EPOX P2-100B Manuel utilisateur

TRADEMARK

All products and company names are trademarks or

registered trademarks of their respective holders.

These specifications are subject to change without

notice.

Manual Revision 2.0

January 27, 1999

P2-100BP2-100B

P2-100B

A PentiumA Pentium

A Pentium®®

®®

®II or DeschutesII or Deschutes

II or DeschutesII or Deschutes

II or Deschutes

Slot1 Processor based AGPSlot1 Processor based AGP

Slot1 Processor based AGP

mainboard (100/66MHz)mainboard (100/66MHz)

mainboard (100/66MHz)

P2-100B

Technical Support Services

If you need additional information, help during installation or normal use of this

product, please contact your retailer. If your retailer can not help, you may E-Mail us

with any questions at the following address [email protected]

Record your serial number before installing your P2-100B mainboard. (the serial

number is located near the ISA slots at the edge of the board)

P2-100B serial number:

__________________________

BIOS Upgrades

Please use either our Web Site or BBS for current BIOS Upgrades.

Internet Access

http://www.epox.com

http://www.epox.com.tw

[email protected]

Modem Access

31-182-618451 (The Netherlands)

You can access this number via a Hayes-compatible modem with a 2,400 to

28,800 baud rate. The following setup format is required:

8 Data Bits, No Parity, 1 Stop Bit.

If your modem is unable to connect at higher baud rates, try connecting at

2,400 baud before contacting Technical Support.

Thank you for using EPoX mainboards!

P2-100B

User Notice

No part of this product, including the product and software may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language

in any form by any means without the express written permission of EPoX Computer

Company (hereinafter referred to as EPoX) except documentation kept by the

purchaser for backup purposes.

EPoX provides this manual “as is” without warranty of any kind, either express or

implied, including but not limited to the implied warranties or conditions of merchant-

ability or fitness for a particular purpose. In no event shall EPoX be liable for any

loss or profits, loss of business, loss of use or data, interruption of business or for

indirect, special incidental, or consequential damages of any kind, even if EPoX has

been advised of the possibility of such damages arising from any defect or error in

the manual or product. EPoX may review this manual from time to time without

notice. For updated BIOS, drivers, or product release information you may visit

EPoX’s home page at: http://www.epox.com

Products mentioned in this manual are mentioned for identification purposes only.

Product names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies.

The product name and revision number are both printed on the mainboard

itself.

Handling Procedures

Static electricity can severely damage your equipment. Handle the P2-100B

and any other device in your system with care and avoid unneccessary contact with

system components on the mainboard.

Always work on an antistatic surface to avoid possible damage to the motherboard

from static discharge.

We assume no responsibility for any damage to the P2-100B mainboard that results

from failure to follow installation instructions or failure to observe safety precautions.

CAUTION

TheP2-100Bmainboardissubjectto

damagebystaticelectricity. Always

observethehandlingprocedures.

P2-100B

Table of Contents

Section 1 Introduction

ComponentsChecklist .................................... 1-1

Overview

PentiumIIorDeschutesProcessor.................. 1-2

S.E.C.CartridgeTerminology ......................... 1-3

AcceleratedGraphicsPort .............................. 1-4

HardwareMonitoring ..................................... 1-4

I/OShieldConnector...................................... 1-7

Power-On/Off(Remote)................................. 1-6

SystemBlockDiagram ................................... 1-7

Section 2 Features

P2-100B Features .......................................... 2-1

Section 3 Installation

P2-100BDetailedLayout ............................... 3-2

Easy Installation Procedure

ConfigureJumpers .......................................... 3-3

SystemMemoryConfiguration ........................ 3-5

InstallingaPentium®IIProcessor .................... 3-7

DeviceConnectors ......................................... 3-8

Section 4 Award BIOS Setup

BIOSInstructions ........................................... 4-1

Standard CMOS Setup .................................. 4-2

BIOS Features Setup ..................................... 4-3

ChipsetFeaturesSetup ................................... 4-8

PowerManagementSetup .............................. 4-10

PNP/PCIConfiguration .................................. 4-13

LoadSetupDefaults ....................................... 4-14

P2-100B

IntegratedPeripherals ..................................... 4-15

Change Supervisor or User Password ............. 4-19

IDEHDDAutoDetection............................... 4-20

HDDLow LevelFormat................................. 4-22

Save&ExitSetup .......................................... 4-22

ExitWithoutSaving......................................... 4-22

Appendix

Appendix A

MemoryMap ................................................. A-1

I/O Map......................................................... A-1

Timer& DMAChannelsMap......................... A-2

InterruptMap ................................................. A-2

RTC & CMOS RAM Map ............................ A-3

Appendix B

POST Codes ................................................. A-5

UnexpectedErrors ......................................... A-8

Appendix C

LoadSetupDefaults ....................................... A-9

Appendix D

CPU Clock Frequency Selection In BIOS Setting

...................................................................... A-10

IntroductionP2-100B

Page 1-1

Section 1

INTRODUCTION

Components Checklist

üü

üA. (1) P2-100B mainboard

üü

üB. (1) P2-100B user’s manual

üü

üC. (1) Floppy ribbon cable

üü

üD. (1) Hard drive ribbon cable

E. (1) PS/2 Mouse Connector

üü

üF. (1) Bus master drivers

üü

üG. (1) COM Port/LPT Port Connector

USERS

MANUAL

P2-100B

Introduction P2-100B

Page 1-2

Overview

Pentium II

The Pentium®II Processor is the follow-on to the Pentium®Processor. The

Pentium®II Processor, like the Pentium®Pro processor, implements a Dynamic

Execution micro-architecture -- a unique combination of multiple branch prediction,

data flow analysis, and speculative execution. This enables the Pentium®II Proces-

sor to deliver higher performance than the Pentium®processor, while maintaining

binary compatibility with all previous Intel architecture processors.

A significant feature of the Pentium®II Processor, from a system perspective, is the

built-in direct multiprocessing support. In order to achieve multiprocessing, and

maintain the memory and I/O bandwidth to support it, new system designs are

needed. For systems with dual processors, it is important to consider the additional

power burdens and signal integrity issues of supporting multiple loads on a high speed

bus. The Pentium®II Processor card supports both uni-processor and dual processor

implementations.

The Pentium®II Processor utilizes Single Edge Contact (S.E.C.) (Figure 1) cartridge

packaging technology. The S.E.C. cartridge allows the L2 cache to remain tightly

coupled to the processor, while maintaining flexibility when implementing high perfor-

mance processors into OEM systems. The second level cache is performance

optimized and tested at the cartridge level. The S.E.C. cartridge utilizes surface

mounted core components and a printed circuit board with an edge finger

connection. The S.E.C. cartridge package introduced on the Pentium®II Processor

will also be used in future Slot 1 processors.

The S.E.C. cartridge has the following features: a thermal plate, a cover and a PCB

with an edge finger connection. The thermal plate allows standardized heatsink

attachment or customized thermal solutions. The thermal plate enables a reusable

heatsink to minimize fit issues for serviceability, upgradeability and replacement. The

full enclosure also protects the surface mount components. The edge finger connec-

tion maintains socketabilty for system configuration. The edge finger connector is

denoted as ‘Slot 1 connector’ in this and other documentation.

The entire enclosed product is called the Pentium®II Processor. The packaging

technology and each of the physical elements of the product are referred to using

accurate technical descriptions. This allows clear reference to the products as just a

IntroductionP2-100B

Page 1-3

processor. This is the model used in past packaging technologies like PGA, TCP,

PQFP, DIP, etc.

S.E.C. Cartridge Terminology

• Pentium®II Processor

The new enclosed card packaging technology is called a “Single

Edge Contact cartridge.” This is similar to previous names for

packaging technology such as PGA or TCP.

• Processor card

The green PCB (with or without components on it)

• Processor core

The silicon on the PLGA package on the PCB

• Cover

The plastic cover on the opposite side from the thermal plate.

• Slot 1

The slot that the S.E.C. cartridge plugs into, just as the Pentium®

Pro processor uses Socket 8.

• Retention mechanism

Formerly ‘retention module’ the dual posts, etc. that holds the

cartridge in place.

• Thermal plate

The heatsink attachment plate.

• Heat sink supports

The support pieces that are mounted on the mainboard to provide

added support for heatsinks.

Figure 1: Pentium®II Processor

CPU with S.E.C. Cartridge

Processor

Printed Circuit Board

Thermal Plate

Cover

The L2 cache (TagRAM, PBSRAM)

components keep standard industry

names.

The Pentium®II Processor is the first

product to utilize the S.E.C. cartridge

technology and Slot 1 connector. Unless

otherwise noted, any references to

“Pentium®II Processor,” “Pentium®II

Processor/Slot 1 processor” or Proces-

sor” will apply to both the Pentium®II

Processor desktop processors.

Introduction P2-100B

Page 1-4

Accelerated Graphics Port

(AGP or A.G.P.)

Typically, 3D graphics rendering requires a tremendous amount of memory, and

demands ever increasing throughput speed as well. As 3D products for the personal

computer become more and more popular, these demands will only increase. This

will cause a rise in costs for both end users and manufacturers. Lowering these

costs as well as improving performance is the primary motivation behind AGP. By

providing a massive increase in the bandwidth available between the video card and

the processor, it will assist in relieving some of these pressures for quite sometime.

Hardware Monitoring

Hardware monitoring allows you to monitor various aspects of your systems opera-

tions and status. The features include CPU temperature, voltage and RPM of fan.

Desktop Management Interface

(DMI)

DMI, or Desktop Management Interface, is a BIOS level method for monitoring

specific BIOS related hardware features. It allows the BIOS to collect and store

information specific to the system, so that vendors and system integrators will have

greater access to information regarding system configuration and design. This allows

for better troubleshooting, migration planning, and upgradeability decision making.

Table des matières

Autres manuels EPOX Carte mère

EPOX

EPOX IP-4PCI2E Series Manuel utilisateur

EPOX

EPOX nVIDIA nForce3 250Gb Manuel utilisateur

EPOX

EPOX EP-D3VA Manuel utilisateur

EPOX

EPOX EP-3VWM Manuel utilisateur

EPOX

EPOX S7-530A Manuel utilisateur

EPOX

EPOX EP-8KTA Manuel utilisateur

EPOX

EPOX M762A Series Manuel utilisateur

EPOX

EPOX EP-61BXC-A Manuel utilisateur

EPOX

EPOX 61BXA-M Manuel utilisateur

EPOX

EPOX P55-BT Manuel utilisateur

EPOX

EPOX AMD Socket et A Processor based AGP (8X)... Manuel utilisateur

EPOX

EPOX EP-3VBM+ Manuel utilisateur

EPOX

EPOX MVP3E Manuel utilisateur

EPOX

EPOX PP6-NF Manuel utilisateur

EPOX

EPOX EP-GXB-M Manuel utilisateur

EPOX

EPOX EP-3VCA Manuel utilisateur

EPOX

EPOX EP-8kem Manuel utilisateur

EPOX

EPOX LX370Y Manuel utilisateur

EPOX

EPOX EP-BX3 Manuel utilisateur

EPOX

EPOX 8KTA Manuel utilisateur

EPOX

EPOX EP-BX6 Manuel utilisateur

EPOX

EPOX 8U1697 GLI Manuel utilisateur

EPOX

EPOX MVP4F Manuel utilisateur

EPOX

EPOX EP-ZX370Y Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
