EPOX SiS 661FX Manuel utilisateur
TRADEMARK
All products and company names are trademarks or registered
trademarks of their respective holders.
These specifications are subject to change without notice.
Manual Revision 1.0
April 05, 2004
User’User’
User’User’
User’ss
ss
s
ManualManual
ManualManual
Manual
60000024SGM10
SiSSiS
SiSSiS
SiS 661FX661FX
661FX661FX
661FX mainboardmainboard
mainboardmainboard
mainboard
for Intel Socket 478 processorfor Intel Socket 478 processor
for Intel Socket 478 processorfor Intel Socket 478 processor
for Intel Socket 478 processor
ii
DISCLAIMER OF WARRANTIES:
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE
DESCRIPTION ON THE FACE OF THE MANUFACTURER LIMITED
WARRANTY. THE MANUFACTURER EXPRESSLY EXCLUDES ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING ITS
PRODUCTS; INCLUDING ANY IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR
NONINFRINGEMENT. THIS DISCLAIMER OF WARRANTIES SHALL
APPLY TO THE EXTENT ALLOWED UNDER LOCAL LAWS IN THE
COUNTRY PURCHASED IN WHICH LOCAL LAWS DO NOT ALLOW
OR LIMIT THE EXCLUSION OF THE IMPLIED WARRANTIES.
iii
Table of Contents
Section 1 Introduction
Package Contents ...................................................... 1-1
Intel Pentium 4 Processors......................................... 1-2
Ultra ATA66/100/133 .................................................. 1-2
Hardware Monitoring ................................................. 1-2
LAN ............................................................................ 1-2
I/O Shield Connector.................................................. 1-3
Power-On/Off (Remote) .............................................. 1-3
System Block Diagram ............................................... 1-4
Section 2 Features
Mainboard Features ................................................... 2-1
Section 3 Installation
Mainboard Layout ..................................................... 3-2
Easy Installation Procedure
CPU Installation ......................................................... 3-3
Jumper Settings .......................................................... 3-5
System Memory Configuration .................................. 3-6
Expansion slots .......................................................... 3-8
Device Connectors..................................................... 3-10
External Modem Ring-in Power ON and
Keyboard Power ON Function (KBPO) ..................... 3-15
ACPI S3 (Suspend To RAM) Function .................... 3-16
Section 4 BIOS Setup
Main Menu ................................................................ 4-1
Standard CMOS Setup ............................................... 4-2
Page
iv
Advanced BIOS Features .......................................... 4- 3
Advanced Chipset Features ...................................... 4- 6
Integrated Peripherals ................................................ 4- 9
Power Management Setup ......................................... 4-14
PNP/PCI Configuration Setup .................................... 4-18
PC Health Status ........................................................ 4-20
Power BIOS Features ................................................. 4-21
Defaults Menu ........................................................... 4-23
Supervisor/User Password Setting ............................ 4-24
Exit Selecting .............................................................. 4-25
Section 5 Driver Installation
Easy Driver Installation .............................................. 5- 1
Realtek Sound Manager Quick User guide ................ 5- 2
Appendix Appendix A
Realtek Media Player User’s Guide ............................ A- 1
Appendix B
Update Your System BIOS ......................................... B- 1
Appendix C
EEPROM BIOS Remover ........................................... C-1
Appendix D
GHOST 7 Quick User’s Guide (Optional) ................... D- 1
Introduction
Page 1-1
Section 1
INTRODUCTION
Package Contents
A
B
USER’S
MANUAL
G
F
C
D
E
Contents
A. Mainboard
B. User’s manual
C. Floppy disk drive cable
D. HDD drive cable
E. CD (drivers and utilities)
F. I/O Shield
Optional Items
G. COM port cable
H. Extra USB2.0 port cable
I. S/PDIF Module
If you need the optional item, please
contact your dealer for assistance.
HI
Introduction
Page 1-2
Intel®Pentium®4 processors
The Pentium 4 processor is designed to deliver performance across applications and
usages where end-users can truly appreciate and experience the performance. These
applications include Internet audio and streaming video, image processing, video
content creation, speech, 3D, CAD, games, multimedia, and multi-tasking user
environments. The Pentium 4 processor delivers this world-class performance for
consumer enthusiasts and business professional desktop PC users as well as for
entry-level workstation users.
Intel adds support for Hyper-Threading Technology to the Pentium 4 processor
family. HT Technology allows a single, physical Pentium 4 processor to function as
two logical processor for next generation multi threaded application.
For more information about all the new features the Pentium 4 delivers check
out the Intel website at http://www.intel.com
Accelerated Graphics Port (AGP)
The AGP slot on the board is compliant with the new AGP 3.0 specification. This
new specification enhances the functionality of the original AGP specification by
allowing 8X data transfers ( 8 data samples per clock) resulting in maximum band-
width of 2.1GB/s. Only 1.5V AGP cards are supported.
Ultra ATA/66/100/133
The board provides two independent ATA133 IDE controllers, supporting standard
programmable input/output (PIO) and Direct Memory Access (DMA) mode
operations, as well as UltraDMA-133/100/66/33 standards for a maximum data
transfer rate of 133MB/sec per channel.
Hardware Monitoring
Hardware monitoring enables you to monitor various aspects of the system operation
and status. The features include CPU temperature, voltage and fan speed in RPMs.
LAN
This mainboard is optionally mounted with LAN chipset. It allows the mainboard to
connect to a local area network by means of a network hub.
Introduction
Page 1-3
I/O Shield Connector
The I/O back panel for this mainboard is shown below (Figure 1). When installing
the mainboard into the computer case, use the bundled I/O shield to protect this
back panel.
Power-On/Off (Remote)
This board has a 20-pin ATX and a 4-pin ATX12V power supply connector to support
power supplies with Remote On/Off feature. The chassis power button should be
connected to the mainboard front panel PW_ON header (Figure 2).
You can turn off the system in two ways: by pressing the front panel power On/Off
button or using the "Soft Off" function that can be controlled by an operating
system such as Windows®XP/ME/2000/98.
Note: For maintaining the DDR SDRAM power during STR (ACPI S3) function, it is strongly
recommended to use power supplies that have a +5VSB current of (>=) 2A. Please check the
5VSB’s specification printed on the power supply’s outer case.
Note: The board requires a minimum of 250 Watt power supply to operate. Your system configura-
tion (amount of memory, add-in cards, peripherals, etc.) may exceed this minimum power
requirement. To ensure that adequate power, use a 300 Watt (or higher) power supply.
Figure 1: I/O back panel layout
PW-ON
Case (chassis) Power ON/OFF button (PW-ON)
Figure 2: Simple ATX power ON/OFF controller
POWER SUPPLY
12V 4-pin
20-pin
COM1
Parallel Port
VGA1
RJ-45 LAN
(Optional)
USB2.0 ports x 4
PS/2
Mouse
PS/2
Keyboard Mic-in/Center&Subwoofer (Pink)
Line-out/Front out (Lime)
Line-in/Rear out (Light blue)
Introduction
Page 1-4
Figure 3: System Block Diagram
System Block Diagram
Features
Page 2-1
Section 2
FEATURES
Mainboard Features
Processor
Socket 478 Intel®Pentium®4 processors up to 3.4+ GHz
Supports Hyper-Threading Technology
To enable the Hyper-Threading Technology function on your computer
system requires ALL of the following platform components:
)CPU: An Intel®Pentium®4 Processor with HT Technology.
)BIOS: A BIOS that supports HT Technology and has it enabled.
)OS: An operating system that supports HT Technology.
Performance will vary depending on the specific hardware and software
you use. See <http://www.intel.com/info/hyperthreading> for information
including details on which processor support HT Technology.
Chipset
SiS 661FX Chipset (661FX + 963L)
- with SiS Mirage Graphics core
Main Memory
Two 184-pin DDR DIMM sockets for PC2100/2700/3200 (DDR266/333/400)
DIMMs
Supports up to 2GB memory size
BIOS
Flash EEPROM with Award BIOS
- ACPI v2.0 compliant
- S3 (Suspend to DRAM) sleep-state support
- SMBIOS (System Management BIOS) v2.2 compliant
- Supports Power failure recovery
- Able to wake the computer from specific states by LAN, Power switch,
PME#, RTC alarm, USB, PS2 K/B, PS2 Mouse, Modem Ring-in COM#1…
Features
Page 2-2
Onboard PCI Devices
LAN --> Integrates 10/100Mps Fast Ethernet controller with onboard
VIA 6103 LAN PHY
Legacy IO Controller
ITE IT8705F LPC IO controller with keyboard, mouse, floppy, printer, game,
serial and IR interface
Audio
Six channel audio with analog and digital output using Realtek ALC655
AC’97CODEC
- AC’97 v2.2 compliant
- In 2-CH mode, supports Line-In (Light Blue), Line-Out (Lime) and Mic-In
(Pink) at rear panel
- In 6-CH mode, supports Rear speaker-out (Light Blue), Front speaker-out
(Lime) and Center&Subwoofer speaker-out (Pink) at rear panel
- Supports CD-In, Aux-In and S/PDIF-in/out interface
- Supports Line-out and Mic-In for front panel
- Supports automatic “jack-sensing”
Peripheral Interfaces
))
))
)At Rear Panel
PS/2 keyboard and mouse ports
One Parallel (printer) port
One Serial port
One VGA port
One RJ45 LAN connector
Four USB2.0 ports
Three Audio jacks
))
))
)Onboard connector and pin-header
One floppy drive connector
Two ATA-133 IDE connectors
