EOS Farblichtmodul Manuel utilisateur

Druck Nr. 29343325en/ - 43.06

Assembly instruction

Farblichtmodul

2GB

lInstallation of electrical equipment

should only be carried out by authorised

electrician.

lRegulations of public ullity (EVU) as well

as appropriate VDE-rules (DIN VDE

0100) must be abided.

lAttention! Danger for life! Please do not

repair and install the equipment yourself.

The cover should only be removed by

qualified personnel only!

lThe equipment should be disconnected

from all power system! Power supply and

fuses have to be switched off completely.

General security rules

Assembly the coloured light module in control unit EMOTEC HCS9003,

/ DC9000 / HIC 75 (ArtNr. 9427671)

plug socket

plug (double-pole)Connecting screws (3 parts)

Layout of coloured light module

Fig. 5

N (blue)

red

yellow

green

blue

Mounting of coloured light module (ArtNr. 942761)

in control unit EMOTEC HCS 9003

Please open the control unit just as described in the assembly instruction.

clamps for

supply lines

Fig 2

Fig. 3

pin border

Fig. 4

Please establish the electrical connection.

- The power supply line for the coloured

light module (longish wire) should be

connected with the clamps below the

transformer.

- The outgoing lines (shortish wire) should

be insert to the attached terminal. The

correct order of the wires has to access

to following colours (fig. 3):

N - red - yellow - green - blue

lease insert now the coloured light module

on to the plug border.

(blue)

red yellow green blue

4GB

safety

screws

plug border

Fig. 5

Fix the coloured light module with the

attached screw.

Attention:

Contact pins should catch the pin border.

Starting up

Please find the appliance of coloured light

modules in the instruction of the

appropriated control unit EMOTEC

HCS9003 / DC9000.

Fig. 6

Please press the mounting nib into the

inside with a flat screwdriver.

Pivot the upper part to open it.

Open the control unit

Remove the safety spinner

Remove the both safety spinner Àand Á

with a screwdriver.

The preparing for the instruction

ÀÁ

Fig. 7

Open the clamp plate

Lift the clamp plate and turn it up.

Fig. 8

Make plug connection

Connect the plug socket of coloured light

module with the pins of the plug at the

mainboard (fig. 9 and 11).

Fig. 9

plug socket (double-pole) pins

Connect the coloured light module to the

spacers with the 3 mounting screws.

Mounting of coloured light module

Fig. 10

mounting screws

6GB

Connect the plug

Insert the double-pole plug in the

appropriate socket at the mainboard (see

fig. 6) .

Install the clamp plate

Reinstall the clamp plate.

It must be catched into the 4 pins of the

plug.

Fig. 11

pins

Fig. 12

masked

Impress the safety spinner

Impress (tight fit) the both safety spinners

again.

ÀÁ

Fig. 13

Connection of cable

Please connect the cables with the upper

clamps sequential from left to right

according to the clamps inscription.

N - red- yellow - green - blue

Fig. 14

Mounting of coloured light

appliance

Fig. 15

Connect the coloured light appliance with

those clamps which are marked in the

figure according to the clamps inscription.

Please regard the connection schema at

fig.1.

Maximum allowable light power: 100 W

Close the upper cover

Please close the upper cover.

Fig. 16

Starting up

Please find the appliance of coloured light

modules in the instruction of the

appropriated control unit HIC 75.

Table des matières

Autres manuels EOS Unité de contrôle

EOS

EOS EmoTouch 3 Manuel utilisateur

EOS

EOS ECON 45A1 Guide de planification

EOS

EOS Infratec Classic Guide de planification

EOS

EOS InfraStyle Manuel utilisateur

EOS

EOS EMOTEC L 09 Relay Manuel utilisateur

EOS

EOS InfraStyle Manuel utilisateur

EOS

EOS SBM-App Manuel utilisateur

EOS

EOS EmoTouch 3 Manuel utilisateur

EOS

EOS Saunabus Soundmodul Series Manuel utilisateur

EOS

EOS ECON H4 Guide de l'utilisateur

EOS

EOS Emotec D Manuel utilisateur

EOS

EOS ECON F1 Manuel utilisateur

EOS

EOS EmoTouch 3 Manuel utilisateur

EOS

EOS EmoTouch II + Manuel utilisateur

EOS

EOS Compact D18 Manuel utilisateur
