Epson S5U12517P00C100 Manuel utilisateur

SEIKO EPSON CORPORATION

Rev. 1.0

S1D13517 Display Controller

S5U13517P00C100

Evaluation Board User

Manual

NOTICE

No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko

Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any lia-

bility of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or cir-

cuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as,

medical products. Moreover, no license to any intellectual property rights is granted by implication or otherwise, and there is

no representation or warranty that anything made in accordance with this material will be free from any patent or copyright

infringement of a third party. This material or portions thereof may contain technology or the subject relating to strategic

products under the control of the Foreign Exchange and Foreign Trade Law of Japan and may require an export license from

the Ministry of International Trade and Industry or other approval from another government agency.

All other product names mentioned herein are trademarks and/or registered trademarks of their respective companies.

S1D13517 Display Controller

S5U13517P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 3

Table of Contents

Chapter 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Chapter 2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Chapter 3 Installation and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.1 Configuration DIP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . .7

3.2 Configuration Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Chapter 4 Technical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4.1 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4.1.1 Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4.1.2 Voltage Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4.1.3 S1D13517 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4.2 Clocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.3 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.4 Host Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.4.1 Direct Host Bus Interface Support . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.4.2 Connecting to the Epson S5U13U00P00C100 USB Adapter Board . . . . . . . . . 14

4.5 LCD Panel Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4.6 GPO and PWM Connections . . . . . . . . . . . . . . . . . . . . . . . . 16

Chapter 5 Parts Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Chapter 6 Schematic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Chapter 7 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Chapter 8 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

8.1 Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

8.2 Document Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

S1D13517 Display Controller

4 EPSON S5U13517P00C100 Evaluation Board User Manual (Rev. 1.0)

S1D13517 Display Controller

S5U13517P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 5

Chapter 1 Introduction

This manual describes the setup and operation of the S5U13517P00C100 Evaluation Board. The evaluation board

is designed as an evaluation platform for the S1D13517

Display Controller.

The S5U13517P00C100 evaluation board can be used with many native platforms via the host connector which

provides the appropriate signals to support a variety of CPUs. The S5U13517P00C100 evaluation board can also

connect to the S5U13U00P00C100 USB Adapter board so that it can be used with a laptop or desktop computer, via

USB 2.0.

This user manual is updated as appropriate. Please check the Epson Research and Development Website at

www.erd.epson.com for the latest revision of this document before beginning any development.

We appreciate your comments on ourdocumentation. Please contact us via email at documentation@erd.epson.com.

S1D13517 Display Controller

6 EPSON S5U13517P00C100 Evaluation Board User Manual (Rev. 1.0)

Chapter 2 Features

The S5U13517P00C100 Evaluation Board includes the following features:

• S1D13517 Display Controller (128-pin QFP)

• Integrated Silicon Solution, Inc. IS42S16800E-7TLI 128M-bit SDRAM (54-pin TSOP)

• Header with all S1D13517 Host Bus Interface signals

• Headers for connection to the S5U13U00P00C100 USB Adapter board

• Headers for connecting to LCD panels

• Header for S1D13517 GPO pins and PWM pin

• On-board 24MHz oscillator

• 14-pin DIP socket (if a clock other than 24MHz must be used)

• 3.3V input power

• On-board voltage regulator with 2.5V output

• On-board voltage regulator with adjustable 6~24V output, 40mA max., to provide power for LED backlight of

LCD panels.

S1D13517 Display Controller

S5U13517P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 7

Chapter 3 Installation and Configuration

The S5U13517P00C100 evaluation board incorporates aDIP switch, jumpers, and 0 ohm resistors which allow it to

be used with a variety of different configurations.

3.1 Configuration DIP Switch

The S1D13517 has 2 configuration inputs (CNF[1:0]). A DIP switch (SW1) is used to configure CNF[1:0] as

described below.

The following figure shows the location of DIP switch SW1 on the S5U13517P00C100 board.

Figure 3-1: Configuration DIP Switch (SW1) Location

Table 3-1: Summary of Power-On/Reset Options

SDU13517P00C100

SW1-[2:1] Config S1D13517

CNF[1:0] Config Power-On/Reset State

1 (ON) 0 (OFF)

SW1-[1] CNF0 Host data bus is 8-bit Host data bus is 16-bit

SW1-[2] CNF1 Host interface is ALE bus Host interface is i80 bus

= Required settings when using S5U13U00P00C100 USB Adapter board

DIP Switch

SW1

S1D13517 Display Controller

8 EPSON S5U13517P00C100 Evaluation Board User Manual (Rev. 1.0)

3.2 Configuration Jumpers

The S5U13517P00C100 has 6 jumpers which configure various board settings. The jumper positions for each

function are shown below.

J1, J2, J3 - Power Supplies for the S1D13517

J1, J2, J3 can be used to measure the current consumption of each S1D13517 power supply.

When the jumper is at position 1-2, normal operation is selected.

When no jumper is installed, the current consumption for each power supply can be measured by connecting an

ammeter between pins 1 and 2 of the jumper.

The jumper associated with each power supply is as follows:

J1 for COREVDD

J2 for IOVDD

J3 for PLLVDD

Figure 3-2: Configuration Jumper Locations (J1, J2, J3)

Jumper Function Position 1-2 Position 2-3 No Jumper

J1 COREVDD Normal —COREVDD current

measurement

J2 IOVDD Normal —IOVDD current

measurement

J3 PLLVDD Normal —PLLVDD current

measurement

J4 IOVDD source 3.3V CN1 connector, pin 32 —

J5 24MHz control

24MHz

stop —Normal

= Required settings when using S5U13U00P00C100 USB Adapter board

Jumper Function Position 1-2 Position 3-4 Position 5-6

J6 Clock source On board 24MHz

Second oscillator

CLKI pin to GND

J2, J1

S1D13517 Display Controller

S5U13517P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 9

J4 - IOVDD Source

J4 is used to select the source for the IOVDD supply voltage.

When the jumper is at position 1-2, the IOVDD voltage is provided by the 3.3V power supply of the board.

When the jumper is at position 2-3, the IOVDD voltage must be provided to the CN1 connector, pin 32.

J5 - 24MHz Control

J5 is used to control the 24MHz oscillator.

When no jumper is installed, the 24MHz oscillator is running.

When the jumper is at position 1-2, the 24MHz oscillator is stopped.

J6 - Clock Source

J6 is used to select the source for the clock input.

When the jumper is at position 1-2, the on board 24MHz oscillator is selected.

When the jumper is at position 3-4, the second oscillator is selected.

When the jumper is at position 5-6, the CLKI pin is forced to GND.

Figure 3-3: Configuration Jumper Location (J4, J5, J6)

J4 J5

S1D13517 Display Controller

10 EPSON S5U13517P00C100 Evaluation Board User Manual (Rev. 1.0)

Chapter 4 Technical Description

4.1 Power

4.1.1 Power Requirements

The S5U13517P00C100 evaluation board requires an external regulated power supply (3.3V / 0.5A). The power is

supplied to the evaluation board through pin 34 of the CN1 header, or pin 5 of the P2 header.

The green LED ‘3.3V Power’ is turned on when 3.3V power is applied to the board.

4.1.2 Voltage Regulators

The S5U13517P00C100 evaluation board has an on-board linear regulator to provide the 2.5V power required by

the S1D13517 Display Controller. It also has a step-up switching voltage regulator to generate adjustable 6~24V,

which can be used to power the LED backlight on some LCD panels.

4.1.3 S1D13517 Power

The S1D13517 Display Controller requires 2.5V and 3.0~3.6V power supplies.

2.5V power for COREVDD and PLLVDD is provided by an on-board linear voltage regulator.

IOVDD can be in the range of 3.0~3.6V. When J4 is set to the 1-2 position, IOVDD is connected to 3.3V. If a

different voltage is required for IOVDD, set JP4 to the 2-3 position and connect the external power supply to pin 32

of connector CN1.
