature for your projector

model may be exceeded.

Such an environment may damage the projector.

Install this product in a place free from excessive dust and humidity to prevent the lens or

optical components from becoming dirty.

Do not use excessive force when adjusting this product.

This product may break, resulting in personal injury.

Notes on handling the Touch Unit

Warning

Do not disassemble or remodel the Touch Unit.

The Touch Unit contains a high power laser product that could cause a fire, electric shock, or an

accident.

Follow the instructions in this guide to setup and operate the Touch Unit.

If the Touch Unit is not setup and operated correctly, it could cause damage to eyesight due to

light from the laser.

Do not apply optical devices such as a magnifying glass or telescope to the laser light

diffused from the Touch Unit.

Using it in this condition could have a negative influence on the human body. It could also cause

a fire or accident.

Using the Product Safely

Warning

Do not look into the Touch Unit's laser diffusion ports.

This could cause damage to eyesight due to the powerful laser light emitted. Take particular care

when there are children present.

Do not view the laser light using optical devices such as a magnifying glass within a range

of 70 mm from the laser diffusion ports.

This could cause visual impairment.

Only connect the Touch Unit to the EB-595Wi. Do not connect it to any other projectors or

devices.

The device could malfunction, or laser light could leak beyond its restricted area.

Do not go near the Touch Unit if you are using medical equipment such as a pace maker.

Furthermore, when using the Touch Unit, make sure there is no one using medical equip-

ment such as a pace maker, in the surrounding area.

A powerful magnet within the unit generates electromagnetic interference which may cause med-

ical equipment to malfunction.

Caution

Do not go near the Touch Unit with magnetic storage media such as magnetic cards, or

precision electronic devices such as computers, digital watches, or mobile phones.

A powerful magnet within the unit could corrupt data or cause a malfunction.

About This Installation Guide

This guide describes how to mount the short-throw projector EB-595Wi on a wall. It also explains how to

install the Touch Unit after mounting on a wall.

Using the Product Safely

Choosing an Installation Location

Projector installation location

•Carry out power supply wiring work for the installation location of the setting plate in advance.

•Install the projector away from other electric devices such as fluorescent lights or air conditioners. Some kinds of

fluorescent lights could interfere with the remote control of the projector.

•It is recommended to keep connection cable length less than 20 meters to reduce external noise.

•We recommend using stick-on screens or board screens.

•Make sure the projector is installed under the following conditions.

•The projected image is a rectangular shape without any distortion.

•The projector is tilted at an angle of no more than ±3° vertically and horizontally in relation to the screen.

•When using the interactive function (Easy Interactive Function), install so that the projected image is within reach.

•Do not install the projector or the screen in a location subject to direct sunlight. If the projector or the screen are

subject to direct sunlight, the interactive function may not operate correctly.

Touch Unit installation location

•When using the Touch Unit, install the projector using one of the following methods. The Touch Unit cannot be used

if another installation method is used.

•Mount the projector on a wall or suspend it from a ceiling and project images from in front of the screen.

•Install vertically on a table and project from the front of the desk. (When installing vertically on a table, you need

the optional Interactive Table Mount (ELPMB29).)

•Before installing the Touch Unit, make sure that the installation location meets the following conditions.

•The Touch Unit can be secured with magnets or with screws.

•A flat, smooth, unwarped surface with no unevenness on the screen surface of more than 5 mm.

•When installing on a whiteboard, install the Touch Unit within the frame of the whiteboard.

Using the Product Safely

Correct installation position Incorrect installation position

•When installing the Touch Unit, make sure there are no obstacles, such as cables, or protruding items such as

whiteboard trays, holders, or thick frames in the shaded areas in the following figure. The Touch Unit will not operate

correctly.

[Unit: mm]

Contents

Using the Product Safely

SafetyInstructions .................... 1

Safetyindications .......................1

ExplanationofSymbols ................... 1

SafetyPrecautionsforInstallation ............ 1

NotesonhandlingtheTouchUnit ............ 3

AboutThisInstallationGuide ............... 4

ChoosinganInstallationLocation ...... 5

Projectorinstallationlocation ............... 5

TouchUnitinstallationlocation.............5

Installation Guide

InstallationWorkFlow ................ 8

Package Contents . . ................... 9

Settingplate ........................... 9

TouchUnit ........................... 10

Specifications ....................... 11

Settingplate .......................... 11

Wallplate .......................... 11

Verticalslideadjustmentrange ........... 12

Horizontalslideadjustmentrange ......... 12

Forward/backward slide adjustment range . . 12

TouchUnit ........................... 13

Touch Unit (external dimensions/weight) . . . 13

Attachedlabels ...................... 13

Laserdiffusionport ................... 14

ProjectionDistanceTable ............ 15

FiguresofInstallationDimensions ........... 15

When Projected Image is Smaller than 75 Inches 16

16:10projectedimage ................. 16

16:9projectedimage .................. 17

4:3projectedimage ................... 18

When Projected Image is Larger than 75 Inches . 19

16:10projectedimage ................. 19

16:9projectedimage .................. 20

4:3projectedimage ................... 21

InstallingtheSettingPlate ........... 23

ConnectingDevices ..................... 23

Necessarycables ..................... 23

InstallationProcedure ................... 24

Disassembletheparts................. 25

Assembletheparts...................25

Installthewallplateonthewall..........26

Determine the projection distance, and then

pass the cables through the setting plate . . . . 28

Attaching the setting plate to the wall plate . . 30

Securing the projector to the setting plate . . . 32

AdjustingtheProjectedImage .............34

AdjustingtheProjectionPosition.........34

Fine-tuningtheFocus .................39

Calibratingthepen ................... 41

AttachingtheCovers .................... 45

InstallingtheTouchUnit ............. 47

InstallationProcedure ................... 47

AngleAdjustment ...................... 51

TouchCalibration ......................62

Appendix

BatchSetupFunction ................ 66

SetupUsingaUSBflashdrive .............. 66

SavingsettingstotheUSBflashdrive......66

Reflecting saved settings to other projectors . 67

Setup by Connecting the Computer and

ProjectorwithaUSBCable ................ 68

Savingsettingstoacomputer ............ 69

Reflecting saved settings to other projectors . 69

WhenSetupFails ....................... 71

Using the Interactive Function when

Multiple Projectors are Installed . . . . . . 72

AttachingaSecurityCable ............ 73

GeneralNotice ...................... 74

Installation Guide

Installation Work Flow

Follow the procedures below to mount the projector on a wall.

Installing the Setting Plate and the Projector (sp.23)

Adjusting the Projected Image (sp.34)

Calibrating the Interactive Pen (sp.41)

When installing the Touch Unit, finish installing the projector first, and then follow the procedures below.

Installing the Touch Unit (sp.47)

Adjusting the Angle of Laser Diffusion (sp.51)

Performing Touch Calibration (sp.62)

Installation Guide

Package Contents

Setting plate

The following supplied items are necessary to mount the projector on a wall. Confirm that you have all items

before beginning.

Setting plate Hexagonal axis Wall plate

Wall plate cover 3-axis adjustment unit

*The slide plate ( ) is secured dur-

ing shipping.

Template sheet

(for installing the wall plate)

End cap Hexagon wrench (for M4) Open-ended spanner

13 mm (for M8 and M6),

6 mm (for hexagonal axis)

Shape Name

Quan-

tity

Application

M4 x 12 mm hexagon socket head cap bolt

with washer/spring washer

6Forwallplateassembly

4 For 3-axis adjustment unit/arm installation

4 For slide plate/projector installation

2 For slide plate/3-axis adjustment unit installa-

tion (attached during shipping)

M6 x 20 mm hexagon shoulder head bolt

with washer/spring washer

1 For setting plate/wall plate installation

M6 x 20 mm cross recessed head shoulder

screws with plastic washers

•Use the bolts or screws supplied with this product to install it as directed in this guide. Do not substitute these bolts

with any other types.

•You need to use commercially available M10 x 60 mm anchors (at least 3) to attach the wall plate to the wall.

•Gather the tools and parts you need before you begin installation.

Autres manuels pour EB-595Wi

Table des matières

Autres manuels Epson Projecteur

Epson

Epson EMP-TS10 Manuel utilisateur

Epson

Epson PowerLite Pro Z8000WU Instructions générales

Epson

Epson UB-E500 Manuel utilisateur

Epson

Epson AP-60 - Projector Sound Solution Manuel utilisateur

Epson

Epson VS410 Guide de référence

Epson

Epson PowerLite 107 Manuel utilisateur

Epson

Epson EMP-52 Manuel utilisateur

Epson

Epson EMP-8300 Manuel utilisateur

Epson

Epson 1925W - POWERLITE Multimedia Projector Manuel utilisateur

Epson

Epson 740c - PowerLite XGA LCD Projector Manuel utilisateur

Epson

Epson PowerLite 1825 Manuel utilisateur

Epson

Epson PowerLite 4650 Manuel d'instructions et de sécurité

Epson

Epson Stylus Pro 9900 Instructions d'installation et d'entretien

Epson

Epson EB-W7 Manuel utilisateur

Epson

Epson EB-585W Manuel utilisateur

Epson

Epson PowerLite Home Cinema 725HD Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite 735c Manuel utilisateur

Epson

Epson dreamio EMP-TW200H Manuel utilisateur

Epson

Epson BrightLink 425Wi Manuel utilisateur

Epson

Epson ELPDC05 - High Resolution Document Imager... Guide de référence

Epson

Epson PowerLite Home Cinema 3020e Manuel d'exploitation et d'entretien

Epson

Epson MovieMate 30s Manuel utilisateur

Epson

Epson 1925W - POWERLITE Multimedia Projector Mode d’emploi

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur

BOXLIGHT

BOXLIGHT CP-322i/CP-634i Manuel utilisateur

JVC

JVC 1108TTH-AO-AO Manuel utilisateur
