Start Here

This card helps you get started using your new

BrightLink.

1. First use this easy 5-step document.

2. Then pop in the DVD and learn more.

3. Next, visit us at the BrightLink Educator

Resource Center.

4. Need more help? Additional resources are shown

on the right.

Need More Help?

BrightLink software, manuals, FAQs, and

more are available at epson.com/support/

brightlinkdownloads (U.S.) or epson.ca/support/

brightlinkdownloads (Canada).

DVD containing BrightLink

training videos in this

Welcome Toolkit.

TeamBoard Draw Tips sheet in

this Welcome Toolkit.

BrightLink Quick Guide.A

complete User’s Guide is also

available on the BrightLink CD or

at the BrightLink websites listed

above.

PrivateLine®technical support

card, with your individual PIN.

Ask your tech coordinator or call

(562) 276-4394 (U.S.) or (905)

709-3839 (Canada).

BrightLink Educator Resource Center

• Sign up for compimentary webinars

• Watch helpful how-to videos

• Find out about cool free interactive sites

• Book on-site Professional Development courses:

Go to www.epson.com/brightlink (U.S.) or

www.epson.ca/brightlink (Canada)

then click the Educator Resource Center tab.

TECHNICAL SUPPORT

PrivateLine

1•800•637•7661

You need Easy Interactive Driver (EID) to make the pen work with

your projected computer image.

Here’s how to ﬁnd out if Easy Interactive Driver is already

installed on your computer:

If you are using Windows®:

Select or Start > All Programs or Programs > Epson

Projector > Easy Interactive Driver. If you see Easy Interactive

Driver, the software is installed.

If you are using Mac OS® X:

Look for the Easy Interactive Driver folder in the Applications

folder on your hard drive. If you see the Easy Interactive Driver

folder, the software is installed.

If Easy Interactive Driver is not installed, follow the steps in the

next column to install it.

If you need to install Easy Interactive Driver

Do one of the following:

•Use the CD that came with the projector,

labeled “Epson Projector Software for Easy

Interactive Function”

•Download the most up-to-date version from:

epson.com/support/brightlinkdownloads

(U.S.)

epson.ca/support/brightlinkdownloads

(Canada)

You will need Internet access.

For detailed installation instructions, see the

Quick Guide that came with the projector or

watch the video on your DVD.

1 Make Sure the Software Is Installed

2Turn on the projector by pressing the power

button on the remote control. You can use other

buttons on the remote to adjust the image.

Select from various

image sources

connected to the

projector

Stop video action

Zoom in and out

Turn projector

on/off

Temporar il y

turn off image

Page through

documents

Access menu

system for

additional

adjustments

Tip: Want to learn more about using your remote

control? Visit us online at Epson’s Educator

Resource Center for a whole set of short videos.

3Display an image from your computer. If the

image doesn’t appear, try one of the following:

•On some PC laptops, you may need to hold

down the Fn key on the keyboard and press

F7 or the function key that lets you display on

an external monitor. It may have an icon such

as , or it may be labelled CRT/LCD.

•On a Mac®, you may need to open your

Display Preferences and select Detect

Displays, Show displays in menu bar, or

Mirror Displays.

•Try pressing the Source Search button on

the remote control.

2 Connect Your Computer to the Projector

1Connect the VGA computer cable and USB

cable to your PC or Macintosh®.

VGA cable

USB cable

Using the Pens

Make sure the batteries are installed in the

interactive pens. Your BrightLink came with

rechargeable batteries and a charger.

•Press the button on the pen. If the light turns

green, the batteries are installed and charged.

Battery indicator light

Button

•Hold the pen at an angle, rather than

perpendicular to the board.

•To left-click, tap on the board.

•To double-click, tap twice.

•To right-click, press and hold the button on the

pen, then tap the board.

•To click and drag, tap and drag with the pen.

If you use the pens for several hours every day,

you may have to recharge the batteries once a

week. If you use them less often, you may only

have to recharge once a month.

Tip: You can only write with one pen at a time,

but you can use both pens and trade off. To learn

more about EID and the BrightLink pen, watch the

videos we made just for you on the included DVD.

3 Launch Easy Interactive Driver

1 Look for the pen icon in lower right corner of your

screen (Windows) or in the Dock (Mac OS).

•If you don’t see the icon in Windows, you may need

to click the arrow(s) to show hidden icons.

Click if necessary

•If a red X appears on the icon , the computer

and projector may not be connected correctly. Make

sure the projector is powered on and the USB cable

is connected to your computer.

2 If you don’t see the icon, make sure you have the

program on your computer. Do one of the following to

check:

•Windows: select or Start > All Programs or

Programs > Epson Projector > Easy Interactive

Driver.

•Mac OS X: open the Applications folder, then open

the Easy Interactive Driver folder and select the

Easy Interactive Driver icon.

3Wait a few moments for the ﬂashing green circle

to appear. Use the interactive pen to touch each

ﬂashing green circle as it appears. Continue until

all the circles stop ﬂashing and turn black.

•Touch the center of each circle, and make

sure you are not casting a shadow on the

pen.

•If you make a mistake, or if too many circles

appear at the same time, press Esc on your

computer keyboard and restart calibration.

Tip: You only need to recalibrate if you change

computers, or if you notice that the pen position

is no longer the same as your cursor.

4 Calibrate Your System

Calibration coordinates the positioning of the pen with

the location of your cursor. You can use either pen, and

you only have to calibrate once.

1Do one of the following:

•Windows: click the pen icon in the system

tray on your taskbar (lower right corner of

your screen), then select Calibrate (Normal).

•Mac OS X: click the pen icon in the Dock,

select Calibration from the menu bar at

the top of the screen, then select Calibrate

(Normal).

Note: If the pen icon appears with a red X ,

you won’t be able to calibrate. Make sure the

projector is powered on and the USB cable is

connected to your computer.

2After you read the following message, click OK.

Note: Advanced calibration is recommended

only if you are projecting highly detailed images.

Congratulations! When you ﬁnish calibration, you’re

ready to explore your software options, as described

on the next page.

If you are using Windows 7 or Windows Vista®,

you can also take advantage of the Tablet PC and

Ink tools to add handwritten input.

To open the Tablet PC input panel, select >

All Programs > Accessories > Tablet PC >

Tablet PC Input Panel.

If you have Microsoft®Ofﬁce 2003 or later, you

can use the Ink function to add handwritten notes

to a Word document, Excel®spreadsheet, or

PowerPoint®presentation.

To add ink annotations in Microsoft Ofﬁce

applications, select the Review menu, then select

Start Inking.

You can select from a variety of Ink Tools:

In Windows XP, you can annotate your

PowerPoint slides without additional software. In

slideshow mode, right-click and select Pointer

Options > Pen.

For more information, see your Windows Help.

Easy Interactive Driver allows you to use the BrightLink pen as a

mouse. For writing, you need annotation software. If you already

have annotation software, you can use it with BrightLink.

You can also use one of the following:

•Easy Interactive Tools (EIT), free from Epson, is a basic

annotation program available for download from the Epson

website. Go to epson.com/support/brightlinkdownloads

(U.S.) or epson.ca/support/brightlinkdownloads (Canada)

Windows Mac OS X

•TeamBoard Draw, a more intermediate level annotation

program, is sold with your projector. You can install it

from the CD that came with your BrightLink projector,

or download it from the Epson website at epson.com/

support/brightlinkdownloads (U.S.) or epson.ca/support/

brightlinkdownloads (Canada). You will need Internet

access and your projector serial number.

For more information, see the TeamBoard Draw Tips sheet or the

TeamBoard training videos on the Epson website.

Epson is a registered trademark and Epson Exceed Your Vision is a registered logomark of

Seiko Epson Corporation.

BrightLink and PrivateLine are registered trademarks of Epson America, Inc.

General Notice: Other product names used herein are for identiﬁcation purposes only and may

be trademarks of their respective owners. Epson disclaims any and all rights in those marks.

This information is subject to change without notice.

Printed in USA

5 Explore Your Software Options
